C C o o n n f f i i g g u u r r a a t t i i o o n n f f r r o o m m V V T T 1 1 0 0 0 0 T T e e r r m m i i n n a a l l M M o o d d e e
By connecting a VT100 compatible terminal or a PC operating in a
terminal emulation mode, a configuration can be performed
through this interface.
To ensure proper communications between the "Disk Array" and
the "Terminal", Please configure the VT100 terminal settings to the
values shown below :
VT100 Terminal ( or compatible ) Set up
Connection
Protocol
Cabling
Baud Rate
Data Bits
Stop Bit
Parity
Keyboard Function Key Definitions
" Enter " key, Use to confirm a selected item
" ESC " key, Use to exit a selection
" A " key, Use to scroll the cursor Upward / Rightward
" Z " key, Use to scroll the cursor Downward / Leftward
" Tab " key, Use to switch mode ( Menu / Output Area )
Serial Port ( COM 1 or COM 2 )
RS232 ( Asynchronous )
Null-Modem cable
115,200
8
1
None
3-7 7
Configuration
