Premio Apollo User Manual

Hide thumbs Also See for Apollo:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Apollo/Shadowhawk
u s e r
m a n u a l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Apollo and is the answer not in the manual?

Questions and answers

Related Manuals for Premio Apollo

Summary of Contents for Premio Apollo

  • Page 1 Apollo/Shadowhawk u s e r m a n u a l...
  • Page 2 System Manual...
  • Page 3 PREMIO System Manual Copyright is a registered trademark of Premio Computer, Inc. All PREMIO other brands and product names are trademarks or registered trademarks of their respective companies. © 1997 by Premio Computer, Inc. All rights reserved. Printed in Taiwan.

  • Page 4: Table Of Contents

    Contents GETTING STARTED ..............1 Setting Up ................2 Switches and Indicators..........3 UPGRADING ................5 Opening the System Unit ..........6 Installing an Expansion Card ........7 Installing Memory ............8 Installing a SIMM ..............8 Removing a SIMM..............9 Installing a DIMM ..............9 Removing a DIMM .............10 Installing a Hard Drive..........11 GETTING HELP................12 Troubleshooting ............12...
  • Page 5 PREMIO System Manual Warranty Service............15 Technical Support............15 PREMIO on the Internet..........15 APPENDIX ................16 Limited 3-Year Warranty..........16 FCC Standards ............. 18 Important Safety Instructions ........19...

  • Page 6: Getting Started

    Getting Started ® Your system consists of three components: PREMIO a mid-tower or desktop system unit a keyboard a mouse Add your choice of monitor, and your system is ready to use. System Unit Mid-tower system Keyboard Mouse Desktop system...

  • Page 7: Setting Up

    PREMIO System Manual Setting Up To set up your system, simply connect your monitor, PREMIO the mouse, the keyboard, and any additional components you want to use to the system unit. Follow these easy steps: Attach your monitor’s video cable Power Connector to the video connector.

  • Page 8: Switches And Indicators

    Switches and Indicators Switches and Indicators The system unit’s front panel provides access to the CD-ROM and floppy drives, and to the system’s switches and indicator lights. The illustration below shows a mid-tower system. If you have a desktop system, turn to the illustration on the next page. The CD-ROM drive reads information on CDs.
  • Page 9 PREMIO System Manual Desktop system Reset Button Power Switch Hard Drive Indicator CD ROM Drive Power Indicator Floppy Drive The reset button restarts the system. The hard drive indicator lights when the hard drive is in use. The power indicator lights when the system is on.

  • Page 10: Upgrading

    Upgrading You can upgrade your system with: PREMIO Expansion cards More memory An additional hard drive To install an upgrade, you must open the system unit. Before proceeding, read the important cautionary note below. Then follow the steps on the next page.

  • Page 11: Opening The System Unit

    PREMIO System Manual Opening the System Unit Note Opening the system unit could affect your warranty. Check with the dealer where you purchased your system before opening the system unit. To open the system unit, follow these steps Mid-tower system Turn off the system and unplug the power cord.

  • Page 12: Installing An Expansion Card

    Installing an Expansion Card Installing an Expansion Card To install an expansion card, open the system unit as described on the previous page. Then follow these steps: Remove the screw securing the slot bracket cover for the expansion slot you want to use.

  • Page 13: Installing Memory

    PREMIO System Manual Installing Memory Note For details on memory configuration, including the placement and type of memory to use in your system, refer to the motherboard user’s manual that came with your system. Follow these general guidelines when adding memory: Use only the same type of memory throughout.

  • Page 14: Removing A Simm

    Installing Memory Removing a SIMM To remove a SIMM, follow these steps: Press the holding clips on both sides of the SIMM outward to release it. Tilt the SIMM to a 45° angle. Pull the SIMM up and out of the socket. Installing a DIMM To install a DIMM, follow these steps: Insert the DIMM vertically into the...

  • Page 15: Removing A Dimm

    PREMIO System Manual Removing a DIMM To remove a DIMM, follow these steps: Push down and out on the plastic clips at either end to release them. Pull the DIMM up and out of the socket.

  • Page 16: Installing A Hard Drive

    Installing a Hard Drive Installing a Hard Drive To install a hard drive in your system, follow these steps: Mid-tower system Desktop system Disconnect the hard drive cable and power connector. Remove the two screws securing the drive bay. Slide the bay toward the rear of the system unit to remove it.

  • Page 17: Getting Help

    Getting Help Troubleshooting Your system is designed to provide years of trouble- PREMIO free performance. If you have a problem with your system, first check the information in this section for a quick solution. Monitor Does Not Work If your monitor appears not to be working properly: Check that the monitor’s power cable is securely attached...

  • Page 18: Keyboard Does Not Work

    Troubleshooting Keyboard Does Not Work If the NumLock indicator in the upper right corner of the keyboard does not light when the system powers up, or the keyboard does not work: Check that the keyboard cable is securely attached to the system unit’s keyboard connector.

  • Page 19: System Unit Problems

    PREMIO System Manual System Unit Problems The fan inside the system unit should make a low, steady sound when operating properly. If the fan is totally silent: Check that the system power cord is securely attached to the back of the system unit and to a power outlet. Verify that the outlet has power.

  • Page 20: Warranty Service

    Premio Computer, Inc. 918 Radecki Court City of Industry, CA 91748 Telephone: 800-568-6388 Fax: 626-839-3191 Email: support@premiopc.com PREMIO on the Internet maintains a web page on the Internet with the latest PREMIO information on products, updated drivers, answers to PREMIO common problems, a Windows 95 troubleshooting guide, and more.

  • Page 21: Appendix

    (hereinafter “Product”) to be free from defects in material and workmanship for a period of three (3) years from the date of original purchase from Premio Computer, Inc. or a Premio Computer, Inc. authorized reseller. This warranty does not cover monitor and LCD panels, nor third-party hardware and software which has a separate manufacturer’s warranty.
  • Page 22 PREMIO COMPUTER, INC.'S SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT AS STATED ABOVE. IN NO EVENT WILL PREMIO COMPUTER, INC. BE LIABLE TO THE CUSTOMER OR ANY THIRD PARTY FOR ANY DAMEAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT.

  • Page 23: Fcc Standards

    FCC Standards The FCC (Federal Communications Commission) restricts the amount of radiation and radio frequency emissions from computing equipment. This equipment generates and uses radio frequency energy and if not installed and used properly in strict accordance with the operation instructions, reference manuals, and the service manual, may cause interference to radio or television reception.

  • Page 24: Important Safety Instructions

    Important Safety Instructions Important Safety Instructions These instructions are provided by Underwriters Laboratories, Inc. Read all of these instructions and save them for later reference. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol cleaners.
  • Page 25 12. Except as explained elsewhere in this manual, don't attempt to service this product yourself. Opening and removing those covers that are marked “Do Not Remove” may expose you to dangerous voltage points or other risks. Refer all servicing on those compartments to service personnel.
  • Page 26 FCC Compliance Statement: This equipment has been tested and found to DECLARATION OF CONFORMITY Per FCC Part 2 Section 2. 1077(a) comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These Responsible Party Name: G.B.T. INC. limits are designed to provide reasonable Address: 18305 Valley Blvd., Suite#A LA Puent, CA 91744...

  • Page 27: Declaration Of Conformity

    Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH Ausschlager Weg 41, 1F, 20537 Hamburg, Germany declare that the product ( description of the apparatus, system, installation to which it refers) Mother Board GA-7ZX-H is in conformity with (reference to the specification under which conformity is declared) in accordance with 89/336 EEC-EMC Directive EN 55011...
  • Page 28 7ZX-H AMD Athlon /Duron Socket A Processor Motherboard USER'S MANUAL AMD Athlon /Duron Socket A Processor Motherboard REV. 5.1 First Edition R-51-01-010419...
  • Page 30 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History Manual revision information 2) Item Checklist Product item list 3) Features Product information & specification 4) Hardware Setup Instructions on setting up the motherboard 5) Performance &...
  • Page 32 Table Of Content Revision History Item Checklist Summary of Features 7ZX-H Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List P.22 Block Diagram P.23 Suspend to RAM Installation P.24 Dual BIOS Introduction (Optional) P.30 @BIOS Introduction...

  • Page 33: Revision History

    7ZX-H Motherboard Revision History Revision Revision Note Date Initial release of the 7ZX-H motherboard user’s Apr. 2001 manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.

  • Page 34: Item Checklist

    Item Checklist Item Checklist The 7ZX-H motherboard Cable for IDE / floppy device CD (TUCD) for motherboard driver & utility 7ZX-H user’s manual...

  • Page 35: Summary Of Features

    /Duron (K7) Socket A Processor 256K/64K L2 cache on die Supports 600MHz ~ 1GHz and faster Support 100/133MHz FSB Chipset Apollo KT133A, consisting of: VT8363A Memory/AGP/PCI Controller (PAC) VT82C686B PCI Super-I/O Integrated Peripheral Controller (PSIPC) Clock Generator ICW W230H ICW W230H...
  • Page 36 Summary of Features PS/2 Connector   PS/2 Keyboard interface and PS/2 Mouse interface On-Board Sound AC’97 CODEC Line In/Line Out/Mic In/AUX In/CD In/TEL/Game Port BIOS Licensed AMI BIOS, 2M bit flash ROM Support Dual BIOS (Optional) Additional Features Support Wake-On-LAN (WOL) Support Internal / External Modem Ring On Support USB KB/MS Wake up from S3-S5 Includes 3 fan power connectors...

  • Page 37: 7Zx-H Motherboard Layout

    7ZX-H Motherboard 7ZX-H Motherboard Layout PS/2 Socket A CPU LED1 JP21 VT8363A 7ZX-H AGP 1 Clock PCI1 Generator BAT1 PCI2 VT82C 686B PCI3 PCI4 PCI5 MAIN BACK Up USB2 BIOS BIOS JP16 JP17 JP18 ISA 1...

  • Page 38: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    7ZX-H Motherboard Layout Page Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors Game & Audio Port COM A / COM B / LPT Port USB 1 Connector USB 2 Connector PS/2 Keyboard & PS/2 Mouse Connector P.10 J3 (CPU Fan) P.10...

  • Page 39: Definition

    7ZX-H Motherboard CPU Speed Setup The system bus speed is selectable at 100~133MHz. The user can select the system bus speed by DIP switch SW1 & JP21. Set System Bus Speed SW1: O: ON / X: OFF JP21: CPU Clock Frequency (Optional) JP21 100MHz 133MHz...

  • Page 40: Connectors

    Connectors Connectors Game & Audio Port Game Port Line Out 1 MIC In Line In COM A / COM B / LPT Port LPT Port COM A COM B...

  • Page 41: Usb 1 Connector

    7ZX-H Motherboard USB 1 Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 5 6 7 8 USB D1- USB D1+ USB 2 Connector Pin No. Definition USB D2- USB D2+ USB D3+ USB D3-...

  • Page 42: Ps/2 Keyboard & Ps/2 Mouse Connector

    Connectors PS/2 Keyboard & PS/2 Mouse Connector PS/2 PS/2 Mouse Mouse/Keyboard Pin No. Definition Data VCC(+5V) Clock PS/2 Keyboard J3: CPU Fan Pin No. Definition Control +12V SENSE...

  • Page 43: Jp6: Power Fan

    7ZX-H Motherboard JP6: Power Fan Pin No. Definition Control +12V J2: Sysem Fan Pin No. Definition Control +12V SENSE...

  • Page 44: Atx Power

    Connectors ATX Power Pin No. Definition 3,5,7,13, 15-17 1,2,11 3.3V 4,6,19,20 +12V -12V Power Good 5V SB (stand by+5V) PS-ON (Soft On/Off) Floppy Port Red Line FDD1...

  • Page 45: Ide1 (Primary), Ide2 (Secondary) Port

    7ZX-H Motherboard IDE1 (Primary), IDE2 (Secondary) Port Red Line IDE 1 IDE 2 J16 TEL: The connector is for Modem with internal voice connector Pin No. Definition Signal-In Signal-Out...

  • Page 46: J15: Aux_In

    Connectors J15: AUX_IN Pin No. Definition AUX-L AUX-R J18: CD Audio Line In Pin No. Definition CD-L CD-R...

  • Page 47: J13 (Ring Power On)

    7ZX-H Motherboard J13: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition Signal J12: Wake On LAN Pin No. Definition +5V SB Signal...

  • Page 48: Jp8 / Led1: Str Led Connector & Dimm Led

    Connectors JP8 / LED1: STR LED Connector & DIMM LED STR LED Connector External. DIMM LED J4: IR Pin No. Definition VCC (+5V) IR Data Input IR Data Output...

  • Page 49: Panel And Jumper Definition

    7ZX-H Motherboard Panel And Jumper Definition J11: 2x11 Pins Jumper S P K P−P−P+ GN (Green Switch) Open: Normal Operation Close: Entering Green Mode GD (Green LED) Pin 1: LED anode(+) Pin 2: LED cathode(−) HD (IDE Hard Disk Active LED) Pin 1: LED anode(+) Pin 2: LED cathode(−) SPK (Speaker Connector)

  • Page 50: Jp4: Rear Usb Device Wake Up Selection

    Panel and Jumper Definition JP16 /JP17/JP18: AMR (Primary or Secondary) Select (Optional) (AMR Audio Modem Riser) JP17 JP16 JP18 JP16 JP17 JP18 Onboard AC97 AMR (Primary) Onboard AC97+MR (Secondary) (Default) JP4: Rear USB Device Wake up Selection (USB Connector USB1) Pin No.

  • Page 51: Jp7: Str Function Enable

    7ZX-H Motherboard JP7: STR Function Enable Pin No. Definition Open Normal (Default) Close STR Enabled JP11: Front USB Device Wake up Selection (USB Port USB2) USB2 Pin No. Definition 1-2 close Normal (Default) Enabled Front USB Device 2-3 close Wake up (If you want to use "USB Dev Wakeup From S3-S5"...

  • Page 52: Jp10 (Bios Write Protection)[Optional]

    Panel and Jumper Definition JP10: BIOS Write Protection (Optional) Pin No. Definition Write Protect Enable Write Protect Disable (Default) Please Set Jumper JP10 to ”OFF” to enabled BIOS Write Function when you update new BIOS or new device JP3: Clear CMOS Function (Optional) Pin No.

  • Page 53: Bat1: Battery

    7ZX-H Motherboard BAT1: Battery CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

  • Page 54: Performance List

    Performance List Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) •...

  • Page 55: Block Diagram

    7ZX-H Motherboard Block Diagram CPUCLK Socket A 2X/4X System Bus VT8363A 3.3V SDRAM 100 / 133MHz 66MHz 100 / 133MHz 100 / 133MHz 66MHz 33MHz ICW W230H 33MHz 5 PCI ATA66/ATA100 IDE Channels 33MHz 14.318MHz 4 USB Ports 48MHz VT82C Game Port 686B COM Ports...

  • Page 56: Suspend To Ram Installation

    Suspend to RAM Installation Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 57 7ZX-H Motherboard Step 2: (If you want to use STR Function, please set jumper JP7 Closed.) Pin No. Definition Open Normal (Default) Close STR Enabled Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter ACPI Sleep BIOS Setup.
  • Page 58 Suspend to RAM Installation A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B.
  • Page 59 7ZX-H Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 60 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. D. Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 61 7ZX-H Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your SDRAM must be PC-100/PC-133 compliant. Jumper JP8 is provided to connect to the STR LED in your system chassis.

  • Page 62: Dual Bios Introduction (Optional)

    Dual BIOS Introduction Dual BIOS Introduction (Optional) What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS.
  • Page 63 7ZX-H Motherboard b. AMI Dual BIOS Flash ROM Programming Utility AMI Dual BIOS Flash ROM Programming Utility Boot From……………………….. Main BIOS Main ROM Type………………… SST 39SF020 Backup ROM Type……………… SST 39SF020 Wide Range Protection Disable Boot From Main BIOS Auto Recovery Enable Halt On Error Disable...
  • Page 64 Dual BIOS Introduction Boot From : Main BIOS (Default), Backup BIOS Status 1: The user can set to boot from main BIOS or Backup BIOS. Auto Recovery : Enable(Default), Disable When one of the Main BIOS or Backup BIOS occurs checksum failure, the working BIOS will automatically recover the BIOS of checksum failure.
  • Page 65 7ZX-H Motherboard DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newness “Value-added” feature, in a long series of innovations from GIGABYTE, is available on GA-7ZX-H motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 66 Dual BIOS Introduction I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS technology simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 67 7ZX-H Motherboard III. Q: How does DualBIOS technology work? Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment.
  • Page 68 Dual BIOS Introduction 2. During or after a BIOS upgrade, if DualBIOS detects that the main BIOS is corrupt, the backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS technology examines the checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.

  • Page 69: Bios Tm Introduction

    7ZX-H Motherboard @BIOS™ Introduction Gigabyte announces @BIOS™ Windows BIOS live update utility Have you ever updated BIOS by yourself? Or like many other people, you just know what BIOS is, but always hesitate to update it? Because you think updating newest BIOS is unnecessary and actually you don’t know how to update it.

  • Page 70: Easytuneiii Tm Introduction

    EasyTune III Introduction EasyTuneIII™ Introduction Gigabyte announces EasyTuneIII™ Windows overdrive utility “Overdrive” might be one of the most common issues in computer field. But have many users ever tried it? The answer is probably “no”. Because “overdrive” is thought to be very difficult and includes a lot of technical know-how, sometimes “overdrive”...
  • Page 71 7ZX-H Motherboard This wonderful software is now free bundled in Gigabyte motherboard attached ™ driver CD. Users may make a test drive of “EasyTuneIII ” to find out more amazing features by themselves. For further technical information, please link to: http://www.gigabyte.com.tw Note: For the latest version of EasyTuneIII , please visit our website.

  • Page 72: Memory Installation

    Memory Installation Memory Installation The motherboard has 3 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.

  • Page 73: Page Index For Bios Setup

    7ZX-H Motherboard Page Index for BIOS Setup Page The Main Menu P.43 Standard CMOS Setup P.45 BIOS Features Setup P.48 Chipset Features Setup P.50 Power Management Setup P.54 PNP/ PCI Configuration P.57 Load BIOS Defaults P.60 Load Setup Defaults P.61 Integrated Peripherals P.62 Hardware Monitor &...

  • Page 74: Entering Setup

    BIOS Setup BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...

  • Page 75: The Main Menu

    7ZX-H Motherboard GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 76 BIOS Setup • • • • Chipset Features Setup This setup page includes all the items of chipset special features. • • • • Power Management Setup This setup page includes all the items of Green function features. • • • • PNP/PCI Configurations This setup page includes all the configurations of PCI &...

  • Page 77: Standard Cmos Setup

    7ZX-H Motherboard Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 78 BIOS Setup • • • • Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. • • • • Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 79 7ZX-H Motherboard • • • • Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.

  • Page 80: Bios Features Setup

    BIOS Setup BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device Floppy 2nd Boot Device IDE-0 3rd Boot Device CDROM S.M.A.R.T. for Hard Disks Disabled BootUp Num-Lock Floppy Drive Seek Enabled Password Check...
  • Page 81 7ZX-H Motherboard • • • • S.M.A.R.T. for Hard Disks Enabled Enable S.M.A.R.T. Hard for Disks. Disabled Disable S.M.A.R.T. Hard for Disks. (Default Value) • • • • Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. •...

  • Page 82: Chipset Features Setup

    BIOS Setup Chipset Features Setup AMIBIOS SETUP – CHIPSET FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved *********DRAM Timing*** SDRAM Command Drive 24 mA Top Performance Disabled Memory Address Drive 24 mA DRAM Frequency 100MHz CAS# Drive 12 mA SDRAM CAS# Latency RAS# Drive...
  • Page 83 7ZX-H Motherboard • • • • AGP Fast Write Enabled Enable this function only if the AGP Card support Fast Write Function. (Enable this function can increase AGP performance). Disabled Disable this function. (Default Value) • • • • AGP Mode Set AGP Mode to 4X.
  • Page 84 BIOS Setup • • • • USB Legacy Support Keyboard/FDD Set USB Legacy Support Keyboard / Floppy. KB/Mouse/FDD Set USB Legacy Support Keyboard / Mouse /Floppy. Disabled Disable USB Legacy Support Function . (Default Value) • • • • USB Port 64/60 Emulation Enabled To use USB mouse under Win NT environment, set USB Legacy Support to KB/Mouse/FDD and USB Port 64/60 Emulation to...
  • Page 85 7ZX-H Motherboard • • • • SDRAM Command Drive 16 mA Set SDRAM Command Drive 16 mA. 24 mA Set SDRAM Command Drive 24 mA. (Default Value) • • • • Memory Address Drive 16 mA Set Memory Address Drive 16 mA. 24 mA Set Memory Address Drive 24 mA.

  • Page 86: Power Management Setup

    BIOS Setup Power Management Setup AMIBIOS SETUP – POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type S1/POS RTC Alarm Date Every Day USB Dev Wakeup from S3-S5 Disabled RTC Alarm Hour Suspend Time Out(Minute) Disabled RTC Alarm Minute Display Activity...
  • Page 87 7ZX-H Motherboard Enable Suspend Time Out after 50min. Enable Suspend Time Out after 60min. • • • • Display Activity Ignore Ignore Display Activity. (Default Value) Monitor Monitor Display Activity. • • • • IRQ 3~IRQ15 Ignore Ignore IRQ3 ~IRQ15. Monitor Monitor IRQ3~IRQ15.
  • Page 88 BIOS Setup • • • • Resume On RTC Alarm You can set “Resume On RTC Alarm” item to enabled and key in Data/time to power on system. Disabled Disable this function. (Default Value) Enabled Enable alarm function to POWER ON system. If the “Resume On RTC Alarm”...

  • Page 89: Pnp/Pci Configurations

    7ZX-H Motherboard PNP/PCI Configurations AMIBIOS SETUP – PNP / PCI CONFIGURATION ( C ) 1999 American Megatrends, Inc. All Rights Reserved PnP OS Installed Reset Configuration Data VGA Boot from PCI AGP Palette Snoop Disabled Auto PCI Slot 1/5 IRQ Priority Auto PCI Slot 2 IRQ Priority PCI Slot 3 IRQ Priority...
  • Page 90 BIOS Setup • PCI Slot 1,5 IRQ Priority Auto The system will reserved a free IRQ for PCI slot 1 & 5 device. (Default Value) The system will reserved IRQ3 for PCI slot 1 & 5 device if no legacy ISA device using IRQ3.
  • Page 91 7ZX-H Motherboard • • • • IRQ (3, 4, 5, 7, 9, 10, 11, 14, 15) ISA/ EISA The resource is used by Legacy ISA device. PCI / PnP The resource is used by PCI/ PnP device.

  • Page 92: Pnp/Pci Configuration

    BIOS Setup Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION...

  • Page 93: Load Setup Defaults

    7ZX-H Motherboard Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD Load SETUP Defaults (Y/N)? N PNP/PCI CONFIGURATION...

  • Page 94: Integrated Peripherals

    BIOS Setup Integrated Peripherals AMIBIOS SETUP – INTEGRATED PERIPHERALS ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard IDE Both OnBoard Serial Port A Auto OnBoard Serial Port B Auto Normal Serial PortB Mode Duplex Mode OnBoard Parallel Port Auto Parallel Port Mode Parallel Port DMA...
  • Page 95 7ZX-H Motherboard • OnBoard Serial Port B Auto BIOS will automatically setup the port B address. (Default Value) 3F8/COM1 Enable OnBoard Serial port B and address to 3F8. 2F8/COM2 Enable OnBoard Serial port B and address to 2F8. 3E8/COM3 Enable OnBoard Serial port B and address to 3E8. 2E8/COM4 Enable OnBoard Serial port B and address to 2E8.
  • Page 96 BIOS Setup • • • • Parallel Port IRQ Set Parallel Port IRQ to 7. Auto Set Auto to parallel Port IRQ DMA Channel. (Default Value) Set Parallel Port IRQ to 5. • • • • AC97 Audio Auto BIOS will search AC97 Codec. If found, AC97 function will be enabled. If no AC97 Codec found, AC97 function will be disabled.
  • Page 97 7ZX-H Motherboard • • • • MPU-401 Enabled Enable MPU-401. Disabled Disable MPU-401. (Default Value) Ps. When Force Feedback joystick is used, MPU-401 needs to be Enable. • • • • MPU-401 I/O Address 330h-333h Set MPU-401 I/O Address to 330h-333h. (Default Value) 300h-303h Set MPU-401 I/O Address to 300h-303h.

  • Page 98: Hardware Monitor & Misc Setup

    BIOS Setup Hardware Monitor & MISC Setup AMIBIOS SETUP – HARDWARE MONITOR & MISC SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Shut Down Temp. Disabled CPU Temperature 32°C/89°F System Temperature 32°C/89°F CPU Fan Speed 7123 RPM System Fan Speed 0 RPM Vcore...
  • Page 99 7ZX-H Motherboard • • • • CPU Fan Speed Detect CPU Fan speed status automatically. • • • • System Fan Speed Detect System Fan speed status automatically. • • • • Voltage (V) Vcore / Vdd / Vcc3 / +5V / +12V Detect system’s voltage status automatically.

  • Page 100: Set Supervisor / User Password

    BIOS Setup Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP...

  • Page 101: Ide Hdd Auto Detection

    7ZX-H Motherboard IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Fri Mar 9, 2001 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave : Not Installed...

  • Page 102: Save & Exit Setup

    BIOS Setup Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION...

  • Page 103: Exit Without Saving

    7ZX-H Motherboard Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24b ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP HARDWARE MONITOR & MISC SETUP CHIPSET FEATURES SETUP SUPERVISOR PASSWORD POWER MANAGEMENT SETUP USER PASSWORD PNP/PCI CONFIGURATION IDE HDD AUTO DETECTION...

  • Page 104: Appendix

    Appendix Appendix Appendix A: VIA KT133/KM133 Chipsets Driver Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 2.Click “Next”. 1.Click “VIA 4in 1 Service Pack Driver”...
  • Page 105 7ZX-H Motherboard 8.Click “Next”. 7.Click “Next”. 9.Click “Finish” to restart computer. (10)
  • Page 106 Appendix Appendix B: VIA AC’97 Audio Driver Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen . Press “Audio” icon. 1.Click “VIA AC’97 Audio Driver”. 2.Click “Next”.
  • Page 107 7ZX-H Motherboard Appendix C: EasyTuneIII Utilities Installation Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen . Press “Tools” icon. 2.Click “EasyTuneIII Ver.3.2f”. 1.Click “Gigabyte Utilities”.
  • Page 108 Appendix 7. Click “Finish” to restart computer.
  • Page 109 7ZX-H Motherboard Appendix D: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Program to flash BIOS. Press “Tools” icon. 2.Click “@BIOS Writer v1.06f”. 1.Click “Gigabyte Utilities”. Click Here. Click “ ”. Methods and steps: I.
  • Page 110 Appendix II. Update BIOS through Internet: Do not click "Internet Update" icon b. Click "Update New BIOS" c. Please select "All Files" in dialog box while opening the old file. d. Please search for BIOS unzip file, downloading from internet or any other methods (such as: 7ZX-H.F1).
  • Page 111 7ZX-H Motherboard Or else you can select flash BIOS in DOS mode. Please check your BIOS vendor (AMI or AWARD), your motherboard name and PCB version on the motherboard. Format a bootable system floppy diskette by the command “format a:/s” in command mode.
  • Page 112 Appendix Appendix E: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communications Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access Desktop Management Interface...
  • Page 113 7ZX-H Motherboard Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID...
