Chapter 2
2. 1.

Position Your Router

• The Product should not be located where it will be exposed to moisture or excessive
heat.
• Place the router in a location where it can be connected to the various devices as well
as to a power source.
• Make sure the cables and power cord are safely placed out of the way so they do not
create a tripping hazard.
• The router can be placed on a shelf or desktop.
• Keep away from the strong electromagnetic radiation and the device of
electromagnetic sensitive.
2. 2.

Connect Your Router

Follow the steps below to connect your router.
If your Internet connection is through an Ethernet cable from the wall instead of
through a DSL / Cable / Satellite modem, connect the Ethernet cable directly to the
router's Internet port, then follow steps 5 and 6 to complete the hardware connection.
Internet
Power adapter Modem
1. Install the antennas.
1
Router
2
3
4
Connect the Hardware
Power adapter
5
10
