Contents
•
1 Hardware
Specifications
•
2 How to install
DD-WRT
2.1 TP-Link
♦
Archer C9 v1
♦
2.2 TP-Link
Archer C9 v2
♦
2.3 TP-Link
Archer C9 v3,
v4
3 Troubleshooting
•
♦
3.1 Bricked
Router
♦
3.2 Recovery
Mode
Hardware Specifications
FCC ID
Industry Canada ID
Power
CPU
Architecture
RAM / Flash (ROM) 128 MiB / 16 MiB
Switch
LAN/WAN ports
USB Ports
JTAG
Serial
WI1 chip
WI1 protocols
WI1 MIMO config
WI1 antenna connector U.FL, RP-SMA
WI2 chip
WI2 protocols
WI2 MIMO config
WI2 antenna connector U.FL, RP-SMA
The Archer C1900 is identical.
Contents
TP_Link_Archer_C9
TE7C9
8853A-C9
12 VDC, 3.3 A
Broadcom BCM4709 @1 GHz
ARM Cortex A9 (2 cores)
Broadcom BCM4709
4 /1 @ 1 Gb/s
1x USB 2.0, 1x USB 3.0
internal
internal, 4-pin header, 3.3V TTL
Broadcom BCM4360
an+ac
3x3:3
Broadcom BCM4360
bgn
3x3:3
1
Advertisement
Table of Contents
Related Manuals for TP-Link Archer C9
Summary of Contents for TP-Link Archer C9
- Page 1 TP_Link_Archer_C9 Contents • 1 Hardware Specifications • 2 How to install DD-WRT 2.1 TP-Link ♦ Archer C9 v1 ♦ 2.2 TP-Link Archer C9 v2 ♦ 2.3 TP-Link Archer C9 v3, 3 Troubleshooting • ♦ 3.1 Bricked Router ♦ 3.2 Recovery...
- Page 2 ◊ E.g. build 04-05-2016-r29409 factory-to-ddwrt.bin • Upload the dd-wrt firmware using the standard TP-Link UI and wait until router reboots • Do a normal reset or nvram erase via telnet/ssh (Do not 30/30/30 an ARM router!) TP-Link Archer C9 v2 •...
- Page 3 The firmware will be automatically downloaded and installed by the router Symptoms: after the dd-wrt installation the MACs are changed! https://dd-wrt.com/phpBB2/viewtopic.php?t=282831&start=345 • • https://www.dd-wrt.com/forum/viewtopic.php?p=1003571 https://www.dd-wrt.com/forum/viewtopic.php?p=1116768 • Recovery Mode The v3 CFE has a built-in Webpage Firmware Recovery mode for bricked routers: see TP-Link article. Bricked Router...
