VESTEL WHITE GOODS
CONSUMER SERVICE
VESTEL REFRIGERATOR
SERVICE MANUAL
VESTELMODEL :
MODEL :
CODE :
RT 260S
RD 26T
( GREECE / CARAD )
10010452
TECHNICAL DEPARTMENT
WHITE GOODS TECHNICAL DOCUMENT : 50024371

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RD 26T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VESTEL RD 26T

Summary of Contents for VESTEL RD 26T

  • Page 1 VESTEL WHITE GOODS CONSUMER SERVICE VESTEL REFRIGERATOR SERVICE MANUAL VESTELMODEL : MODEL : CODE : RT 260S RD 26T ( GREECE / CARAD ) 10010452 TECHNICAL DEPARTMENT WHITE GOODS TECHNICAL DOCUMENT : 50024371...

  • Page 2: Table Of Contents

    CONTENTS PAGE 1. SPECIFICATIONS 2. ASSEMBLE & DISASSEMBLE A - Changing the doorway direction to right hand B - Changing the thermostat C - Thermostat knob 3. REFRIGERANT CYCLE DIAGRAM 4. MACHINE ROOM VIEW 5. CIRCUIT DIAGRAM 6. INTERIOR PARTS 7.

  • Page 3: Specifications

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS SPECIFICATIONS MAIN SPECIFICATIONS RD 26T CLIMATE DOOR COLOUR WHITE DOOR 2 SIDE AVAILABLE DOOR INSULATION CYCLOPENTAN INSULATION CYCLOPENTAN LEVELLING FOOT REFRIGERATOR GASKET WHITE FREEZER GASKET WHITE ELECTRICAL SPECIFICATIONS RD 26T VOLTAGE/FREQUENCY 220-240 V / 50Hz...

  • Page 4: Door Accessory

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS SPECIFICATIONS TEMPERATURE CONTROL MAXIMUM (COLD) RD 26T + 3.5 C - 29 C TEMPERATURE CONTROL MINIMUM (WARM) RD 26T + 3.5 C - 16.7 C DIMENSIONS RD 26T REFRIGERATOR VOLUME GROSS (l) FREEZER VOLUME GROSS (l)

  • Page 5: Assemble & Disassemble

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS ASSEMBLE & DISASSEMBLE A- Changing The Doorway Direction to Right Hand 1- Unscrew the two screws which are fixing the middle hinge and remove two big taps and one small tap. (FIG-1) Unscrew the two hinge screw.
  • Page 6 VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS ASSEMBLE & DISASSEMBLE A- Changing The Doorway Direction to Right Hand 4- Then change the placement of bottom hinge pin as shown below.Unscrew the hinge pin and screw in the next hole. (FIG-4) Figure - 4 5- Place the two big taps and one small tap as shown in the figure.
  • Page 7 VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS ASSEMBLE & DISASSEMBLE A- Changing The Doorway Direction to Right Hand 7- Replace the bushing with the bushing cap on top of refrigerator door. Change the placement of bushing on the bottom of the refrigerator door. (FIG-7) Replace the bushing with the bushing cap on top of freezer door.

  • Page 8: B - Changing The Thermostat

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS ASSEMBLE & DISASSEMBLE Changing the thermostat 1) Take off the lamp cover and unscrew the fixing screw. 2) Take off screw cap and unscrew the fixing screw. 3) Take off the thermostat box by pulling and take off the wire connector.

  • Page 9: Refrigerant Cycle Diagram

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS REFRIGERANT CYCLE DIAGRAM TECHNICAL VESTEL DEPARTMENT WHITE GOODS CONSUMER SERVICE Printed Date : 21 / 12 / 2001 Document No : 50024371...

  • Page 10: Machine Room View

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS MACHINE ROOM VIEW / CIRCUIT DIAGRAM MACHINE ROOM VIEW CIRCUIT DIAGRAM VESTEL TECHNICAL WHITE GOODS CONSUMER SERVICE DEPARTMENT Printed Date : 21 / 12 / 2001 Document No : 50024371...

  • Page 11: Interior Parts

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS INTERIOR PARTS 7 16 29 23 30 31 32 TECHNICAL VESTEL DEPARTMENT WHITE GOODS CONSUMER SERVICE Printed Date : 21 / 12 / 2001 Document No : 50024371...

  • Page 12: Interior Parts List

    DECEMBER 2001 WHITE GOODS INTERIOR PARTS LIST CODE PARTS NAME RD 26T 20041377 ASSY URT CAB/260T 40006464 HEAD PANEL/260V 35004623 TOP HINGE/260V (WITH PIN) D.Ç.3,8 35004624 TOP HINGE/260V (WITHOUT PIN) D.Ç.3,8 35000714 SCREW M5*14 WN 1342-H EJOT 35001817 SCREW 4.2*9.5 WITH WASHER...

  • Page 13: Door Assy. Parts

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS DOOR ASSY. PARTS TECHNICAL VESTEL DEPARTMENT WHITE GOODS CONSUMER SERVICE Printed Date : 21 / 12 / 2001 Document No : 50024371...

  • Page 14: Door Assy. Parts List

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS DOOR ASSY. PARTS LIST CODE PARTS NAME RD 26T 20059509 F DOOR ASSY SRGF/260S 20059543 R DOOR ASSY/260S 40002242 BUSHING/345P 40002243 BUSHING CAP 45002336 LOGO CARAD 40006626 BOTTLE SHELF/140 40006625 EGG SHELF/140 40003910 EGG HOLDER/140 (BLUE)

  • Page 15: Unit Parts

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS UNIT PARTS TECHNICAL VESTEL DEPARTMENT WHITE GOODS CONSUMER SERVICE Printed Date : 21 / 12 / 2001 Document No : 50024371...

  • Page 16: Unit Parts List

    VESTEL REFRIGERATOR VESTEL DECEMBER 2001 WHITE GOODS UNIT PARTS LIST CODE PARTS NAME RD 26T 35002813 MAIN CONDENSER/260T 40002180 SPACER 40003898 PLUG,CABLE HARNESS 35001817 SCREW 4.2*9.5 WITH WASHER 30009529 POWER CORD GR.BPM1111Z/260(50Hz) 30010202 POWER CORD (1.5m) 30009530 OVER LOAD RELAY GR.BPM1111Z(50Hz)260 40006235 CABLE HOLDER PLS/140 35000743 SCREW 4.2*9.5 DIN 7981 YSB...
  • Page 17 REVISION SHORT HISTORY: REV. NO: REV. DATE: PAGE NO: REV. REASON 21.12.2001 First publication DISTRIBUTION : Greece-Carad Date: 28.12.2001 PREPARED BY : Sirma KARAKAYA PRINTED DATE : 21 DECEMBER 2001 APPROVED BY : Filiz KUNURALP DOCUMENT NO : 50024371...
