USER'S
MANUAL
RCO-1000-J1900 Series
Compact Fanless Embedded System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCO-1000-J1900 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Premio RCO-1000-J1900 Series

Summary of Contents for Premio RCO-1000-J1900 Series

  • Page 1 USER’S MANUAL RCO-1000-J1900 Series Compact Fanless Embedded System...
  • Page 2 RCO-1000-J1900 | User’s Manual Please note, the RCO-1000 is now referred to as "RCO-1000-J1900" due to a model name change. All product features and functionality remain the same. If any questions, please contact us for more information. Name Change Guide: LEGACY Model Name NEW Model Name RCO-1000...

  • Page 3: Table Of Contents

    RCO-1000-J1900 | User’s Manual Table of Contents Prefaces …………………………………………………….……………………………………………. 04 Revision …………………………………………………………………………………………..……………….………..04 Disclaimer ………………………………………………………..…….…….………………………….………………..04 Copyright Notice …………………………………….…………………….…………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….……………….. 04 Safety Precautions ………………………………………….……………………………….…………….…………..05 Technical Support and Assistance …………………………………….…………….…………….…………….06 Conventions Used in this Manual ………………………………………………………………….….………..06 Package Contents …………………………………………………………………………………………….…………07 Ordering Information …………………………………….……………………………………….……….…………...
  • Page 4 RCO-1000-J1900 | User’s Manual 3.12 Installing wall mount kit …………………….…………..….…………………..………….…..50 3.13 Installing VESA mount kit …….…………..….…..….………………………………………….. 51 3.14 Installing side mount kit …….…………..….…….….………………………………………….. 53 3.15 Installing DIN rail holder …….…………..….…..…...…………………………………………..55 Chapter 4 BIOS Setup …………………………………………………………………………… 56 BIOS Introduction …….……….……………………………………..….…….…..….…………...57 Main Setup ……..……….………………….…………………………..…….….………………..58 4.2.1 System Date …….……………………………………………..……..……………………..58 4.2.2 System Time ………..…………………………………………..……….…………………...

  • Page 5: Prefaces

    The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc. We disclaim all warranties, express or implied, including, without limitation, those of merchantability, fitness for a particular purpose with respect to contents of this User’s Manual.

  • Page 6: Safety Precautions

    Preface RCO-1000-J1900 | User’s Manual Safety Precautions Before installing and using the equipment, please read the following precautions: ⚫ Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage. ⚫ The power outlet shall be installed near the equipment and shall be easily accessible. ⚫...

  • Page 7: Technical Support And Assistance

    Preface RCO-1000-J1900 | User’s Manual Technical Support and Assistance Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ⚫ Model name and serial number ⚫...

  • Page 8: Package Contents

    Preface RCO-1000-J1900 | User’s Manual Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty RCO-1000 Series Embedded System Utility DVD Driver Wall Mount Kit Accessory Kit DVI to VGA Adapter Ordering Information Model No.

  • Page 9: Optional Accessory

    Preface RCO-1000-J1900 | User’s Manual Optional Accessories Model No. Product Description 1-E09A06007 Adapter AC/DC 12V 5A 60W with 3pin Terminal Block Plug 5.0mm Pitch SFICBL022 Power Cord, 3-pin US Type, 180cm 1-TPCD00002 Power Cord, European Type, 180cm 1-TPCD00001 Power Cord, 3-pin UK Type, 180cm 3-SIDE-0001 RCO-1000 Series Side Mount Kit 3-SIDE-0002...

  • Page 10: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 11: Overview

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.1 Overview Based on Intel® Atom™ E3845 (1.91GHz) or Celeron® J1900 (2.0GHz) Quad Core processor, RCO-1000 series is a high variety and diversity fanless embedded system. It offers modularize expansion I/O, rich connectivity interfaces, wide range (9~48V) DC power input, and high reliability even operating in °...

  • Page 12: Hardware Specification

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.2 Hardware Specification Processor System Digital Input & Output • Onboard Intel® Atom™ E3845 / J1900 Dual or Quad • 4x Digital Input (Source Type) Core Processor, 1.91GHz / 2.0 GHz with AMI 64Mbit SPI - Input Voltage (Dry Contact): BIOS.

  • Page 13: System I/O

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.3 System I/O 1.3.1 RCO-1000 Front Panel LAN port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network AT/ATX mode select switch Line-out Used to select AT or ATX power mode Used to connect a speaker...

  • Page 14: Rco-1010 / Rco-1010A / Rco-1010B

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.3.2 RCO-1010 / RCO-1010A / RCO-1010B Front Panel LAN port ATX power on/off switch Used to connect the system to a local area Press to power-on or power-off the system network AT/ATX mode select switch Line-out Used to select AT or ATX power mode Used to connect a speaker...

  • Page 15: Rco-1020C / Rco-1020D

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.3.3 RCO-1020C / RCO-1020D Front Panel Line-out ATX power on/off switch Used to connect a speaker Press to power-on or power-off the system Mic-in AT/ATX mode select switch Used to connect a microphone Used to select AT or ATX power mode Remote power on/off switch Power LED...
  • Page 16 Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual Rear Panel COM port DC IN COM1 ~ COM4 support RS232/422/485 serial Used to plug a DC power input with terminal device (RCO-1020C Only) block COM1 ~ COM6 support RS232/422/485 serial DVI-I port device (RCO-1020D Only) Used to connect a DVI monitor or connect Antenna hole...

  • Page 17: Rco-1030

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.3.4 RCO-1030 Front Panel Line-out ATX power on/off switch Used to connect a speaker Press to power-on or power-off the system Mic-in AT/ATX mode select switch Used to connect a microphone Used to select AT or ATX power mode Remote power on/off switch Power LED Used to plug a power on/off switch with...
  • Page 18 Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual Rear Panel Digital I/O Terminal Block DC IN The Digital I/O terminal block supports 4 digital Used to plug a DC power input with terminal input and 4 digital output block COM port DVI-I port COM1 ~ COM6 support RS232/422/485 serial Used to connect a DVI monitor or connect...

  • Page 19: Mechanical Dimension

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.4 Mechanical Dimensions 1.4.1 RCO-1000 Unit: mm...

  • Page 20: Rco-1010 / Rco-1010A / Rco-1010B

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.4.2 RCO-1010 / RCO-1010A / RCO-1010B Unit: mm...

  • Page 21: Rco-1020C / Rco-1020D

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.4.3 RCO-1020C / RCO-1020D Unit: mm...

  • Page 22: Rco-1030

    Chapter 1: Product Introductions RCO-1000-J1900 | User’s Manual 1.4.4 RCO-1030 Unit: mm...

  • Page 23: Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 24: Switch And Connector Locations

    Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual 2.1 Switch and Connector Locations 2.1.1 Top View...

  • Page 25: Bottom View

    Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual 2.1.2 Bottom View 2.1.3 Daughter board view...

  • Page 26: Connector / Switch Definition

    Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX1 AT / ATX Power Mode Switch CLR_CMOS1 Clear BIOS Switch PWR_SW1 Power Switch PWR_LED1 Power LED Status HDD_LED1 HDD Access LED Status WDT_LED1...

  • Page 27: Switch Definitions

    Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual 2.3 Switches Definitions AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Right) ATX Power Mode（Default） 2-3 (Left) AT Power Mode CLR_CMOS1: Clear BIOS Switch Switch Definition Normal Status (Default) Clear BIOS 2.4 Connectors Definitions PWR_SW1: Power Button...
  • Page 28 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual USB3_1: USB 3.0 Connector, Type A Definition Definition USB3_RX+ USB2_DATA1- USB2_DATA1+ USB3_TX- USB3_TX+ USB3_RX- LAN1, LAN2: RJ45 with LEDs Port Definition Definition LAN1_MDI0P LAN1_MDI2N LAN1_MDI0N LAN1_MDI1N LAN1_MDI1P LAN1_MDI3P LAN1_MDI2P LAN1_MDI3N Definition Definition LAN2_MDI0P LAN2_MDI2N...
  • Page 29 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual LINE_OUT1 : Line-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC_IN1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R MIC_L PWR_SW2 : Remote Power Switch Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button RESET1 : Reset Button...
  • Page 30 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual DVI_I1: DVI-I Connector Definition Definition DVI_TX2- DVI Hot Plug Detect DVI_TX2+ DVI_TX0- DVI_TX0+ DDC_CLOCK DDC_DATA VGA VSYNC DVI_TXCLK+ DVI_TX1- DVI_TXCLK- DVI_TX1+ VGA_RED VGA_GREEN VGA_BLUE VGA_HSYNC COM1_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex...
  • Page 31 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual COM2_1: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD2 TX2- DATA2- RxD2 TX2+ DATA2+ TxD2 RX2+ DTR2 RX2- DSR2...
  • Page 32 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual CN2: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DCD4 (DCD6) TX4- (TX6-) DATA4- (DATA6-) RxD4 (RxD6) TX4+ (TX6+) DATA4+ (DATA6+) TxD4 (TxD6)
  • Page 33 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual...
  • Page 34 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual MINIPCIE1: Mini PCI-Express Socket Definition Definition Definition WAKE# +3.3V +3.3V USB_DP1 +3.3V MINIPCIE RST# MINIPCIE_RXN1 +3.3V +1.5V +3.3V CLKREQ1# MINIPCIE_RXP1 USIM_VCC USIM_DATA +1.5V MINIPCIE_CLKN1 USIM_CLK SMB_CLK +1.5V MINIPCIE_CLKP1 MINIPCIE_TXN1 USIM_RST SMB_DATA MINIPCIE_TXP1 USIM_VPP +3.3V...
  • Page 35 Chapter 2: Switches and Connectors RCO-1000-J1900 | User’s Manual SATA1: SATA with Power Connector Definition Definition SATA_TXP1 SATA_TXN1 SATA_RXN1 SATA_RXP1 +3.3V +3.3V +12V +3.3V +12V +12V...

  • Page 36: Chapter 3 System Setup

    Chapter 3 System Setup...

  • Page 37: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 3.2 Removing the chassis bottom cover In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.

  • Page 38: Removing Hdd Bracket

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.3 Removing HDD bracket 1. This step is does not apply to RCO-1000 model as it has no HDD bracket. 2. Unscrew four screws (M3x5L) circled below. 3. Now you can remove the HDD bracket.

  • Page 39: Removing Chassis Top Cover

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.4 Removing chassis top cover 1. Unscrew the three screws (M3x5L) and two copper stud (M3x11L) highlighted below. 2. Hold the body of the system and lift it vertically away from the top cover. 3.

  • Page 40: Installing Sodimm

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.5 Installing SODIMM 1. Place the system body with SODIMM socket facing upward. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound. Make sure the memory module is firmly in place.

  • Page 41: Installing Mini Pcie Card / Msata

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.6 Installing Mini PCIe card / mSATA 1. Place the system body upside down so you can see the 2x mini card socket. Mini PCIe 2 (CN3) can support mSATA. Mini PCIe 2 / mSATA Mini PCIe 1 2.

  • Page 42: Installing Antenna

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.7 Installing antenna 1. Remove antenna hole cover on the system panel. Front Rear 2. Have antenna jack penetrate through the hole. 3. Put on washer and fasten the nut with antenna jack.
  • Page 43 Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 4. Assemble the antenna and antenna jack together. 5. Attach the RF connector at the cable-end onto the communication module.

  • Page 44: Assemble Chassis Top Cover

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.8 Assemble chassis top cover 1. Place both top cover and system body upside down as shown below. 2. Ensure thermal pad is in place where the CPU is located or paste the thermal pad back on the CPU thermal block.
  • Page 45 Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 4. Push the system body down until it is firmly in place. 5. Fasten the three screws (M3x5L) and two copper stud (M3x11L) to lock the system body with top cover.

  • Page 46: Installing Sata Hdd

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.9 Installing SATA HDD 1. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L). 2. Slide the iron plate into the opening on top cover and then place the entire bracket down.
  • Page 47 Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3. Press the entire bracket following the below direction so the SATA connector is firmly plugged into the HDD. 4. Fasten the four screws (M3x5L) to lock the HDD bracket in place.

  • Page 48: Assemble Chassis Bottom Cover

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.10 Assemble chassis bottom cover 1. Place the bottom cover according to the below direction and make sure the rail is facing inside the system. 2. Lock the bottom cover with the four screws (M3x5L).

  • Page 49: Installing Sim Card

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.11 Installing SIM card 1. SIM card socket is located on the front panel of the system. Unscrew one screw (M3x5L) to remove the SIM card socket cover. 2. Now you can insert SIM card into the socket. SIM 1 SIM 2...
  • Page 50 Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3. Please note that the installation of SIM 1 and SIM 2 has to match the installation of mini PCIe sockets. SIM Card Socket Number Matching Mini PCIe Slot SIM 1 Mini PCIe 1 SIM 2 Mini PCIe 2 / mSATA (CN3) 4.

  • Page 51: Installing Wall Mount Kit

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.12 Installing wall mount kit 1. Wall mount kit is available for RCO-1000 series included in the standard package. 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.

  • Page 52: Installing Vesa Mount Kit

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.13 Installing VESA mount kit 1. VESA mount kit is available for RCO-1000 series as optional accessories. For Panel For System 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.
  • Page 53 Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 4. Lock the VESA mount kit (for system) with four screws (M3x8L, Nylok). 5. VESA mount kit (for panel) should be locked on the back of the panel with four screws. 6. Now the system can be hang in the back of the panel using the hooks.

  • Page 54: Installing Side Mount Kit

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.14 Installing side mount kit 1. Side mount kit is available for RCO-1000 series as optional accessories. 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.
  • Page 55 Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 4. Lock the side mount kit with four screws (M3x8L, Nylok).

  • Page 56: Installing Din Rail Holder

    Chapter 3: System Setup RCO-1000-J1900 | User’s Manual 3.15 Installing DIN rail holder 1. Din rail holder is available for RCO-1000 series as optional accessories. 2. Place the system upside down so you can see the bottom cover. The highlighted screw holes below will be used.

  • Page 57: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup...

  • Page 58: Bios Introduction

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del>...

  • Page 59: Main Setup

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. 4.2.1 System Date Set the system date.

  • Page 60: Advanced Setup

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3 Advanced Setup 4.3.1 ACPI Settings ■ Enable ACPI Auto Configuration This item allows you to enable or disable BIOS ACPI Auto Configuration. ■ Enable Hibernation This item allows you to enable or disable system ability to hibernate. ■...

  • Page 61: Super Io Configuration

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3.2 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration ❑ Serial Port This item allows you to enable or disable serial port.
  • Page 62 Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual ■ Serial Port 2 Configuration ❑ Serial Port This item allows you to enable or disable serial port. ❑ Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ❑...
  • Page 63 Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual ■ Serial Port 4 Configuration ❑ Serial Port This item allows you to enable or disable serial port. ❑ Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ❑...
  • Page 64 Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual ■ Serial Port 6 Configuration ❑ Serial Port This item allows you to enable or disable serial port. ❑ Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ❑...

  • Page 65: Hardware Monitor

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3.3 Hardware Monitor These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. 4.3.4 Serial Port Console Redirection ■ Console Redirection These items allows you to enable or disable COM1~COM6 console redirection.

  • Page 66: Cpu Configuration

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3.5 CPU Configuration ■ Intel Virtualization Technology Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple Virtual systems. ■...

  • Page 67: Ppm Configuration

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3.6 PPM Configuration ■ CPU C state Report Enables or disables support for CPU's power-saving functions. ■ Enhanced C state Enables or disables Intel CPU Enhanced Halt (C1E) function, a CPU power-saving function in system halt state.

  • Page 68: Sata Configuration

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3.7 SATA Configuration ■ SATA Speed Support Change the SATA Speed. Select <Gen1> or <Gen2> speed. ■ SATA Mode This item allows you to select IDE or AHCI Mode. ■ Serial – ATA Port 0 This item allows you to enable or disable Serial-ATA Port 0.

  • Page 69: Csm Configuration

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3.9 CSM Configuration ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter This item allows you to select which type of operating system to boot. UEFI and Legacy: Allows booting from operating systems that support legacy option ROM or UEFI option ROM.

  • Page 70: Usb Configuration

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.3.10 USB Configuration ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support.

  • Page 71: Chipset

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.4 Chipset 4.4.1 North Bridge This section provides information on the installed memory size and memory/onboard graphics-related configuration options.
  • Page 72 Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual ■ Intel IGD Configuration This section provides onboard graphics-related configuration options. ❑ IGD Turbo Enable This item allows you to enable or disable IGD Turbo. ❑ GFX Boost This item allows you to enable or disable GFX Boost. ❑...

  • Page 73: South Bridge

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.4.2 South Bridge ■ Azalia HD Audio Control detection of the Azaliadevice. ❑ Audio Controller Enabled: Azalia will be unconditionally enabled. Disabled: Azalia will be unconditionally disabled. ■ USB Configuration ❑ XHCI Mode This item allows you to enable or disable the USB XHCI controller.
  • Page 74 Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual ■ PCI Express Configuration ❑ PCI Express Port 1 (mPCIE1) This item allows you to enable or disable PCI Express Port 1 (mPCIE1) in the Chipset. ❑ Speed ❑ Change the PCIe Port Speed. Select <AUTO> ,<Gen 2> or <Gen 1> ❑...

  • Page 75: Security

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.5 Security Security menu allow you to change administrator password and user password settings. 4.5.1 Administrator Password This item allows you to set Administrator Password. 4.5.2 User Password This item allows you to set User Password.

  • Page 76: Boot

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.6 Boot This menu allows you to setup the system boot options. 4.6.1 Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State This item selects the keyboard NumLock state.

  • Page 77: Save & Exit

    Chapter 4: BIOS Setup RCO-1000-J1900 | User’s Manual 4.7 Save & Exit This setting allows you to configure the boot settings. 4.7.1 Save Changes and Reset This item allows you reset the system after saving the changes. 4.7.2 Discard Changes and Reset Select this option to quit Setup without making any permanent changes to the system configuration.

  • Page 78: Wdt & Gpio

    Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output).

  • Page 79: Wdt Sample Code

    Appendix – WDT & GPIO RCO-1000-J1900 | User’s Manual WDT Sample Code WDT Setting // IO Address 0xA16 is time value // IO Address 0xA15 is WDT enable and configuration Example, Set 0xA16=-0x03, 0xA15=0x31, it will reset after 3 seconds #define TimePort 0xA16 #define TimeEnablePort...

  • Page 80: Gpio Sample Code

    Appendix – WDT & GPIO RCO-1000-J1900 | User’s Manual GPIO Sample Code GPIO Setting IO_DO4 I/O 0xA02h Bit3 IO_DO3 I/O 0xA02h Bit2 IO_DO2 I/O 0xA02h Bit1 IO_DO1 I/O 0xA02h Bit0 IO_DI4 I/O 0xA03h Bit7 IO_DI3 I/O 0xA03h Bit6 IO_DI2 I/O 0xA03h Bit5 IO_DI1 I/O 0xA03h Bit4 #define GPI_ADDR 0xA03...
  • Page 81 All Rights Reserved RCO-1000-J1900 | User’s Manual...
