The TurboChef 30˝
Model NuMbers
Voltage 208 VAC
240 VAC
dimenSionS
Overall Oven Height
Width
Depth
Depth from Wall
Weight
Top Oven Cavity Height
Width
Depth
Cooking Space
Bottom Oven Cavity Height
Width
Depth
Cooking Space
electrical SpecificationS
Electrical Supply Phase
Requirements Frequency
Current
Cord
Voltage (VAC)
Connection (see note 3)
Total Connected Power (see note 4)
NOTE:
1. "*" Indicates a two letter code – OR, RD, BU, CH, IV, WH, or SS – which refers to the oven door color.
2. Dimensions in parentheses are in millimeters unless otherwise noted.
3. Unit includes a 5½ foot flex conduit to be used between the oven and conduit box. Connectors are
supplied by installation electrician.
4. Branch circuit must be protected with a 50 Amp (Double Wall Oven) or 30 Amp (Single Wall Oven)
over-current protector.
5. See back of this page for illustrations.
Specifications are subject to change without notice.
with top door open
with bottom door open

SpecS and dimenSionS

30˝ double Wall
TDO30 – * – 208
TDO30 – * – 240
50¼˝ (1276)
30˝ (762)
23 / ˝ (607)
7
8
4¼˝ (108)
17½˝ (445)
19½˝ (495)
410 lbs. (186 kg.)
12˝ (305)
24˝ (610)
15˝ (381)
2½ cu. ft.
15½˝ (394)
24˝ (610)
17½˝ (445)
3¾ cu. ft.
Single
60 Hz
50 Amp
4-wire (inc. ground)
208 (TDO30 – * – 208)
240 (TDO30 – * – 240)
5½ foot flex conduit
50 Amps
page 1 of 2
30˝ siNgle Wall
TSO30 – * – 208
TSO30 – * – 240
26½˝ (673)
30˝ (762)
23 / ˝ (607)
7
8
4¼˝ (108)
17½˝ (445)
n/a
230 lbs. (105 kg.)
12˝ (305)
24˝ (610)
15˝ (381)
2½ cu. ft.
n/a
n/a
n/a
n/a
Single
60 Hz
30 Amp
4-wire (inc. ground)
208 (TSO30 – * – 208)
240 (TSO30 – * – 240)
5½ foot flex conduit
30 Amps
