To use the Elite Omni-Directional Tabletop Microphone, it should be centered
on the table within 2 to 6 feet (0.6 to 2m) from people speaking and do not need
to be pointing any particular direction as they pick up sound from all
directions.
It is always better to place a microphone as close to meeting participants as
possible, while avoiding placing the microphone where it might be blocked by
equipment or paperwork. Do not place microphones too close to an audio or
video conference speaker to avoid echoes. Make sure that the microphone's
rubber feet are sitting atop a flat surface.
The Elite Directional Wired Tabletop Boundary
Microphones
The Elite Directional Wired Tabletop Boundary Microphone, shown below, is
designed to provide optimum coverage when placed on a conference room table
in front of one to three people.
1. Bottom door latch — replace the bottom cover for permanent installations
using this latch.
2. Audio wire — connect the microphone to the DSP or other audio equipment
using this wire.
2
1
