  • Page 1 USER’S MANUAL VIO-200-PC100-KBL-U Series Industrial Panel PCs...

  • Page 2: Table Of Contents

    l User’s Manual VIO-200-PC100-KBL-U Table of Contents Prefaces …………………………………………………….…………………………………….……. 04 Revision …………………………………………………………………………………………..……………….…….. 04 Disclaimer ………………………………………………………..…….…….………………………….…………….. 04 Copyright Notice …………………………………….…………………….………………………………………… 04 Trademarks Acknowledgment …………..………………………………………………………....04 Environmental Protection Announcement …………………………….………………….…………….. 04 Safety Precautions ………………………………………….……………………………….…………….……….. 05 Technical Support and Assistance …………………………………….…………….…………….…..……. 06 Conventions Used in this Manual ………………………………………………………………….….…….. 06 Package Contents …………………………………………………………………………………………….………...
  • Page 3 l User’s Manual VIO-200-PC100-KBL-U Chapter 3 Front Panel Controls ……………………..…………………………………… 45 Users Controls ……...………………………………………………………………..……….…... 46 OSD Operation ……...……………………………………………….……………..………..…... 47 3.2.1 Luminance ……………………………………………………………………..…………… 47 3.2.2 Picture ………………………………….………………………………………..…………… 48 3.2.3 Color ………………………………….…………………………………………..…………… 48 3.2.4 OSD Settings …………………………………………………………………..…………… 48 3.2.5 Setup ……………………………………………………………………………..…………… 49 Chapter 4 System Setup …………………………..…………………………………………...

  • Page 4: Prefaces

    2019/09/19 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. Premio Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of Premio Inc.

  • Page 5: Safety Precautions

    Preface l User’s Manual VIO-200-PC100-KBL-U Safety Precautions Before installing and using the equipment, please read the following precautions:  Put this equipment on a reliable surface during installation. Dropping it or letting it fall could cause damage.  The power outlet shall be installed near the equipment and shall be easily accessible. ...

  • Page 6: Technical Support And Assistance

    User’s Manual Preface VIO-200-PC100-KBL-U Technical Support and Assistance 1. Visit the Premio Inc website at https://premioinc.com/ where you can find the latest information about the product. 2. Contact your distributor, our technical support team or sales representative for technical support if you need additional assistance.

  • Page 7: Package Contents

    l User’s Manual Preface VIO-200-PC100-KBL-U Package Contents Before installation, please ensure all the items listed in the following table are included in the package. VIO-215-PC100-KBL-U VIO-212-PC100-KBL-U VIO-215-PC100-KBL-U-1 VIO-212-PC100-KBL-U-1 Item Description Q’ty Item Description Q’ty VIO-215-PC100-KBL-U Series VIO-212-PC100-KBL-U Series Panel PC Panel PC Panel Mount Kit Panel Mount Kit...

  • Page 8: Ordering Information

    l User’s Manual Preface VIO-200-PC100-KBL-U Ordering Information Product Description Model No. VIO-212R-PC100-KBL-U-7300U 12.1" XGA Resistive Touch Thin Frame Panel PC with Intel® Core™ i5-7300U Processor VIO-212C-PC100-KBL-U-7300U 12.1" XGA Capacitive Touch Thin Frame Panel PC with Intel® Core™ i5-7300U Processor VIO-212R-PC100-KBL-U-7100U 12.1"...
  • Page 9 l User’s Manual Preface VIO-200-PC100-KBL-U Product Description Model No. VIO-W215R-PC100-KBL-U- 15.6" 16:9 Full HD Resistive Touch Thin Frame Panel PC with Intel® Core™ i5-7300U Processor 7300U VIO-W215C-PC100-KBL-U- 15.6" 16:9 Full HD Capacitive Touch Thin Frame Panel PC with Intel® Core™ i5-7300U Processor 7300U VIO-W215R-PC100-KBL-U- 15.6"...

  • Page 10: Optional Accessory

    l User’s Manual Preface VIO-200-PC100-KBL-U Product Description Model No. VIO-W221R-PC100-KBL-U- 21.5" 16:9 Full HD Resistive Touch Thin Frame Panel PC with Intel® Core™ i5-7300U Processor 7300U VIO-W221C-PC100-KBL-U- 21.5" 16:9 Full HD Capacitive Touch Thin Frame Panel PC with Intel® Core™ i5-7300U Processor 7300U VIO-W221R-PC100-KBL-U- 21.5"...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions...

  • Page 12: Overview

    VIO-200-PC100-KBL-U 1.1 Overview The VIO-200-PC100-KBL-U series Panel PC is based on 7th Gen. Intel® Core™ i5-7300U (up to 3.5GHz) / i3-7100U (2.4GHz) Dual Core processor. Designed with flat surface, IP 65 dust / waterproof front panel, and aluminum die-casting front frame with rugged body structure, it is a versatile I/O connections, and rugged reliability industrial panel PC.

  • Page 13: Hardware Specification

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.2 Hardware Specification 1.2.1 VIO-212R(C)-PC100-KBL-U | VIO-212R(C)-PC100-KBL-U-1 Hardware Specification Display • VGA: 1x VGA • LCD Size: 12.1” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1024 x 768 (XGA) • COM •...

  • Page 14: Vio-215R(C)-Pc100-Kbl-U | Vio-215R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.2.2 VIO-215R(C)-PC100-KBL-U | VIO-215R(C)-PC100-KBL-U-1 Hardware Specification Display • VGA: 1x VGA • LCD Size: 15” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1024 x 768 (XGA) • COM • Brightness (cd/m ): 350 - 4x RS-232/422/485 •...

  • Page 15: Vio-W215R(C)-Pc100-Kbl-U | Vio-W215R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.2.3 VIO-W215R(C)-PC100-KBL-U | VIO-W215R(C)-PC100-KBL-U-1 Hardware Specification Display • VGA: 1x VGA • LCD Size: 15.6” (16:9) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1920 x 1080 (Full HD) • COM • Brightness (cd/m ): 400 - 4x RS-232/422/485 •...

  • Page 16: Vio-217R(C)-Pc100-Kbl-U | Vio-217R(C)-Pc100-Kbl

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.2.4 VIO-217R(C)-PC100-KBL-U | VIO-217R(C)-PC100-KBL-U-1 Hardware Specification Display • VGA: 1x VGA • LCD Size: 17” (4:3) • DisplayPort: 1x 1x DisplayPort • Max. Resolution: 1280 x 1024 (SXGA) • COM • Brightness (cd/m ): 350 - 4x RS-232/422/485 •...

  • Page 17: Vio-219R(C)-Pc100-Kbl-U | Vio-219R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.2.5 VIO-219R(C)-PC100-KBL-U | VIO-219R(C)-PC100-KBL-U-1 Hardware Specification • VGA: 1x VGA Display • DisplayPort: 1x 1x DisplayPort • LCD Size: 19” (4:3) • COM • Max. Resolution: 1280 x 1024 (SXGA) - 4x RS-232/422/485 •...

  • Page 18: Vio-W221R(C)-Pc100-Kbl-U | Vio-W221R(C)-Pc100-Kbl

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.2.6 VIO-W221R(C)-PC100-KBL-U | VIO-W221R(C)-PC100-KBL-U-1 Hardware Specification • VGA: 1x VGA Display • DisplayPort: 1x 1x DisplayPort • LCD Size: 21.5” (16:9) • COM • Max. Resolution: 1920 x 1080 (Full HD) - 4x RS-232/422/485 •...

  • Page 19: Vio-W224R(C)-Pc100-Kbl-U | Vio-W224R(C)-Pc100-Kbl

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.2.7 VIO-W224R(C)-PC100-KBL-U | VIO-W224R(C)-PC100-KBL-U-1 Hardware Specification • VGA: 1x VGA Display • DisplayPort: 1x 1x DisplayPort • LCD Size: 23.8” (16:9) • COM • Max. Resolution: 1920 x 1080 (Full HD) - 4x RS-232/422/485 •...

  • Page 20: System I/O

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.3 System I/O 1.3.1 Front Removable HDD Bay SIM Card Socket Used to inserts a 2.5” HDD device Used to insert SIM card Antenna hole CFast Socket Used to connect an antenna for optional Mini- Used to insert CFast card PCIe WiFi module 1.3.2 Rear...

  • Page 21: Side (Left)

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.3.3 Side (Right) COM port AT/ATX mode select switch COM3~4 support RS232/422/485 serial device Used to select AT or ATX power mode PC/CAR mode select switch Universal I/O Bracket Used to select PC or CAR power mode Used to customized I/O output (VIO-xxx-PC100-KBL-U only) DELAY TIME switch...

  • Page 22: Top

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.3.5 Top VESA Mounting Hole These are mounting holes for VESA mount (75x75mm and 100x100mm)

  • Page 23: Mechanical Dimension

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.4 Mechanical Dimensions 1.4.1 VIO-212R(C)-PC100-KBL-U Unit: mm VIO-212R(C)-PC100-KBL-U-1 Unit: mm...

  • Page 24: Vio-215R(C)-Pc100-Kbl-U | Vio-215R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.4.2 VIO-215R(C)-PC100-KBL-U Unit: mm VIO-215R(C)-PC100-KBL-U-1 Unit: mm...

  • Page 25: Vio-W215R(C)-Pc100-Kbl-U | Vio-W215R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.4.3 VIO-W215R(C)-PC100-KBL-U Unit: mm VIO-W215R(C)-PC100-KBL-U-1 Unit: mm...

  • Page 26: Vio-217R(C)-Pc100-Kbl-U | Vio-217R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.4.4 VIO-217R(C)-PC100-KBL-U Unit: mm VIO-217R(C)-PC100-KBL-U-1 Unit: mm...

  • Page 27: Vio-219R(C)-Pc100-Kbl-U | Vio-219R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.4.5 VIO-219R(C)-PC100-KBL-U Unit: mm VIO-219R(C)-PC100-KBL-U-1 Unit: mm...

  • Page 28: Vio-W221R(C)-Pc100-Kbl-U | Vio-W221R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.4.6 VIO-W221R(C)-PC100-KBL-U Unit: mm VIO-W221R(C)-PC100-KBL-U-1 Unit: mm...

  • Page 29: Vio-W224R(C)-Pc100-Kbl-U | Vio-W224R(C)-Pc100-Kbl-U-1

    l User’s Manual Chapter 1: Product Introductions VIO-200-PC100-KBL-U 1.4.7 VIO-W224R(C)-PC100-KBL-U Unit: mm VIO-W224R(C)-PC100-KBL-U-1 Unit: mm...

  • Page 30: Switches And Connectors

    Chapter 2 Switches and Connectors...

  • Page 31: Switch And Connector Locations

    l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U 2.1 Switch and Connector Locations 2.1.1 Top View SIM1 SIM2...

  • Page 32: Bottom View

    l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U 2.1.2 Bottom View...

  • Page 33: Connector / Switch Definition

    l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U 2.2 Connector / Switch Definition List of Connector / Switch Connector Location Definition AT_ATX2 AT / ATX Power Mode Switch CLR_CMOS1 Clear BIOS Switch CAR_PWR2 PC / Car Mode Switch DELAY_TIME2 Car mode PC turn off delay time CFAST1_2 CFast Socket...

  • Page 34: Switch Definitions

    l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U 2.3 Switches Definitions AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Right) ATX Power Mode（Default） 2-3 (Left) AT Power Mode CLR_CMOS1: Clear BIOS Switch Switch Definition Normal Status (Default) Clear BIOS CAR_PWR2: PC / Car Mode Switch Switch...
  • Page 35 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U Step of Setting Power Ignition Step 1: To select power ignition by PC/CAR switch. Step 2: To configure the power off delay time, please check the Delay Time Setting Options in advance.

  • Page 36: Connector Definitions

    l User’s Manual Chapter 2: Switches and Connectors Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U 2.4 Connectors Definitions CFAST1_2: CFast Socket Definition Definition Definition PC10 SATA_TXP1 PC11 SATA_TXN1 PC12 PC13 +3.3V SATA_RXN1 PC14 +3.3V SATA_RXP1 PC15 PC16 PC17 PWR_SW2: Power Button Definition Definition Power Button...
  • Page 37 l User’s Manual Chapter 2: Switches and Connectors Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U SIM1, SIM2: SIM Card Socket Definition Definition UIM_PWR UIM_VPP UIM_RESET UIM_DATA UIM_CLK COM: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition...
  • Page 38 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U COM: RS232 / RS422 / RS485 Connector Connector Type: 2X5 10-pin box header, 2.54mm pitch RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DATA- DATA+ DC_IN1: DC Power Input Connector (+9~50V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~50VIN...
  • Page 39 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U DP: DisplayPort Connector Definition Definition DP_LANE0_P DP_LANE3_N DP_LANE0_N DP_LANE1_P DP_AUX_P DP_LANE1_N DP_LANE2_P DP_AUX_N DP_HPD DP_LANE2_N DP_LANE3_P +3.3V LINE_OUT1 : Line-out Jack (Green) Connector Type: 5-pin Phone Jack Definition OUT_R OUT_L MIC_IN1: Microphone Jack (Pink) Connector Type: 5-pin Phone Jack Definition MIC_R...
  • Page 40 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U DIO1: Digital Input / Output Connector Connector Type: Terminal Block 2X9 18-pin, 3.5mm pitch Definition Definition DIN1 DOUT1 DIN2 DOUT2 DIN3 DOUT3 DIN4 DOUT4 DIN5 DOUT5 DIN6 DOUT6 DIN7 DOUT7 DIN8 DOUT8 DC power input (+5V~+30V)
  • Page 41 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U PWR_SW1 : Remote Power Switch Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button...
  • Page 42 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U LAN1, LAN2: RJ45 with LEDs Port Connector Type: RJ45 Connector Definition Definition LAN_MDI0P LAN_MDI2N LAN_MDI0N LAN_MDI1N LAN_MDI1P LAN_MDI3P LAN_MDI2P LAN_MDI3N Act LED Status Definition Blinking Yellow Data Activity No Activity Link LED Status Definition Steady Orange 1Gbps Network Link...
  • Page 43 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U MINIPCIE1: Mini PCI-Express / mSATA Socket Definition Definition Definition WAKE# +3.3V USB2_D+ +3.3V RESET# +3.3V +1.5V +3.3VAUX CLKREQ# UIM_PWR DEVSLP USIM_DATA +1.5V REFCLK- UIM_CLK SMB_CLK +1.5V REFCLK+ UIM_RST SMB_DATA PCIE_MSATA_SEL USIM_VPP +3.3V USB2_D- MINIPCIE2: Mini PCI-Express Socket...
  • Page 44 l User’s Manual Chapter 2: Switches and Connectors VIO-200-PC100-KBL-U PWR_LED2: Power LED Status Definition POWER LED+ POWER LED- HDD_LED2: HDD Access LED Status Definition HDD LED+ HDD LED-...

  • Page 45: Chapter 3 Front Panel Controls

    Chapter 3 Front Panel Controls...

  • Page 46: Users Controls

    l User’s Manual Chapter 3: Front Panel Controls VIO-200-PC100-KBL-U 3.1 Users Controls POWER MENU INCREASE DECREASE AUTO  Power Button Turns the monitor on or off.  1. Blue indicates power on. 2. Yellow indicates HDD access status.  MENU / Enter Button Press to view the OSD menu.

  • Page 47: Osd Operation

    l User’s Manual Chapter 3: Front Panel Controls VIO-200-PC100-KBL-U 3.2 OSD Operation 3.2.1 Luminance ■ Brightness Adjust the luminance level of the screen. ■ Contrast Adjusts the contrast level of the screen. ■ Gamma This item allows you to on or off the Gamma function. ■...

  • Page 48: Picture

    l User’s Manual Chapter 3: Front Panel Controls VIO-200-PC100-KBL-U 3.2.2 Picture ■ Phase Adjust the monitor internal signal phase. ■ Clock Adjust the monitor internal sampling clock rate. ■ H. Position Adjusts the position of the screen image left and right. ■...

  • Page 49: Setup

    l User’s Manual Chapter 3: Front Panel Controls VIO-200-PC100-KBL-U 3.2.5 Setup ■ Language Selects the language in which the OSD menu is displayed. The factory default is English. ■ Mute Allows the user to turn the Mute On or Off. ■...

  • Page 50: Chapter 4 System Setup

    Chapter 4 System Setup...

  • Page 51: Set Torque Force To 3.5 Kgf-Cm To Execute All The Screwing And Unscrewing

    l User’s Manual Chapter 4: System Setup VIO-200-PC100-KBL-U 4.1 Set torque force to 3.5 kgf-cm to execute all the screwing and unscrewing. 4.2 Removing PC module from the display module. In order to prevent electric shock or system damage, before removing the chassis cover, must turn off power and disconnect the unit from power source.

  • Page 52: Installing Sodimm

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.3 Installing SODIMM 1. Remove SODIMM cover in the below circled area for installing memory module. 2. Insert memory module from 45 degree direction. 3. Press the memory module vertically downward until you hear the “click” sound. Make sure the memory module is firmly in place.

  • Page 53: Installing Mini Pcie Card / Msata

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.4 Installing mini PCIe card / mSATA 1. Two mini PCIe slots are available for PC100-KBL-U series. MiniPCIE1 supports mSATA. MiniPCIE2 MiniPCIE1 / mSATA 2. Insert mini PCIe card or mSATA module from 45 degree direction. 3.

  • Page 54: Installing Hdd On Removable Stat Hdd Bay

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.5 Installing HDD on removable STAT HDD bay 1. One removable SATA HDD bays is available for PC100-KBL-U Series 2. Unscrew the two sun screws circled below to take out the removable SATA HDD bay.
  • Page 55 l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 3. Lock the 2.5” HDD with HDD bracket using four screws (M3x4L). 4. Slide the HDD bracket back and then fasten the sun screws.

  • Page 56: Installing Cfast Card

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.6 Installing CFast card 1. One CFast socket is available for PC100 series. Unscrew two screws to remove the bracket. 2. Insert CFast card into the socket until you hear the “click” sound. 3.

  • Page 57: Installing Sim Card

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.7 Installing SIM card 1. For PC100-KBL-U Series, two SIM card slots are available on system chassis between removable HDD bay and CFast slot. 2. Press the SIM card in until you hear the “click” sound.
  • Page 58 l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 3. Please note that the installation of SIM 1 and SIM 2 has to match the installation of mini PCIe slots. SIM Card Socket Number Matching Mini PCIe Slot SIM 1 Mini PCIe 2 (CN2) SIM 2 Mini PCIe 1 / mSATA (CN1) MiniPCIE2...

  • Page 59: Removing Chassis Top Cover

    l User’s Manual Chapter 4: System Setup VIO-200-PC100-KBL-U 4.8 Removing chassis top cover 1. Unscrew the 6 screws (M3x5L) below. 2. Now you can remove the top cover of PC module.

  • Page 60: Installing Antenna

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.9 Installing antenna 1. Three antenna holes are available for PC100-KBL-U series. 2. Remove antenna hole cover on the system panel. 3. Have antenna jack penetrate through the hole.
  • Page 61 l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4. Put on washer and fasten the nut with antenna jack. 5. Attach the RF connector at the cable-end onto the communication module. 6. Assemble the antenna and antenna jack together.

  • Page 62: Assembling Chassis Top Cover

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.10 Assembling chassis top cover 1. Ensure thermal pad is in place on the CPU thermal block. 2. Close the chassis top cover following the below direction and make sure the aluminum part on the top cover is touching the thermal pad on CPU thermal block.
  • Page 63 l User’s Manual Chapter 4: System Setup VIO-200-PC100-KBL-U 3. Fasten the 6 screws (M3x5L) to lock the system body with top cover.

  • Page 64: Connecting Pc Module With Vio Display Module

    l User’s Manual Chapter 3: System Setup VIO-200-PC100-KBL-U 4.11 Connecting PC module with VIO display module 1. Hold the PC module with its connector facing towards the connector on the back of VIO display module. 2. Press the PC module downward to ensure two modules are firmly connected. 3.

  • Page 65: Chapter 5 Bios Setup

    Chapter 5 BIOS Setup...

  • Page 66: Bios Introduction

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del>...

  • Page 67: Main Setup

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu. ■...

  • Page 68: Advanced Setup

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3 Advanced Setup...

  • Page 69: Cpu Configuration

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.1 CPU Configuration ■ Intel Virtualization Technology Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple Virtual systems. ■...

  • Page 70: Pch-Fw Configuration

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.2 PCH-FW Configuration 5.3.3 SATA and RST Configuration ■ SATA Controller(s) Enable or disable Serial ATA controller. ■ SATA Mode Selection This item allows users to select mode of SATA controller. ■ Serial ATA Port 0 / 1 / 2 This item allows users to enable or disable Serial ATA Port 0 / 1 / 2.

  • Page 71: Rst (Uefi Raid) Configuration

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.4 RST (UEFI RAID) Configuration How to set the UEFI RAID: 1. When set to RAID, please save change reset system. 2. After reboot the system, please into BIOS utility and then will see “Intel (R) Rapid Storage Technology”...
  • Page 72 l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 3. Into Intel(R) Rapid Storage Technology, and start create RAID volume. 4. Start Create the RAID ■ Select Disk that you want to do the RAID ■ Select [x]; No-Select [ ]...

  • Page 73: Trusted Computing

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.5 Trusted Computing ■ Security Device Support Enable or disable Security Device Support. 5.3.6 ACPI Settings ■ Enable ACPI Auto Configuration Enable or disable ACPI Auto Configuration.

  • Page 74: Super Io Configuration

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.7 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option. ■ Serial Port 1 Configuration  Serial Port This item allows you to enable or disable serial port.
  • Page 75 l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U ■ Serial Port 2 Configuration  Serial Port This item allows you to enable or disable serial port.  Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ...
  • Page 76 l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U ■ Serial Port 4 Configuration  Serial Port This item allows you to enable or disable serial port.  Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ...

  • Page 77: Hardware Monitor

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U ■ Serial Port 6 Configuration  Serial Port This item allows you to enable or disable serial port.  Change Settings This item allows you to change the address & IRQ settings of the specified serial port. ...

  • Page 78: Serial Port Console Redirection

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.9 Serial Port Console Redirection ■ Console Redirection These items allows you to enable or disable COM1 console redirection. 5.3.10 Stack Configuration...

  • Page 79: Csm Configuration

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.11 CSM Configuration ■ CSM Support This item allows users to enable or disable for “CSM Support”. ■ GateA20 Active This item allows users to set Upon Request or Always for "GateA20 Active“. ■...

  • Page 80: Usb Configuration

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.3.12 USB Configuration ■ Legacy USB Support Allows USB keyboard/ mouse to be used in MS-DOS. ■ XHCI Hand-off Determines whether to enable XHCI (USB3.0) Hand-off feature for an operating system without XHCI (USB3.0) Hand-off support. ■...

  • Page 81: Chipset

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 5.4.1 System Agent (SA) Configuration ■ VT-d This item allows users to enable or disable VT-d.
  • Page 82 l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U ■ Graphic Configuration  GTT Size This item allows you to change the GTT size.  Aperture Size Aperture size optimal between 128MB, 256MB, 512MB, 1024MB or 2048MB.  DVMT Pre-Allocated DVMT pre-allocated (fixed) Graphics memory size optimal from 0M to 60M. ...

  • Page 83: Pch-Io Configuration

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.4.2 PCH-IO Configuration This section allows you to configure the chipset. ■ PCI Express Configuration...
  • Page 84 l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U  PCI Express Root Port 6 / 10 / 11  PCI Express Port 6 / 10 / 11 This item allows you to enable or disable PCI Express Port 6 / 10 / 11 in the chipset. ...
  • Page 85 l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U ■ HD Audio Configuration  HD Audio Control detection of the HD-Audio device. This item allows you to select <Enabled>, <Disabled> or <Auto>. Disabled: Azalia will be unconditionally be disabled. Enabled: Azalia will be unconditionally be enabled. Auto: Azalia will be enabled if present, disabled otherwise.

  • Page 86: Security

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.5 Security Security menu allow users to change administrator password and user password settings. ■ Administrator Password This item allows you to set Administrator Password. ■ User Password This item allows you to set User Password.

  • Page 87: Boot

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.6 Boot This menu allows you to setup the system boot options. ■ Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. ■ Bootup NumLock State This item selects the keyboard NumLock state.

  • Page 88: Save & Exit

    l User’s Manual Chapter 4: BIOS Setup VIO-200-PC100-KBL-U 5.7 Save & Exit This setting allows users to configure the boot settings. ■ Save Changes and Reset This item allows user to reset the system after saving the changes. This item allows user to reset the system after saving the changes.

  • Page 89: Appendix

    Appendix WDT & GPIO & Mounting Guide...

  • Page 90: Wdt Sample Code

    l User’s Manual Appendix – WDT & GPIO VIO-200-PC100-KBL-U WDT Sample Code // IO Address 0xA16 is time value // IO Address 0xA15 is WDT enable and configuration Example, Set 0xA16=-0x03, 0xA15=0x31, it will reset after 3 seconds #define TimePort 0xA16 #define TimeEnablePort 0xA15 WriteByte (TimePort,0x03)

  • Page 91: Gpio Sample Code

    l User’s Manual Appendix – WDT & GPIO VIO-200-PC100-KBL-U GPIO Sample Code  GPI 1 ~ GPI 8 GPI 1 GPI 2 GPI 3 GPI 4 GPI 5 GPI 6 GPI 7 GPI 8 IO Address 0xA03h 0xA03h 0xA03h 0xA03h 0xA06h 0xA06h 0xA06h...
  • Page 92 l User’s Manual Appendix – WDT & GPIO VIO-200-PC100-KBL-U Sample Code: #1 : // Get GPI 1 status //Get GPI 0 Pin Status Register printf("Input port value = %x\n", ReadByte(GPI1to4_ADDR)); // bit4 = GPI 1 status // Get GPI 5 status //Get GPI 0 Pin Status Register printf("Input port value = %x\n", ReadByte(GPI_REG5to8));...

  • Page 93: Mounting Guide

    l User’s Manual Appendix – Panel Mount VIO-200-PC100-KBL-U Mounting Guide Flush Mount / Panel Mount: • Cut hole in the wall w/ dimensions according to the screen size you have purchased. Please refer to the next page for the list of cutout dimensions and max wall depths Max.
  • Page 94 User’s Manual Appendix – Panel Mount VIO-200-PC100-KBL-U VIO-200-PC100-KBL-U Series Model Wall Cut-Out (W x H) Unit: mm Max Wall Thickness (mm) VIO-212R(C)-PC100-KBL-U 310 x 249 VIO-215R(C)-PC100-KBL-U 368 x 292.5 VIO-217R(C)-PC100-KBL-U 400 x 331.5 VIO-219R(C)-PC100-KBL-U 442 x 367 VIO-W215R(C)-PC100-KBL-U 389.5 x 238.5 10.5...
