Page 1: Quick Start Guide
Illustra Essentials Indoor / Outdoor HD Bullet Quick Start Guide 8200-1102-01 B0... -
Page 2: Customer Service
The dealer through whom you originally purchased this product is your point of contact if you need service or support. Our dealers are empowered to provide the very best in customer service and support. Dealers should contact Tyco Security Products at (800) 507-6268 or (561) 912-6259 or on the Web at www.illustraessentials.com. -
Page 3: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please note: Do not connect two power supplying sources to the device at the same time;... - Page 4 6. Daily Maintenance Please shut down the device and then unplug the power cable before you begin daily maintenance work. Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens surface.
-
Page 5: Table Of Contents
Table of Contents Important Safeguards and Warnings ........................ii Table of Contents .............................. iv Framework ................................. 1 Cable ................................. 1 Framework and Dimension ........................2 Device Installation .............................. 4 Quick Configuration Tool ........................... 6 Overview ..............................6 Operation ..............................6 Web Operation .............................. -
Page 6: Framework
Framework Cable You can refer to the following figure for cable information. See Figure 1-1 Figure 1-1 Cable Please refer to the following sheet for detailed information. Port Function Connection Note Name Connect to standard Ethernet cable. Ethernet Note: Some devices do not support PoE. Network port port Before making crystal head, pull the anti-dust, waterproof... -
Page 7: Framework And Dimension
Framework and Dimension Please refer to the following figures for dimension information. The unit is mm. See Figure 1-2 Figure 1-4 Figure 1-2... - Page 8 Figure 1-3 Figure 1-4...
-
Page 9: Device Installation
Device Installation Note Before the installation, please make sure the installation environments can at least support 3x weight of the camera. Figure 2-1 Device installation 1 Please see Figure 2-1 and Figure 2-2. Step 1 Stick installation sticker to designated surface where you will install the device (wall or ceiling). Step 2 Dig a hole according to position of hole on installation sticker. -
Page 10: Step
Figure 2-2 Device installation 2 Step 6 Use Philip’s head screw (in accessories bag) to loosen adjusting screw. Step 7 Adjust the device in all possible directions, and set its monitoring direction. Step 8 Use Philip’s head screw to tighten the screws. -
Page 11: Quick Configuration Tool
Quick Configuration Tool Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. Operation Double click the “ConfigTools.exe”... - Page 12 Figure 3-2 Search interface 2 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set. In the configuration tool search interface (Figure 3-1), please select a device IP address and then double click it to open the login interface.
-
Page 13: Web Operation
Web Operation This series network camera products support the Web access and management via PC. Web includes several modules: Monitor channel preview, system configuration, alarm and etc. Network Connection Please follow the steps listed below for network connection. Make sure the network camera has connected to the network properly. ... - Page 14 Figure 4- 2 After you successfully logged in, please install WEB plug-in unit. Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction. See Figure 4- 3. Figure 4- 3...
-
Page 15: Appendix Toxic Or Hazardous Materials Or Elements
Appendix Toxic or Hazardous Materials or Elements Component Name Toxic or Hazardous Materials or Elements Cr VI PBDE ○ ○ ○ ○ ○ ○ Circuit Board Component ○ ○ ○ ○ ○ ○ Device Construction Material ○ ○ ○ ○ ○...
