- Page 1 POWER STATION FOR V-LOCK LITHIUM ION BATTERIES ONLY Model PWS2 OPERATING INSTRUCTIONS Revision 1.1 www.blueshape.net Printed in Malta 2016...
- Page 2 With the high output power capability of the PWS2, it is to be expected and is also quite normal for the internal electronics to generate a certain amount of heat and for the internal temperature to rise to a controlled extent.
- Page 3 Package contents PWS2 two position Power Station Operating manual The unit IS NOT waterproof and not intended for usage in humid or wet environments...
- Page 4 PWS2 graphic description – Front/left side LED display for both channels 14V/ 140W max output (4 pin female XLR) 28V/ 280W max output (3 pin XLR) Illuminated power On/Off switch. The unit needs to be switched on to start operating and can be switched off even if the...
- Page 5 PWS2 graphic description – Rear/right side Ventilation outlet (slow running, low noise fan) Data connector V-Lock Battery position #2 (right) Note: The ventilation inlets are on the topside of the unit underneath the handle and also in the bottom.
- Page 6 The internal electronics are highly efficient operating at not less than 91% even when delivering full loads. Such efficiency permits the PWS2 to remain cool even after hours of continuous operation. This feature ensures a safe and prolonged system reliability and lifetime.
- Page 7 Data communication outlet (useful for firmware upgrade/ testing and calibration purposes at factory or even for future user software applications) Interpretation of the Display At least one battery on any channel must be present for the PWS2 to light up. L3 (red) L2 (g reen)
- Page 8 Full Full Note: If the batteries in use are able to communicate with the PWS2, the real current value is read directly from the battery. If the batteries in use are not able to communicate with the PWS2, an indication corresponding to the analogue value of the current is...
- Page 9 Usage with BLUESHAPE BV batteries PWS2 Recommendations Recommended 1 = least BATTERY MODEL Capacity (Wh) Max. Discharge (A) 5 = most BV065 65Wh BV090 90Wh BV100HD 94Wh BV100HD (SPLASH) 94Wh BV150 150Wh BV180 180Wh ...
- Page 10 XLR Polarity Accessories A number of cable accessories are available for connecting the PWS2 with the most popular cameras on the market. Examples: PWC33: XLR 3 pole to XLR 3 pole PWC34: XLR 3 pole to XLR 4 pole PWC44: XLR 4 pole to XLR 4 pole PWCAL: XLR 3 pole to Fischer 2 pole for ARRI...
-
Page 11: Technical Specifications
Technical specifications: Parameter Value Output Voltage #1 28V (+/- 5mV on no load, +/- 1.2% on full load) Outlet 1 x 3pin female XLR Maximum output #1 280W Output Voltage #2 14V (+/- 4mV on no load, +/- 2.4% on full load) Outlet 1 x 4pin female XLR Maximum output #2... - Page 12 Warranty BLUESHAPE Power Stations are warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
