- Page 1 LS4000W, LS4000B, LS4000S LS4001W, LS4001B, LS4001S AM/FM Stereo Receiver and Compact Disc Player Designed for In-Wall Installation of All Recreational Vehicles, Motor Homes and Mobile Housings 12 Volts DC U.S. Patent No. D502, 461 A Registered Trademark of Magnadyne Corporation...
-
Page 2: Controls And Functions
INTRODUCTION Please read all of the information in this booklet before using this unit to insure that you fully understand the capabilities of this unit. CONTROLS AND FUNCTIONS WARNING! To prevent fire or electrical shock hazard, do not expose this product to rain or moisture, or remove cover or bottom screws. - Page 3 CONTROLS AND FUNCTIONS 1. Power Button (PWR) Press this button in to turn the unit on. Press again to turn the unit off. 2. AM/ FM Button Press the button to select the desired AM or FM radio band. 3. CD / Tuner Button Press this button to select the desired playing mode either AM/FM radio or CD player.
-
Page 4: Radio Operation
CONTROLS AND FUNCTIONS 16. Random Button Use the random button to play the disc tracks in a random order selected by the disc player's computer. 17. Repeat Button Use the repeat button to continuously play one song repeat- edly or to continuously play the entire disc repeatedly. Radio Operation: 1. - Page 5 CONTROLS AND FUNCTIONS Using the Compact Disc Program Feature: If you desire to have the song selection of the disc played in a different order than arranged on the disc, repeat the following procedures to program the playing order. 1. When the CD disc is stopped, press the PROGRAM button (10).
-
Page 6: Using The Repeat Feature
CONTROLS AND FUNCTIONS Using the Repeat Feature: The repeat feature has two modes of operation. A single track can be continuously repeated or the entire disc can be continuously repeated. Repeating Single CD Track: Press the REPEAT button (17) one time while a CD is playing. "REP"... -
Page 7: Installation
INSTALLATION End Caps Caution: Do not install radio without rear cover installed. No user-serviceable parts inside. Rear cover provides protection against potential fire hazard. -
Page 8: Power Connections
POWER CONNECTIONS This unit for use only with a 12 volt DC power source with a negative ground. RED Wire (+) To 12 Volt DC Power BLACK Wire (-) Ground... -
Page 9: Speaker Connections
SPEAKER CONNECTIONS Left Speaker (A) BROWN Wire ORANGE Wire GREEN Wire Speaker Connections: Do not confuse the A and B speaker sets Left Speaker (B) GRAY Wire WHITE Wire BLUE Wire Right Speaker (A) Right Speaker (B) -
Page 10: Antenna Connections
Either If an automotive antenna is not available or is undesired, we recommend the use of a Magnadyne DP36AXT di-pole anten- na substitute. Plug the male plug from the DP36AXT into the female receptacle of the LS4000 or LS4001 unit and allow the... -
Page 11: Safety Instructions
SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be read before the appliance is operated. Retain Instructions: The safety and operating instructions should be retained for future reference. Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to. -
Page 12: Operation And Maintenance
CD’s Fahrenheit Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the Magnadyne Corporation or its authorized...
