Your Jet 2 has two main assemblies: the seat and the power base. See figures 3 and 4. Typically, the seating
assembly includes the armrests, seatback, and a joystick/controller. Your Jet 2 seat may also have some
optional accessories attached to it, such as a basket, a cane/crutch holder, or a cup holder. See XI. “Options and
Accessories.”
The power base assembly is the heart of your Jet 2. The power base assembly includes two drive wheels, two anti-
tip wheels, two rear caster wheels, a body shroud, and footrest.
SEAT
ASSEMBLY
POWER BASE
ASSEMBLY
REAR CASTER WHEEL
16
I V .
Y O U R
SEATBACK
Figure 3. The Jet 2
www.pridemobility.com
J E T
ARMRESTS
JOYSTICK
DRIVE WHEEL
2
CONTROLLER
BODY SHROUD
MANUAL FREEWHEEL
LEVERS
FOOTREST
ANTI-TIP WHEELS
Jet 2/Rev F/Feb03
