Chapter 1
1. 3. 2.
The Back Panel
The following parts are located on the back panel (View from left to right).Refer to the
following for detailed instructions.
Item
USB 2.0
Reset/WPS
Internet
The USB 2.0 port connects to a USB 2.0 storage device or a USB 2.0 printer.
Pressing this button for less than 5 seconds enables the WPS function. If your
client devices, such as wireless adapters, that support Wi-Fi Protected Setup, then
you can press this button to quickly establish a connection between the router
and client devices and automatically configure wireless security for your wireless
network.
Pressing this button for more than 5 seconds enables the Reset function. With
the router powered on, press and hold the Reset/WPS button for approximately 8
seconds. And then release the button and wait the router to reboot to its factory
default settings.
This port is where you will connect the DSL/cable Modem, or Ethernet.
Get to Know About Your Router
Description
7
