- Page 1 INTELLIGENT BATTERY CHARGER FOR B-MOUNT LITHIUM-ION BATTERIES ONLY Model: CBTR2P - SIMULTANEOUS OPERATING MANUAL Revision 1.0 Printed in Malta 2024 www.blueshape.net...
-
Page 3: Explanation Of Symbols Used In This Manual
Read all instructions and cautionary markings in this manual and on the charger before using this product. Adhere these instructions to prevent misuse of the products and possible injury or damage to property. Keep these instructions. This manual contains important safety and operating instructions for the charger. -
Page 4: General Safety Instructions
Always refer servicing to qualified personnel. DANGER ELECTRIC SHOCK BLUESHAPE CHARGERS ARE INTENDED FOR OPERATION WITH LINE VOLTAGES BETWEEN 100V AND 264V AC AND LINE FREQUENCIES BETWEEN 43 Hz AND 60 Hz To prevent fire or shock hazard do not expose the unit to rain or moisture. - Page 5 Other types of batteries may burst, causing personal injury or damage. BLUESHAPE lithium-ion battery chargers have been designed to provide a superior performance by managing relatively high currents during their operation in order to reduce charging time. As may be...
- Page 6 The charger is also equipped with over- temperature protection. Please consult your BLUESHAPE dealer if you notice that either a charger or a battery has become excessively hot during the charging operation. Keep ventilation openings unobstructed to allow adequate airflow through the device.
- Page 7 These materials contain chemicals that can damage, weaken, or destroy plastic. CBTR2P Package Contents This device package contains the following - CBTR2P simultaneous dual position charger - AC Power Cord [according to region] Device-End Connector: IEC 60320 C13 EU Plug: IEC 884/CEE7-VII3...
-
Page 8: Graphic Description
Graphic Description Mains socket (with fuse) Fan switch (ON/OFF) Cooling fan outlet Aux output connector (28.8V 115W) 3-pin XLR Data socket B-Mount Plate (Battery installation bay #2) Carrying Handle LEDs (Bat #1, AC on/off, Bat #2) B-Mount Plate (Battery installation bay #1) 10. - Page 9 The BLUESHAPE series of intelligent lithium-ion battery chargers have been specifically designed for fast and reliable charging of BLUESHAPE batteries with the B-Mount standard and 28V nominal voltage. The charging speed depends on the type of batteries on charge since the charger communicates and acquires information from the batteries during operation.
- Page 10 *The output voltage of the auxiliary output is dependent on the battery voltage. It can therefore range between 25V up to 34V. BLUESHAPE Battery Charging and Performance Features The electronic circuitry provides a very accurate lithium-ion charge algorithm. Initially, the chargers will only apply a pre-charge current of a few mA to batteries that are heavily discharged.
- Page 11 CBTR2P Charging Performance with Fan ON Approximate charging time per channel (minutes) State of Charge (SOC)% Battery Battery Model CC rate (0.5C) Capacity 100% (mins) BB145 5Ah - 145Wh 2.5A BB145HS 5Ah - 145Wh 2.5A BB290 10Ah - 290Wh BB435...
- Page 12 Operating Instructions This device simultaneously charges two batteries with charging currents of up to 3A, depending on the battery capacity. The Li-ion batteries can be either BLUESHAPE (preferred) or any other 3 party compatible batteries can be of any capacity.
- Page 13 Insert a battery in any one of the two B-Mount Plates as indicated in the illustration on page 10. Monitor the battery LED for charge status. The BLUESHAPE battery LED array allows reading the charge status in 10% increments, or for full resolution, utilize the Bluetooth Low Energy (BLE) feature of the battery (refer to the battery operating manual for detailed instructions).
- Page 14 Using the Charger as an Auxiliary Power Supply In the case when a device is plugged into the auxiliary XLR port, the charging process may continue but can be slowed down, depending on the power taken by the AUX port that has the priority. The AUX port is always available whenever AC is connected.
-
Page 15: Battery Led Indications
Battery LED Indications Indication Description Steady Red There is no AC present Steady Green There is AC present Bat #1 or Steady Green Battery is full Bat #2 Bat #1 or Channel is idle and ready to charge and/or Flashing Green Bat #2 supply AUX The battery is in charge and is charging at... -
Page 16: Technical Specifications
Available Overtemperature protection Available Charging current and voltage regulated according to Special features battery capacity for BLUESHAPE or compatible batteries only Power supply AC mains 100V - 264V ~ universal,47 - 63 Hz, 1000W Fuse 1 x 250V-2.5A + 1 spare... - Page 17 Concerning Charger Usage with BLUESHAPE Battery Packs It is recommended that the users always have at least another spare battery readily available. It is preferable to charge batteries immediately before use. Some self-discharge would result if the batteries are charged several weeks in advance of their use.
-
Page 18: Disposal Instructions
Disposal Instructions When the equipment has reached the end of its life please dispose of the components in accordance with your local waste directive in your country. Electronic equipment should be recycled wherever possible and not disposed of with regular waste. -
Page 19: Warranty
Warranty BLUESHAPE chargers are warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation. - Page 20 ® BLUESHAPE is a registered trademark of: NEW CELL TOP Srl Via Liguria 4-6, 42124 Reggio Emilia, ITALY TEL.: +39 0522 518556 WEB: www.blueshape.net EMAIL: info@blueshape.net...
