- Page 1 LS3500CD-LS3500CDW Manual 8/13/04 4:15 PM Page 1 OWNER'S MANUAL LS3500CDB, LS3500CDW, LS3500CDS AM/FM Stereo Receiver and Compact Disc Player Designed for In-Wall Installation of All Recreational Vehicles, Motor Homes and Mobile Housings 12 Volts DC A Registered Trademark of Magnadyne Corporation...
-
Page 2: Controls And Functions
LS3500CD-LS3500CDW Manual 8/13/04 INTRODUCTION Please read all of the information in this booklet before using this unit to insure that you fully understand the capabilities of this unit. CONTROLS AND FUNCTIONS 4:15 PM Page 2 WARNING! To prevent fire or electrical shock hazard, do not expose this product to rain or moisture, or remove cover or bot- tom screws. - Page 3 LS3500CD-LS3500CDW Manual 8/13/04 CONTROLS AND FUNCTIONS 1. Power Button Press this button in to turn the unit on. Press again to turn the unit off. 2. AM / FM / CD Function Knob After turning the unit on, select the desired playing mode with this knob.
-
Page 4: Compact Disc Operation
LS3500CD-LS3500CDW Manual 8/13/04 CONTROLS AND FUNCTIONS 16. Random Button Use the random button to play the disc tracks in an random order selected by the disc player computer. 17. Repeat Button Use the repeat button to continuously play one song repeatedly or to continuously play the entire disc repeatedly. - Page 5 LS3500CD-LS3500CDW Manual 8/13/04 CONTROLS AND FUNCTIONS Using the Program Feature: If you desire to have the song selection of the disc played in a different order than arranged on the disc, repeat the following procedures to program the playing order. 1.
- Page 6 LS3500CD-LS3500CDW Manual 8/13/04 CONTROLS AND FUNCTIONS Using the Repeat Feature: The repeat feature has two modes of operation. A single track can be continuously repeated or the entire disc can be continuously repeated. 1. Press the repeat button (17) one time while a CD is playing. REP will be flashing in the compact display (18) area.
-
Page 7: Installation
LS3500CD-LS3500CDW Manual 8/13/04 4:15 PM Page 7 INSTALLATION Wall Panel End Caps Structural Caution: Do not install radio without rear Stud cover installed. No user-serviceable parts inside. Rear cover provides protection against potential fire hazard. -
Page 8: Power Connections
LS3500CD-LS3500CDW Manual 8/13/04 POWER CONNECTIONS This unit for use only with a 12 volt DC power source with a negative ground. RED Wire (+) To 12 Volt DC Power BLACK Wire (-) Ground 4:15 PM Page 8... -
Page 9: Speaker Connections
LS3500CD-LS3500CDW Manual 8/13/04 SPEAKER CONNECTIONS Left Speaker (A) BROWN Wire ORANGE Wire GREEN Wire Left Speaker (B) Speaker Connections: Do not confuse the A and B speaker sets 4:15 PM Page 9 Right Speaker (A) GRAY Wire WHITE Wire BLUE Wire Right Speaker (B) -
Page 10: Antenna Connections
Either If an automotive antenna is not available or is undesired, we recommend the use of a Magnadyne DP36AXT di-pole anten- na substitute. Plug the male plug from the DP36AXT into the female receptacle of the LS3500CD unit and allow the cable... -
Page 11: Safety Instructions
LS3500CD-LS3500CDW Manual 8/13/04 SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be read before the appliance is operated. Retain Instructions: The safety and operating instructions should be retained for future reference. Heed Warnings: All warnings on the appliance and in the oper- ating instructions should be adhered to. -
Page 12: Operation And Maintenance
WARRANTY ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the Magnadyne Corporation or its authorized...
