Monitor The Internet Traffic Statistics - TP-Link Archer C9 User Manual

Chapter 12
Tips: SMTP server is available for users in most webmail systems. For example, the SMTP server address of
Hotmail is smtp-mail.outlook.com. You can refer to their Help page to learn the SMTP server address.
4 ) Select Enable
Tips: Generally, Enable Authentication should be selected if the login of the mailbox requires username and
password.
5 ) Username: Enter the email address used to send the system log.
6 ) Password: Enter the password to login the sender's email address.
7 ) Select Enable Auto
Tips: The router will send the system log to the designated email address if this option is enabled.
8 ) Set a fixed time. The recipient will receive the system log sent at this time every
day.
5. Click Save.

12. 10. Monitor the Internet Traffic Statistics

The Traffic Statistics page displays the network traffic of the LAN, WAN and WLAN sent
and received packets, allows you to monitor the volume of Internet traffic statistics.
1. Visit http://tplinkwifi.net, and log in with the username and password you set for the
router.
2. Go to Advanced > System Tools
3. Toggle on Traffic Statistics, and then you can monitor the traffic statistics in
Statistics List section.
Note: Traffic Statistics and NAT Boost cannot be enabled at the same time, you need to disable NAT Boost first.
Please follow step a and b to disable NAT Boost .
a. Click NAT Boost.
b. Deselect Enable NAT Boost and click Save, then click
Authentication.
Mail.
> Traffic Statistics.
OK on the prompt window.
Manage the Router
Traffic
89
