- Page 1 Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Quick Start Guide 8200-1135-02 A0...
- Page 2 Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Copyright Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form, in whole or in part, without prior written consent of Tyco Security Products.
-
Page 3: Table Of Contents
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Contents What’s in the box? ........................... 4 Indoor Camera ............................. 4 Outdoor Camera ..........................4 Indoor and Outdoor Camera Installation ..................... 4 Preparing the Camera for Installation ....................5 Remove camera from the box ......................5 Use the template to prepare the mounting area .................. -
Page 4: What's In The Box
*Not supplied with LT camera models. Indoor and Outdoor Camera Installation This installation guide includes information for installing both the indoor and outdoor variants of the Illustra Pro Series Mini Dome camera. Refer to the procedure relevant to your installation. -
Page 5: Preparing The Camera For Installation
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 2. Preparing the Camera for Installation Enclosure Base Assembly Camera Assembly Camera Liner Bubble Assembly Figure 1 Remove camera from the box Take care when removing the camera from the box. -
Page 6: Use The Template To Prepare The Mounting Area
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Use the template to prepare the mounting area Select the type of mounting required from the procedures below. Flush Mount Using Screws 1. Create a circular opening in the mounting surface with a diameter of 120 mm (4.7”) with tolerances of -0/+5 mm (-0/.0.2”). -
Page 7: Connect The Cables And Make Adjustments
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 3. Connect the cables and make adjustments PoE Network *Alarm in-1 *Alarm Out Port AC Power *Audio Out *Alarm in-2 *Audio IN *Not available on LT camera models Figure 3 ... - Page 8 Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Phone Home (Future Enhancement) Analog Video Out Reset/Defaults NTSC Future Enhancement IR (On/Off) micro SD Card slot (not visible in this image) Note: micro SD Card is not available on LT...
-
Page 9: Mount The Camera Enclosure
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 4. Mount the Camera Enclosure Select the type of mounting required and refer to the relevant procedure: Flush Mount Using Screws (Indoor) Surface Mount (Indoor) Surface Mount (Outdoor) ... -
Page 10: Flush Mount Using Locking Arms (Indoor)
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Flush Mount using Locking Arms (Indoor) 1. Turn the screws clockwise to extend the locking arms as seen in Figure 5. Figure 5 2. Tighten the screws sufficiently to compress the arms to adjust to the mounting surface. -
Page 11: Surface Mount (Outdoor)
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 7. Finally, insert the screw hole covers to cover three screws in the bubble assembly. Surface Mount (Outdoor) 1. Pierce a small hole through the base seal of the enclosure base assembly at the corresponding screw hole to allow the screw to be inserted. -
Page 12: Mount Using A Junction Box (Indoor)
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Mount Using a Junction Box (Indoor) 1. Tie your wiring into a junction box and feed the wires through the top conduit hole on the enclosure base assembly. 2. Tighten the screws to secure the enclosure base assembly to the junction box. Then connect the wiring. -
Page 13: Mount Using The Pendant Cap (Outdoor)
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series Mount using the Pendant Cap (Outdoor) If mounting the camera using the pendant cap you must ensure that the cable seal connector is used and that the wires are shaped as in the image below. This will allow any moisture that may gather to run off without entering the enclosure base assembly. - Page 14 Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 6. Secure the enclosure base assembly to the pendant cap. Tighten the screws to secure the enclosure base assembly to the pendant cap. Then connect the wiring. NOTE: When attaching the enclosure base assembly to the pendant cap take care to avoid nipping the cables.
-
Page 15: Network Connection
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 5. Network Connection Connect to a PC directly: Directly connect the camera to a PC using a standard Ethernet cable. Connecting Camera(s) to a Local Area Network (LAN): To add the camera(s) to an existing LAN, just connect the camera(s) to the hub or switch on your network. -
Page 16: Installation Using The Static Ip Address
Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 3. Select the camera you wish to configure, locating it by its unique MAC address. Illustra Connect allows basic configuration of the camera. Refer to the Illustra Connect manual for more information. - Page 17 Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series 3. Select the Picture Basic tab from the Basic Configuration menu. 4. Select the required Orientation setting: Mirror Flip 5. The video pane will update to display the new settings.
