ACU-RITE 06022RM Instruction Manual

Display for 5-in-1 weather sensor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Package Contents
1. Display unit with tabletop stand
2. Power adapter
3. Instruction Manual
This product requires an AcuRite 5-in-1 Weather Sensor (sold separately) to be
operational.
IMPORTANT
PRODUCT REGISTRATION
Register online
to receive 1 year
warranty protection
www.AcuRite.com
Questions?
(877) 221-1252 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Display for 5-in-1 Weather Sensor
Contact Customer Support at
Instruction Manual
model 06022RM
PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE
►
Register a Product

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 06022RM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ACU-RITE 06022RM

Summary of Contents for ACU-RITE 06022RM

  • Page 1 Instruction Manual Display for 5-in-1 Weather Sensor model 06022RM Package Contents 1. Display unit with tabletop stand 2. Power adapter 3. Instruction Manual This product requires an AcuRite 5-in-1 Weather Sensor (sold separately) to be operational. IMPORTANT PRODUCT MUST BE REGISTERED...
  • Page 2 Features & Benefits Display Unit...
  • Page 3 1. Previous 2 Wind Directions 2. Current Wind Speed Button for setup preferences. 3. Current Wind Direction 18. SET Button 4. Current Indoor Temperature for setup preferences. Arrow icon indicates direction temperature is trending. Button for setup preferences. 5. Display Low Battery Indicator 20.
  • Page 4 BACK OF DISPLAY UNIT 1. Integrated Hang Hole for easy wall mounting. 2. Backlight Button Dimmer control while using power adapter. Activates momentary 6. A-B-C Switch backlight while on battery power. ID code that must match 5-in-1 3. Plug-in for Power Adapter sensor’s A-B-C switch to ensure units synchronize.

  • Page 5: Display Unit Setup

    Display Unit Setup AcuRite recommends high quality alkaline batteries for the best product performance. Heavy duty or rechargeable batteries are not recommended. Set the A-B-C Switch Plug Power Adapter into Electrical Outlet The A-B-C switch is located inside the battery compartment. It can be set to A, B or C.

  • Page 6: Set The Time, Date & Units

    Set the Time, Date & Units Press the “ SE T ” button, located on the front of the display unit, to enter SET MODE. Once in set mode, the preference you are currently setting will blink on the display. To adjust the currently selected (flashing) item, press and release the “...

  • Page 7: Weather Forecast

    OPERATION Placement for Maximum Accuracy AcuRite sensors are sensitive to surrounding environmental conditions. Proper placement of both the display unit and the sensor are critical to the accuracy and performance of this product. Display Unit Placement Place the display unit in a dry area free of dirt and dust. To ensure accurate temperature measurement, place out of direct sunlight and away from heat sources or vents.

  • Page 8: Rainfall Tracking

    Rainfall Tracking This weather station features enhanced tracking of historical rainfall data. Rain accumulation data is recorded for today, over all-time, by year, by month, and by rainfall event. Press the “RAINFALL” button to review rainfall records. The icon is shown on the display while historical data is being viewed.

  • Page 9: Weather Ticker

    Weather Ticker ™ The Weather Ticker automatically flashes your real-time weather information and alerts as text in the lower part of the display unit screen. The possible WEATHER TICKER messages are as follows: HEAT INDEX-XX WINDCHILL-XX DEW POINT-XX IT FEELS LIKE XX OUTSIDE 7 DAY HIGH TEMP. XX- MM/DD 7 DAY LOW TEMP.

  • Page 10: Troubleshooting

    Troubleshooting Problem Possible Solution • Make sure both the display unit and 5-in-1 sensor are placed away from any heat sources or vents (see page 7). Inaccurate • Make sure both units are positioned away from moisture sources (see page 7). temperature or humidity •...

  • Page 11: Care And Maintenance

    Care & Maintenance Display Unit Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. Calibration The indoor / outdoor temperature and humidity readings, and barometric pressure can be calibrated on the display unit to improve accuracy.

  • Page 12: Specifications

    Specifications TEMPERATURE RANGE Outdoor: -40ºF to 158ºF; -40ºC to 70ºC Indoor: 32ºF to 122ºF; 0ºC to 50ºC HUMIDITY RANGE Outdoor: 1% to 99% RH Indoor: 1% to 99% RH WIND SPEED 0 to 99 mph; 0 to 159 kph WIND DIRECTION 16 points INDICATORS RAINFALL...

  • Page 13: Customer Support

    Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 info@chaney-inst.com AcuRite 24/7 support at www. .com Installation Videos Register your Product...
  • Page 16 ©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy- rights are the property of their respective owners. AcuRite uses patented technology. Printed in China 06022RM INST 040215 Visit www.AcuRite.com/patents for details.
