ENGLISH
RAIS - manual for Rais Rina, Rais Viva & Rais Juno
INSTRUCTIONS FOR INSTALLATION,
USE AND MAINTENANCE
RAIS RINA, RAIS VIVA & RAIS JUNO
IMPORTANT INFORMATION
On first lighting the stove you must be careful not to touch the painted
surfaces and it is MOST IMPORTANT that the door is kept slightly 'ajar' in
order for the door seal and sealant to cure.
This will prevent the door seal sticking to the painted body and becoming
damaged.
1
