This product requires at least one AcuRite Monitor or Sensor
CONTENTS
Unpacking Instructions ........... 2
Package Contents .................. 2
Product Registration ............... 2
Features & Benefits ................. 3
Display Setup ........................ 7
Placement Guidelines ............. 8
Expand the System................. 9
Questions?
(877) 221-1252 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Weather Station Display
(sold separately) to be operational.
Contact Customer Support at
Instruction Manual
High Resolution
Using the Weather Station .....10
Troubleshooting ....................15
Care & Maintenance .............16
Specifications ........................17
FCC Information ...................17
Customer Support .................18
Warranty..............................18
model 06027
Advertisement
Table of Contents
Related Manuals for ACU-RITE 06027
Summary of Contents for ACU-RITE 06027
-
Page 1: Table Of Contents
Instruction Manual High Resolution Weather Station Display model 06027 This product requires at least one AcuRite Monitor or Sensor (sold separately) to be operational. CONTENTS Unpacking Instructions ... 2 Using the Weather Station ..10 Package Contents ....2 Troubleshooting ....15 Product Registration .... -
Page 2: Unpacking Instructions
Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LED screen prior to using this product. -
Page 3: Features & Benefits
Features & Benefits Weather Overview Dashboard 6. Day Of The Week Alarm ON Indicator Indicates alarm is activated to emit an Date audible alert when conditions exceed 8. Weather Forecast and your presets (see page 10). Current Conditions 2. Indoor Conditions or Self-Calibrating Forecasting pulls data How-to-Dress Character from your sensor to generate your... - Page 4 Features & Benefits Indoor Overview Dashboard indoor ºF indoor comfort: open windows high humidity! it’s mild outside 12:35 TUE 10/25 weather overview indoor overview 1. Humidity Level Indicator 5. Recommendations Indicates a high, low or ideal Indoor comfort recommendations humidity comfort level (see page 14). based on outdoor conditions (see page 14).
- Page 5 Features & Benefits All Locations Dashboard Outdoor Baby’s Room ºF ºF 87º 23% sensor: Display Basement ºF ºF sensor: No Water Detected press for multi-sensor setup 12:35 TUE 10/25 All Locations 1. Wireless Signal Strength 5. Wired Sensor Indicator Signal strength detected for the Indicates a Wired Sensor (sold external Monitor or Sensor (sold separately) is reporting data to the...
- Page 6 Features & Benefits Display DISPLAY BACK 1. Plug-in for Power Adapter Button For setup preferences and cycling 2. Display Stand through messages on the Weather Snaps in for tabletop use. Overview dashboard. 3. Mounting Bracket Button For easy wall mounting. Press to view a different dashboard.
-
Page 7: Display Setup
SETUP Display Setup Install External Monitor or Sensor Batteries BEFORE powering on the display, install batteries for all external Monitors and/or Sensors (sold separately) that you would like to synchronize with the display. A-B-C Channel A-B-C Channel NOTE: If pairing more than one wireless sensor (model 06002 or 06044) with the display, the A-B-C channel must differ between each sensor. -
Page 8: Placement Guidelines
Settings After powering on for the first time, the display will automatically enter setup mode. Follow the on-screen instructions to set up the display. To adjust the currently selected item, press and release the “ ” or “ “ buttons (press and HOLD to fast adjust). To save your adjustments, press and release the “... -
Page 9: Expand The System
Expand the System The display features built-in sensors for measuring temperature and humidity at its location. The display can be expanded to track additional conditions by using compatible Monitors and Sensors (optional; sold separately). Add up to 3 Monitors and Sensors to observe conditions in additional locations within 330 ft (100 m). Compatible Monitors and Sensors are available at: www.AcuRite.com Compatible Monitors Perfect for:... -
Page 10: Using The Weather Station
OPERATION Using the Weather Station Menu Records Monitors Alarms Units Setup Calibrate Display Factory Reset press to exit menu Navigate to the main menu at any time by pressing the “ ” button. From the main menu, you can view records, set alarms, setup additional monitors and more. 1. - Page 11 4. Display Access the “Display” sub-menu to adjust display settings (brightness, contrast, tint), display mode (screen cycle) and backlight (auto dim). When auto dim mode is activated in display setup, the backlight automatically dims the brightness based on the time of day and year. Automatically adjusts display brightness based on time of day &...
- Page 12 Weather Overview Dashboard Weather Forecast AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast of weather conditions for the next 12 to 24 hours by collecting data from a sensor in your backyard. It generates a forecast with pinpoint accuracy - personalized for your exact location.
- Page 13 Messages This display shows real-time weather information and alert messages on the Weather Dashboard. Manually cycle through all available messages by pressing the “ ” or “ “ buttons while viewing the Weather Overview dashboard. Default messages are pre-loaded as follows: BAROMETER Xx.xx AND RISING 30 DAYS HIGH TEMPERATURE RECORDED BAROMETER Xx.xx AND STEADY...
- Page 14 Indoor Overview Dashboard Humidity Level Indicator Indoor humidity is measured by the 0-10% display’s built-in humidity sensor. Humidity is shown with a simple Humidity Level indoor comfort low humidity Meter and text readout on the Indoor Overview dashboard. Recommendations 11-20% indoor comfort The Indoor Overview dashboard provides you with low humidity...
-
Page 15: Troubleshooting
Troubleshooting Problem Possible Solution If the wireless signal indicator shows no bars: • Relocate the display and/or synced Monitor/Sensor (if applicable). The products must be within 330 ft (100 m) of each other. • Make sure products (display, Monitors, Sensors) are placed at least 3 feet (.9 m) away from electronics No reception that may interfere with the wireless communication... -
Page 16: Care & Maintenance
Problem Possible Solution If the Home Environment Display is being used with more than one Temperature & Humidity Sensor (models 06002 or 06044), the A-B-C channels must differ between each sensor. 1. Bring the display and wireless sensors together and position them side-by-side. -
Page 17: Specifications
Specifications DISPLAY’S BUILT-IN 32ºF to 122ºF; 0ºC to 50ºC TEMPERATURE SENSOR RANGE DISPLAY’S BUILT-IN 1% to 99% RH HUMIDITY SENSOR RANGE 433 MHz OPERATING FREQUENCY 5vdc power adapter POWER Display Data: 60 second updates DATA REPORTING FCC Information This device complies with part 15 of FCC rules. Operation is subject to the following two conditions: 1- This device may NOT cause harmful interference, and 2- This device must accept any interference received, including interference that may cause undesired operation. -
Page 18: Customer Support
Customer Support AcuRite customer support is committed to providing you with best-in-class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 AcuRite Visit us at www. .com Installation Videos Register your Product... - Page 20 ©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy- rights are the property of their respective owners. AcuRite uses patented technology. Printed in China 06027 INST 062316 Visit www.AcuRite.com/patents for details.
- Page 21 Instruction Manual Tower Sensor model 06002RM/592TXR Features & Benefits OUTDOOR SENSOR 1. Integrated Hanger For easy placement. 2. Wireless Signal Indicator Weather Temperature Weather Kitchen Clocks Stations & Humidity Alert Radio Thermometers Flashes when data is being sent to the &...
- Page 22 Specifications -40°F to 158°F; -40°C to 70°C Temperature Range: A-B-C Switch 1% – 99% RH (relative humidity) Humidity Range: A B C Battery Requirements: 2 x AA alkaline or lithium batteries Install Batteries 330’ / 100 m depending on home construction materials Wireless Range 2 AA batteries Customer Support...
