- Page 1 VESTEL WHITE GOODS CUSTOMER SUPPORT VESTEL REFRIGERATOR SERVICE MANUAL VESTEL CUSTOMER PRODUCT MODEL : MODEL : CUSTOMER : CODE: RN 425S SMP 420.05 FRANCE / VESTEL FRANCE / STARFROST 10600044 SERVICE MANUEL CODE : 52000615...
-
Page 2: Table Of Contents
CONTENTS PAGE 1. ASSEMBLE & DISASSEMBLE * Changing the door swing direction * Changing the freezer door swing direction * Changing the thermostat * Thermostat knob 3. REFRIGERANT CYCLE DIAGRAM 4. COMPRESSOR AREA VIEW 5. CIRCUIT DIAGRAM 6. INTERIOR PARTS 7. - Page 3 (FIG-1) Hinge covers Figure - 1 2- Dismantle the door from bottom hinge by pulling the door upwards. (FIG-2) Figure - 2 CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615...
-
Page 4: Assemble & Disassemble
4- Unscrew the pin of the top hinge. Turn the top hinge by 180 then screw the pin of the top hinge. (FIG-4) Turn the top hinge 180° Figure - 4 CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 5: Document No
( Screw the top hinge to left hand side. ) Fix the hinge covers by replacing the right and left one. Finally, by using a knife cut left side of the kick plate and assemble it. CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004... -
Page 6: Changing The Freezer Door Swing Direction
(Reverse operation of item 1) (FIG-4) Finally, insert the freezer door hinge cover. Freezer Door Holder insert the two small caps Figure - 4 Figure - 3 CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 7: Changing The Thermostat
By turning the knob between “1” and “5”, you can increase or decrease the cooling degree. v The refrigerator is designed to get optimum performance when the thermostat knob is set between position “2” to “4”. CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 8: Refrigerant Cycle Diagram
VESTEL REFRIGERATOR VESTEL APRIL 2004 WHITE GOODS REFRIGERANT CYCLE DIAGRAM CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 9: Compressor Area View
VESTEL REFRIGERATOR VESTEL APRIL WHITE GOODS 2004 COMPRESSOR AREA VIEW & CIRCUIT DIAGRAM COMPRESSOR AREA VIEW CIRCUIT DIAGRAM CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 10: Interior Parts
VESTEL REFRIGERATOR VESTEL APRIL 2004 WHITE GOODS INTERIOR PARTS 23 24 25 26 CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 11: Interior Parts List
40020567 R COMPARTMENT SHELF TRIM/455 (EXT) (ICE WHITE) 47000078 MAGIC SHELF/455 (ICE WHITE) 45001946 CRISPER COVER SRGF/425 (WHIRLPOOL) 40020577 CRISPER COVER TRIM/455 (EXT) (ICE WHITE) 40019101 CRISPER/465 (ICE WHITE) CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 12: Interior Parts List
40018981 THERMOSTAT BOX/345 (ICE WHITE) 30007921 THERMOSTAT (DNFS077B6575,R2070-K59-1) 45000560 HEAT REFLECTOR FOIL 40019016 THERMOSTAT BOX PLUG (ICE WHITE) 30007906 LAMP (E14/220-240V/15W) 30007907 LAMP HOLDER-E14 30014148 WIRING ASSY/THERMOSTAT/425T-340T CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 13: Door Assy. Parts
VESTEL REFRIGERATOR VESTEL APRIL WHITE GOODS 2004 DOOR ASSY. PARTS CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 14: Door Assy. Parts List
40019005 SMALL SHELF SRGF/425 (ICE WHITE) 40007082 EGG HOLDER(I+II)455 (TRANSP-BLUE) 40019007 EGG SHELF SRGF/455 (ICE WHITE) 40018985 BOTTLE HOLDER (ICE WHITE) 40019008 BOTTLE SHELF SRGF/455 (ICE WHITE) CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 15: Unit Parts
VESTEL REFRIGERATOR VESTEL APRIL WHITE GOODS 2004 UNIT PARTS CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... -
Page 16: Unit Parts List
50014044 PACKAGE BAG (1425*2000*0,05)425 0,272 kg. (1) 50019386 STYROFOAM UPPER/455 (CARTOON) 50019384 STYROFOAM BOTTOM/455 (CARTOON) 50019297 STYROFOAM FRONT CORNER/345 (CARTOON) 50019298 STYROFOAM BACK CORNER/345 (CARTOON) CUSTOMER VESTEL WHITE GOODS SUPPORT Printed Date : 24 / 04 / 2004 Document No : 52000615... - Page 17 REVISION SHORT HISTORY: REV. NO: REV. DATE: PAGE NO: REV. REASON 24.04.2004 First publication DISTRIBUTION : France – Vestel France Date: 24.04.2004 PREPARED BY : Poyraz DOGACI PRINTED DATE : 24 APRIL 2004 APPROVED BY : Deniz SPORER DOCUMENT NO : 52000615...
