Page 2
But Panorama 2 is not only simple to install and use, thanks to advanced acoustic technology borrowed directly from our highest performance hi-fi designs, it offers sound quality more often associated with the best hi-fi separates.
Page 3
2. Installing Panorama 2 2.1 Panorama 2 Location and Mounting The home theatre surround performance achieved by Panorama 2 will be optimised if it is located in the room approximately symmetrically between two sound-reflective walls. Figure 1 illustrates two possible room layouts. Panorama 2 can be either...
Page 4
2.2 Panorama 2 Input Connections The Panorama 2 connection sockets are located optical/aux sub out service on the rear of the unit. Panorama 2 may be turned upside-down to gain access to the sockets. Ensure HDMI out HDMI 1 HDMI 2...
It has two operational modes: Normal Mode and Setup Mode. When Panorama 2 is switched on from standby it will start up in normal mode. Setup Mode, which requires the Panorama 2 to be...
Figure 8 If a signal is present on Input 1 Panorama 2 will immediately reproduce it. Handset controls Once reproducing audio satisfactorily, use the...
4. Panorama 2 setup buttons to increase or decrease the level. Return to walls to either side of Panorama 2 to be specified. Select LEFT WALL and RIGHT WALL in turn and the previous menu by pressing the Back button Using Panorama 2’s default setup is likely to...
The LANGUAGE menu enables the language used for the Panorama 2 Setup Mode on screen display to be changed. Select LANGUAGE and use the Input ( ) and Audio Mode ( ) buttons to select from the available languages.
