Magnadyne LS7500CD Owner's Manual

Linear series am/fm stereo receiver and compact disc player
Hide thumbs
Table of Contents

Advertisement

Quick Links

LS7500CD
08/03/00
2:49 PM
Page 1
OWNER'S MANUAL
LS7500CD
AM/FM Stereo Receiver and Compact Disc Player
Designed for In-Wall Installation of All Recreational Vehicles, Motor Homes and Mobile Housings
12 Volts DC
A Registered Trademark of Magnadyne Corporation

Advertisement

Table of Contents
loading

Related Manuals for Magnadyne LS7500CD

Summary of Contents for Magnadyne LS7500CD

  • Page 1 LS7500CD 08/03/00 2:49 PM Page 1 OWNER'S MANUAL LS7500CD AM/FM Stereo Receiver and Compact Disc Player Designed for In-Wall Installation of All Recreational Vehicles, Motor Homes and Mobile Housings 12 Volts DC A Registered Trademark of Magnadyne Corporation...

  • Page 2: Controls And Functions

    LS7500CD 08/03/00 2:49 PM Page 2 INTRODUCTION Please read all of the information in this booklet before using this unit to insure that you fully understand the capabilities of this unit. CONTROLS AND FUNCTIONS WARNING! To prevent fire or electrical shock hazard, do not expose this product to rain or moisture, or remove cover or bottom screws.
  • Page 3 LS7500CD 08/03/00 2:49 PM Page 3 CONTROLS AND FUNCTIONS 1. On / Off Button Press this button in to turn the unit on. Press again to turn the unit off. 2. AM / FM / CD Function Knob After turning the unit on, select the desired playing mode with this knob.
  • Page 4 LS7500CD 08/03/00 2:49 PM Page 4 CONTROLS AND FUNCTIONS 17. Random Button Use the random button to play the disc tracks in an random order selected by the disc player computer. 18. Intro Button Use the intro button to listen to the first 10 seconds of all the tracks on the compact disc.
  • Page 5 LS7500CD 08/03/00 2:49 PM Page 5 CONTROLS AND FUNCTIONS Using the Program Feature: If you desire to have the song selection of the disc played in a different order than arranged on the disc, repeat the following procedures to program the playing order.
  • Page 6 LS7500CD 08/03/00 2:49 PM Page 6 CONTROLS AND FUNCTIONS Using the Repeat Feature: The repeat feature has two modes of operation. A single track can be continuously repeated or the entire disc can be continuously repeated. 1. Press the repeat button one time while a track is playing.

  • Page 7: Installation

    LS7500CD 08/03/00 2:49 PM Page 7 INSTALLATION Wall Panel End Caps Structural Caution: Do not install radio without rear Stud cover installed. No user-serviceable parts inside. Rear cover provides protection against potential fire hazard.

  • Page 8: Power Connections

    LS7500CD 08/03/00 2:49 PM Page 8 POWER CONNECTIONS This unit for use only with a 12 volt DC power source with a negative ground. RED Wire (+) To 12 Volt DC Power BLACK Wire (-) Ground...

  • Page 9: Speaker Connections

    LS7500CD 08/03/00 2:49 PM Page 9 SPEAKER CONNECTIONS Left Speaker (A) BROWN Wire ORANGE Wire GREEN Wire Left Speaker (B) Speaker Connections: Do not confuse the A and B speaker sets Right Speaker (A) GRAY Wire WHITE Wire BLUE Wire...

  • Page 10: Antenna Connections

    If an automotive antenna is not available or is undesired, we recommend the use of a Magnadyne DP36AXT di-pole antenna substitute. Plug the male plug from the DP36AXT into the female receptacle of the LS7500CD unit and allow the cable of the antenna to lay inside the wall.

  • Page 11: Safety Instructions

    LS7500CD 08/03/00 2:49 PM Page 11 SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be read before the appliance is operated. Retain Instructions: The safety and operating instructions should be retained for future reference. Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to.

  • Page 12: Operation And Maintenance

    Magnadyne Corporation or its authorized agents, if said product or part is found defective in materials or workmanship, when properly connected and operating on the correct power requirements designated for the specific product.
