Megatron PORTI-T380 Operator's Manual

Kiosk & ticket printer
Hide thumbs Also See for PORTI-T380:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
PORTI-T380
MODEL
(Kiosk & Ticket Printer)
All specifications are subjected to change without notice
Megatron S.A.R.L - 451 route des Blaves - Z.I de Noyer
74200 ALLINGES - FRANCE
+33 (0)4.50.70.54.54
http://www.megatron.fr

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PORTI-T380 and is the answer not in the manual?

Questions and answers

Related Manuals for Megatron PORTI-T380

Summary of Contents for Megatron PORTI-T380

  • Page 1 PORTI-T380 MODEL (Kiosk & Ticket Printer) All specifications are subjected to change without notice Megatron S.A.R.L - 451 route des Blaves - Z.I de Noyer 74200 ALLINGES - FRANCE +33 (0)4.50.70.54.54 http://www.megatron.fr...
  • Page 2 150mm/sec high-speed printer. The 3inch thermal panel printer is most suitable for ticketing applications, such as transportation, coupons, industrial machine, lottery, ATM and kiosks. The general features of PORTI-T380 printer are as follows: Very silent printing thru direct thermal printing method. High speed(150mm/sec, MAX)

  • Page 3: Operating Precautions

    ¦ Operating Precautions Please follow the precautions below to enjoy and maintain the full performance of the printer. Using the Printer ● Be careful not to drop or bump the printer on a hard surface. ● Do not install the printer in direct sunlight or such areas. Suitable environment for the use of the printer is as follows: ◆...

  • Page 4: Table Of Contents

    CONTENTS 1. Outline .............................. 5 1.1. Model classifications ......................5 1.2. Product Part Number System ....................5 1.3. Specifications ......................... 6 2. Setting up the printer ........................7 2.1. Printer & Accessories ......................7 2.2. Printer Features ........................8 2.3.

  • Page 5: Outline

    PORTI-T380 ( Model name Interface None: UART Power None : DC 24V Model n ame / Interface S pec. Wired Wireless RS-232C Bluetooth SC30 IrDA None RS-485 Parallel None Serial/Bluetooth Part No. ⇒ S40/A1 Example) 1. Porti-S40 2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1...

  • Page 6: Specifications

    Item Specification Direct thermal line printing Printing method Characters per line 64cpl (MAX) Character size Eng. : 9*24dots, 12*24dots Kor. : 16*24dots, [24*24dots] Simplified/Traditional Chinese, Arabic, Cyrillic, Russian, Tukish, Optional Characters Greek, Japanese, Persian, Latin9 and Others upon request. 203dpi, 8dots/mm Resolution Print width 3-inch (72mm, 576dots)

  • Page 7: Setting Up The Printer

    & & When unpacking your printer box make sure it contains the printer and all accessories. If any accessories are missing or damage, please contact your dealer for assistance. PORTI-T380 Thermal roll paper...

  • Page 10: Replacing The Paper Roll

    Note : Be sure to use paper rolls that meet the specifications. Do not use paper rolls that have the paper glued to the core because the printer can not detect the paper end correctly. 1. Make sure that the printer is not receiving data; otherwise, data may be lost. 2.
  • Page 11 4. Be sure to not the correct direction that the paper comes off the roll. 5. Push in the paper, as shown. The paper will be loaded automatically.

  • Page 12: Power Supply

    The PORTI-T380 printer is equipped to an external supply electrical power. The functions assigned to the pins in the connector are as follows: WARNING A wrong connection of power supply connector could be damage the printer. 51004-0400 (MOLEX) Applicable connector : MOLEX 53014-0410 or equivalent.

  • Page 13: Sensor Connector(Option)

    Pin No. Pin Spec. Function Anode Signal Collector Emitter...

  • Page 14: Interface

    The PORTI-T380 printer has a UART(RS-232C or TTL)interface and is connected by means of a 3 pin female connector. In the following table, the signals present on the connector are listed: Pin No Name Direction Function Output Transmit Data Input...

  • Page 15: Using The Printer

    Button - FEED Button : When the printer is on, paper can be feed manually by pressing and holding the FEED button for more than one second. u Panel lamp Printer is ON and ready to receive data. -POWER : Indicates a fault condition or a printer error.

  • Page 16: Consumable Parts

    Type : Thermal Paper Paper width : 80mm Paper thickness : 60±5㎛ External diameter : Ø 80mm or less Inside di a meter : Ø 12m m Recording side : Outside of roll Cautions 1. Do not paste the paper to the core. And the roll paper which has near end mark printing on its near end is recommended.
