Installation and
Operations Manual
POWER
AM/FM/CD RECEIVER
EJECT
VOL
DISP
BAND
MUTE
SEL
LOUD/DIM
VOL
OPEN
SHIFT
MODE
SCAN
1
2 MEM
3 PGM
4 RPT
5 RDM
6 INT
AS/PS
ELAPSE
M4100CD
Water-Resistant
AM/FM/WB and CD Stereo Receiver
A Registered Trademark of Magnadyne Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Linear M4100CD and is the answer not in the manual?

Questions and answers

Related Manuals for Magnadyne Linear M4100CD

Summary of Contents for Magnadyne Linear M4100CD

  • Page 1 Installation and Operations Manual POWER AM/FM/CD RECEIVER EJECT DISP BAND MUTE LOUD/DIM OPEN SHIFT MODE SCAN 2 MEM 3 PGM 4 RPT 5 RDM 6 INT AS/PS ELAPSE M4100CD Water-Resistant AM/FM/WB and CD Stereo Receiver A Registered Trademark of Magnadyne Corporation...
  • Page 2 M4100CDUM.qxd 07/24/03 4:29 PM Location and Function of Control at a Glance POWER SHIFT MODE SCAN 1. Power Button: Turns the unit On/Off. 2. Audio Control Buttons: Adjusts the Volume, Bass, Treble, Balance and Fader. 3. Multi-Function Buttons: Adjusts the radio frequency, sets the clock, and changes CD tracks. 4.
  • Page 3 M4100CDUM.qxd 07/24/03 4:29 PM Location and Function of Control at a Glance 9. Multi-Function Button 4/RPT: Radio: Recalls a memorized radio station, and programs a radio station into memory (See Radio Operation for more information). CD: Enters CD track repeat mode (See CD Operation for more information). 10.

  • Page 4: Using The Detachable Front Panel

    M4100CDUM.qxd 07/24/03 4:29 PM Using the Detachable Front Panel To Detach the Front Panel 1. Press the OPEN button (13), and the front panel will slide down to a flat position. Open Button 2. With the front panel down, press the bottom button of the front panel upward and pull the front panel out from the panel bracket.

  • Page 5: Radio Operation

    M4100CDUM.qxd 07/24/03 4:29 PM Radio Operation Listening to the Radio 1. Press the “BAND” button (17) to select a radio band: FM1, FM2, AM or WX (weather band). 2. AM or FM Station Selection: Automatic Seek Station Selection: Press the button (3) to automatically seek the next strong station.

  • Page 6: General Operations

    M4100CDUM.qxd 07/24/03 4:29 PM General Operations Setting the Clock 1. Press DISP button (16) for more than 3 seconds until the clock shown in the display area is flash- ing. 2. Press the button (3) to adjust the hours 3. Press the button (3) to adjust the minutes.
  • Page 7 M4100CDUM.qxd 07/24/03 4:29 PM CD Operation Inserting a Disc Push the Open button (13) to open the front panel. Insert a disc into the CD Slot, label side up, and the disc will begin to play automatically. Ejecting a Disc Push the Open button to open the front panel.

  • Page 8: Installation Procedure

    M4100CDUM.qxd 07/24/03 4:29 PM Installation Procedure Step 1: The radio chassis is designed to be “Sleeve Mounted” through a opening in the dashboard panel. The required opening size is 182mm (7-3/16") x 84mm (3-5/16"). Cut or enlarged an opening in the dashboard to accommodate the mounting sleeve.

  • Page 9: Wiring Diagram

    White Wire with Black Stripe Left Green Wire Rear Speaker Green Wire with Black Stripe Page 9 M4100CD Audio Line Out Connect to Line Input of Optional Amplifier Gray Wire Gray Wire with Black Stripe Violet Wire Violet Wire with Black Stripe...

  • Page 10: Final Installation

    M4100CDUM.qxd 07/24/03 4:29 PM Final Installation Push Out Mounting Sleeve Tabs Removing the Unit from Dashboard: Remove the metal strap holding the back of the radio chassis. With the front panel in the down position, insert removal keys into the small slots in the upper part of chassis panel.
  • Page 11 M4100CDUM.qxd 07/24/03 4:29 PM CD Changer Connection M4100CD 8-Pin Din Connector Wired Remote Connection M4100CD Female 8-Pin Mini Din Connector Page 11 CD Changer (Optional) Male to Male 8-Pin Din Cable (Supplied with CD changer) Wired Remote (Optional) Male 8-Pin...

  • Page 12: Specifications

    ONE (1) YEAR LIMITED WARRANTY Magnadyne Corporation or its authorized agents will within one year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of...
