- Page 1 INTELLIGENT BATTERY CHARGER FOR V-LOCK LITHIUM ION BATTERIES ONLY Model CVTR2 - SEQUENTIAL OPERATING INSTRUCTIONS Revision 1.2 www.blueshape.net Printed in Malta 2009...
-
Page 2: This Equipment Must Be Earthed
Please read these instructions concerning your safety BLUESHAPE lithium-ion battery chargers have been designed to provide a superior performance by managing relatively high currents during their operation in order to reduce charging time. As may be expected, the chargers become warm during operation and it is therefore very important to keep their ventilation openings unobstructed. - Page 3 Package contents - CVTR2* sequential dual position charger with Aux output - AC power cord - Safety operating instructions *CVTR2 can also be powered by the “In-car” adapter type PWCAR rated 22V / 5A, 110VA, available as a separate product.
- Page 4 CVTR2 graphic description Mains switch AUX output connector (13.8V 110W) AUX output LED indicator (see page 12 for explanation) Battery LED indicators (see page 11 for explanation) Carrying handle Ventilation inlets Battery #2 charging bay (Battery #1 charging bay is on the...
- Page 5 CVS8X graphic description – Rear/left side AC Mains input, 100V-240V Ventilation outlets Data connector DC input 22V/5A, 110VA (PWCAR) Carrying handle Ventilation inlets Battery #1 charging bay (Battery #2 charging bay is on the opposite side) Rotating support foot Release button...
- Page 6 Introduction The BLUESHAPE series of intelligent lithium ion battery chargers has been specifically designed for fast and reliable charging of the BLUESHAPE V-lock battery range. All charger models (except CVTR1M) are capable of delivering around 4 Amps in constant current mode making them particularly suitable to users who require a fast turnaround from their batteries.
- Page 7 Li-Ion charger in the broadcasting sector. This results in currently the shortest possible battery charging time. BLUESHAPE Li-Ion BV battery series allow fast charging due to several intrinsic features such as pre-charge protection and cell balancing; avoiding cell damage and life-cycle shortening, as demonstrated by the life-cycle performances.
-
Page 8: Ctp: Flexibility Of Operation And Charger Reliability
To improve the reliability of the device without compromising its usage flexibility, BLUESHAPE has developed an innovative feature; CTP (Charger Thermal Protection) that allows the electronics to work out the best possible charge profiles without causing damage, even in adverse temperature conditions. - Page 9 Insert in the direction of the arrow Observe the LED. In addition, the charge status may be read in 20% steps through the BLUESHAPE battery LED array. Leave the battery to charge for the appropriate time (see table on page 6)
-
Page 10: Additional Safety Notes
ADDITIONAL SAFETY NOTES Chargers and/or batteries may become hot during charging. This is normal. Please consult your BLUESHAPE dealer if you notice that either a charger or a battery, become excessively hot during the charging operation. Be careful not to block the equipment’s ventilation outlets. -
Page 11: Battery Led Indications
Battery LED indications OPERATING MODE TIMEOUT LED INDICATION BATTERY DETECTION BATTERY WAITING: Battery detected while the other on GREEN: 1sec ON/1sec OFF the same pair is already charging BATTERY NOT ALLOWED BATTERY NOT ALLOWED: 10Kohm < ID resistor < 60Kohm GREEN: 500ms/RED: 500ms BATTERY EVALUATION i) Total pack voltage <... -
Page 12: Aux Output Led Indications
AUX output LED indications OPERATING MODE LED INDICATION The AUX output is correctly powered up: AUX OK: 30mA < I < 8.0A ~ 8.2A AUX LED Steady GREEN The AUX is self-protected if a load is connected and SHORT-CIRCUIT: an excessive current is absorbed: AUX LED Steady ORANGE I >... -
Page 13: Technical Specifications
1 x 220V 2.5A (5x20mm quick blow) + 1 spare Power consumption 100W max / 90W typical Operating temperature range 0°C - 45°C Storage temperature range -20°C - 65°C (-4°F - 149°F) Dimensions 250 x 145 x 80mm Weight 970g The CVTR2 underwent and has successfully passed CE certification. -
Page 14: Notes Concerning Charger Usage With Blueshape Battery Packs
The pack resumes normal charging once the temperature drops back to below 50°C. This is a safety feature incorporated in all BLUESHAPE battery packs. CVTR2 - charging performance of BLUESHAPE BV battery packs 8000 17000 7500... - Page 15 Warranty BLUESHAPE chargers are warranted to be free from defects in materials, workmanship and functionality for a period of 12 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
- Page 16 NEW CELL TOP Srl VIA LIGURIA 4-6, 42100 REGGIO EMILIA, ITALY TEL. +39 0522 518556 FAX. +39 0522 277084 WEB: www.blueshape.net EMAIL: info@blueshape.net...
