easyRAID F8P U3TT User Manual page 35

L L C C D D S S t t a a t t u u s s P P a a n n e e l l
Located the LCD panel, the LCD status panel informs you of the
Disk Array's current operating status at a glance. Upon activating a
certain function, a symbol or icon corresponding to that function
will appear in the display window. The symbol will remain in the
display window indicating the status of the Disk Array.
I I d d e e n n t t i i f f y y i i n n g g t t h h e e s s t t a a t t u u s s o o n n t t h h e e L L C C D D
The following illustration shows the symbols (characters) been used
and their representation.
A description of each of the symbols in LCD display window :
R Error occur (Fault)
I Identifying Disk Drive
S Spare Disk Drive
X Disk Drive not installed
W Warning: Disk Drive with too many Bad Sectors
A Add new Disk Drive when On-Line Expansion
J JBOD Configuration
1/2/3/4 RAID Group 1/2/3/4
Example of the LCD status display window :
1 1 1 1 1 1 2 2 2 2 2 2 S S X X
RAID1 R5
1 1 2 2 3 3 4 4 5 5
This informs you :
a. HDD 1 ~ HDD 3 : On-line (RAID Group1)
b. HDD 4 ~ HDD 6 : On-line (RAID Group2)
c. HDD 7
d. HDD 8
This informs you :
a. RAID 1 : RAID Group1
b. R5 : RAID Level 5
c. 12345 : HDD No. 1, 2, 3, 4, 5 in RAID1
members
2-1 1 6
Getting Started
: It is a Spare disk drive
: Not installed
