  • Page 5 English RAIS/ - User manual for RINA-HERA-VIVA-JUNO FIRE ENVIRONMENTALLY FRIENDLY! 5 Eco-friendly advices for sensible heating - common sense both environmentally and economically. 1. Effective lighting. Use small pieces of wood (fir tree) and a suit- able fire lighter, for example paraffined wood wool/sawdust.
  • Page 6: Table Of Contents

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Revision : Date 12-06-2017 INTRODUCTION ........................7 WARRANTY ..........................8 SPECIFICATIONS ........................9 DISTANCES ...........................10 CONVECTION ........................15 CHIMNEY ..........................15 INSTALLATION INSTRUCTIONS ....................16 INSTALLATION ........................17 INSTALLATION OF HERA WITH SWIVEL BASE .................18 CHANGE OF CHIMNEY CONNECTION ..................19 INSTALLATION DISTANCE IN CASE OF COMBUSTIBLE WALL ..........
  • Page 7: Date : 12-06-2017

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Introduction Thank you for purchasing a RAIS/attika wood burning stove. These appliances have been approved by SCA/HETAS Ltd as intermittent operating appliances for burning wood logs only. attika A RAIS/ wood burning stove is more than just a heat source. It also shows that you care about design and quality in your home.
  • Page 8: Warranty

    In the event of repair, we ensure proper and professional execution. Warranty claims submitted for additionally delivered or repaired parts are subject to national/EU laws and regulations in terms of renewed warranty periods. Please contact RAIS A/S for the applicable warranty provisions.
  • Page 9: Specifications

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Specifications...
  • Page 10: Distances

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Danish Technological Institute Teknologiparken Kongsvang Allé 29, DK-8000 Aarhus C Denmark www.dti.dk Telephone: +45 72 20 20 00 Fax: +45 72 20 10 19 DIstances See drawing of the stove in front of the manual. All dimensions are stove dimensions without handle and set screws.
  • Page 11 HERA...
  • Page 12 VIVA 98       VIVA 98 G    ...
  • Page 13 VIVA 120               VIVA 120 G        ...
  • Page 14 JUNO JUNO 166 JUNO 120 JUNO G JUNO 166 G JUNO 120 G...
  • Page 15: Convection

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Convection attika RAIS/ stoves are convection stoves. This means that the stove’s back and side panels are not over-heated. Convection means that there is a circulation of air, which ensures that the heat is distributed more evenly throughout the entire room.
  • Page 16: Revision

    • If this appliance is installed into an existing chimney, the chimney must first be swept and examined for soundness and suitability before the appliance is installed (see also section headed “Chimney”). NOTE! This appliance may only be installed by a qualified RAIS dealer/installer. See www.rais.com for dealer list.
  • Page 17: Installation

    RAIS recommends to consult a building expert. When you choose where to set up your RAIS wood burning stove, you should consider the heat distribution to the other rooms. This will enable you to get the best use out of your stove.
  • Page 18: Installation Of Hera With Swivel Base

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Installation of HERA with swivel base The stove can be fitted with and without a swivel base. If the stove is supplied with a swivel base, it is mounted below the stove and secured with 2 wing screws (transport safety).
  • Page 19: Change Of Chimney Connection

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Change of chimney connection The stove is delivered ready for top outlet, but may be changed to back outlet in the following way: Sample photos Strike out the knock out plate at the rear of stove.
  • Page 20: Installation Distance In Case Of Combustible Wall

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Installation distance in case of combustible wall Normal set-up (corner setting) RINA 90 / HERA Uninsulated flue A. Distance to furniture (min.) 700 mm Distance to flammable materials (min.) B. in front (floor)
  • Page 21 English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Normal set-up (corner setting) VIVA / JUNO VIVA G / JUNO G Uninsulated flue A. Distance to furniture (min.) 700 mm 650 mm Distance to flammable materials (min.) if distances are not shown, B.
  • Page 22 English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Corner setting 45° RINA 90 / HERA Uninsulated flue A. Distance to furniture (min.) 700 mm Distance to flammable materials (min.) B. in front (floor) if distances are not shown, national/local regulations are followed C.
  • Page 23 English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Corner setting 45° VIVA / JUNO VIVA G / JUNO G Uninsulated flue A. Distance to furniture (min.) 700 mm 650 mm Distance to flammable materials (min.) if distances are not shown, B.
  • Page 24 English RAIS/ - User manual for RINA-HERA-VIVA-JUNO VIVA / JUNO / 360° swivel base VIVA G / JUNO G Hera Uninsulated flue A. Distance to furniture (min.) 700 mm 650 mm Distance to flammable materials (min.) if distances are not shown, B.
  • Page 25: Installation Distance In Case Of Non Combustible Wall

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Installation distance in case of non-combustible wall We recommend a minimum distance to non-combustible material of 50 mm (F) for cleaning considerations. It should always be possible to access the access door.
  • Page 26: Fuel

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Operating instructions Please note that HETAS Ltd Appliance Approval only covers the use of dry seasoned wood logs on this appliance. HETAS Ltd Approval does not cover the use of other fuels either alone or mixed with the wood logs, nor does it cover instructions for the use of other fuels.
  • Page 27: Drying And Storage

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Drying and storage Drying wood takes time. Proper air drying takes approx. 2 years. Here are some tips: • Store the wood sawn, split and stacked in an airy, sunny place, which is protected against rain (the south side of the house is particularly suitable).
  • Page 28: Using The Wood Burning Stove

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Using the wood burning stove Adjustment of the air damper - the damper has 3 settings Position 1 Pull the lever to the left. The damper is almost closed; there is a minimal air intake. This position must be avoid- ed during normal operation.
  • Page 29: Lighting And Fuelling

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO IMPORTANT - Warning Note! Properly installed, operated and maintained this appliance will not emit fumes into the dwelling. Occasional fumes from de-ashing and re-fuelling may occur. However, persistent fume emission is potentially dangerous and must not be tolerated. If fume emission does persist, the following immediate actions should be taken: 1.
  • Page 30 When refueling, open the door carefully to avoid smoke escaping. Never add wood while it is burning (flames!) in the stove. RAIS recommends to refuel with 2-3 pieces wood - approx. 1 ½ kg - within 58 minutes (intermittent operation).
  • Page 31 English RAIS/ - User manual for RINA-HERA-VIVA-JUNO...
  • Page 32: Warning

    Advarsel attika English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Hvis brændet kun ulmer eller ryger, og der tilføres for lidt luft, udvikles der Hvis brændet kun ulmer eller ryger, og der tilføres for lidt luft, udvikles der Hvis brændet kun ulmer eller ryger, og der tilføres for lidt luft, udvikles der Warning!! uforbrændte røggasser.
  • Page 33: Upper Convection - Hera

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Upper convection - HERA HERA stove has a convection grate in the top plate. Close the upper convection plate of the When the stove is getting hot the stove when lighting upper convection can now be opened (turn handle counterclockwise).
  • Page 34: Cleaning And Care

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Cleaning and care Glass Most woodstoves use a ceramic glass product which is resistant to heat but requires cleaning to keep its appearance. Soot or opaque marks can easily cleaned if the marks are fresh, however If you leave...
  • Page 35: Cleaning Of Flue Ways

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Cleaning of flue ways In order to gain access to the smoke flue, remove the upper plate – baffle plate made of vermiculite and the smoke barrier (steel plate). Handle the parts with care. Remove the baffle plate by tilting it backwards and turning it a little slantwise.
  • Page 36 In case of cold chimney or difficult weather conditions you can compensate by adding more fresh air (open the damper) to the stove than usual. If your stove continues to malfunction, we recommend that you contact your RAIS distrib- utor or chimney sweep.
  • Page 37 English RAIS/ - User manual for RINA-HERA-VIVA-JUNO...
  • Page 38: Mounting The Soapstones - Rina Sst

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO Mounting the soapstones - RINA SST 3327002 0110-M5x16 cyl rå (BN272) 3327006 0110-M8x35 pinol ki (BN433) 3327006 0110-15x7x5,2...
  • Page 39: Accessories

     0.9 Spare parts RINA 90 If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor. For reference see spare parts drawing (back of manual).
  • Page 40: Spare Parts Hera

    - User manual for RINA-HERA-VIVA-JUNO Spare parts HERA If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor. For reference see spare parts drawing (back of manual).
  • Page 41: Spare Parts Viva 98 - Viva 120

    - User manual for RINA-HERA-VIVA-JUNO Spare parts VIVA 98 - VIVA 120 If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor.
  • Page 42: Spare Parts Viva 98 G - Viva 120 G

    - User manual for RINA-HERA-VIVA-JUNO Spare parts VIVA 98 G - VIVA 120 G If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor.
  • Page 43: Spare Parts Juno 120 / Juno 166

    - User manual for RINA-HERA-VIVA-JUNO Spare parts JUNO 120 / JUNO 166 If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor.
  • Page 44: Spare Parts Juno 120 G / Juno 166 G

    - User manual for RINA-HERA-VIVA-JUNO Spare parts JUNO 120 G / JUNO 166 G If spare parts other than those recommended by RAIS are used, the warranty is voided. All replaceable parts can be bought as spare parts from your RAIS distributor.
  • Page 45: Declaration Of Performance

    English RAIS/ - User manual for RINA-HERA-VIVA-JUNO...
  • Page 46 RINA 90...
  • Page 47 Hera...
  • Page 48 VIVA 98 VIVA 120 23185 VIVA 9...
  • Page 49 VIVA 98 G VIVA 120 G...
  • Page 50 JUNO 120 - JUNO 166...
  • Page 51 JUNO 120 G - JUNO 166 G...
  • Page 52 ATTIKA FEUER AG Brunnmatt 16 CH-6330 Cham Switzerland www.attika.ch RAIS A/S Industrivej 20 DK-9900 Frederikshavn Denmark www.rais.dk...
