- Page 1 INTELLIGENT BATTERY CHARGER FOR V-LOCK LITHIUM ION BATTERIES ONLY Model CVS4XL - Simultaneous Quad Position Charger with Touch Display and Auxiliary Power Output USER MANUAL Revision 1.0 www.blueshape.net Printed in Malta 2020...
- Page 3 Keep these instructions. This manual con- tains important safety and operating instruc- tions for the CVS4XL charger. Explanation of symbols used in this manual This symbol indicates the presence of an electrical shock hazard.
-
Page 4: General Safety Instructions
TO AVOID ELECTRIC SHOCK, DO NOT OPEN THE APPA- RATUS AND ALWAYS REFER ANY SERVICING TO QUALI- FIED PERSONNEL. BLUESHAPE CHARGERS ARE INTENDED FOR OPERATION WITH LINE VOLTAGES BETWEEN 100V AND 240V AC AND LINE FREQUENCIES BETWEEN 47Hz AND 63 Hz. - Page 5 Other types of batteries may burst, causing personal injury or damage. BLUESHAPE lithium-ion battery chargers have been designed to provide a superior performance by managing relatively high currents during their operation in order to reduce charging time. As may be expected, the chargers become warm to the touch during operation.
- Page 6 Do not handle charger, including the charger plug and charger terminals with wet or damp hands. Use of an attachment not recommended or sold by the battery- charger manufacturer may result in a risk of fire, electric shock, or injury to persons.
- Page 7 CVS4XL Package Contents CVS4XL CVS4XL simultaneous quad position charger with Aux out- put and Touch Display AC power cord [according to region] CORDAGE: H05VV-F, 3 x 1.0mm, UNSHIELDED CEE COLOR CODE, TEMP. RATING 60°C RATING: 250V 10A JACKET COLOR: BLACK...
- Page 8 CVS4XL Graphic Description 3.5” Touch Display USB Charging Port Data socket (for computer connectivity and FW upgrades if needed) Mains socket with fuse Mains switch with indicator lamp Exhaust Ventilation Auxiliary power XLR 4pin V-Lock battery bay #1 V-Lock battery bay #2...
- Page 9 The CVS4XL is capable of delivering up to a maximum of 6 Amps in constant current (CC) mode on all four channels simultaneously.
- Page 10 If the battery is placed on charge, the AUX power will be derived from both mains and battery if necessary. Data receptacle via USB Micro-B for computer connectivity and monitoring of BLUESHAPE batteries through BSCVMON free software, directly downloadable from our website. Note: USB Micro-B cable not included with product.
- Page 11 After the constant current (CC) phase is completed, a constant voltage (CV) phase initiates with the current tapering slowly to 150mA until full cut-off. CVS4XL charging performance with fan set to ‘ON’ Approximate charging time per channel (minutes) State of Charge (SOC)%...
-
Page 12: Charging Li-Ion Batteries
This device simultaneously charges four batteries with charging currents of up to 6A, depending on the battery capacity. The batteries to be charged are V-Lock batteries, which can be BLUESHAPE (preferred) or any other 3 party compatible batteries can be of any capacity ranging from: ... - Page 13 CVS4XL When no battery is connect- ed or detected in a battery bay ‘NO BAT’ is shown in the battery status. ...
- Page 14 This may be done if silent operation of the CVS4XL is required. For charging performance as determined by fan state, refer to the technical speci- fication table in this manual.
- Page 15 Tapping on the cog icon on the main screen will show gen- eral charger status and information. Display backlight bright- ness can be adjusted via the slider at the bottom of the screen. CVS4XL Serial Number 99999 dd-mm-aaaa Mfg date Fw version 1.xx-1.xx-1.xx...
- Page 16 When a device is powered by the AUX port and at least a battery is installed, the unit operates as an UPS: in case of a sudden AC power cut, the device remains powered if at least a battery is installed and its voltage is higher than 12500mV.
- Page 17 The fan icon is also replaced by a power icon to be able to shutdown the charger when not being used as an auxiliary power supply. Tap to shutdown CVS4XL charger Tapping on the power icon will switch off the charger. To restart the charger power the charger via an AC input or disconnect and reconnect all battery packs.
-
Page 18: Technical Specifications
Overtemperature protection Available USB Charge Output 5V, 2.0A Max. Charging current and voltage regulated according to battery capacity for BLUESHAPE or compatible batteries Special features only AC mains 100V - 240V ~ 47 - 63 Hz autoselect Power supply Fuse 1 x 220V 2.5A (5x20mm quick blow) + 1 spare... -
Page 19: Notes Concerning Charger Usage With Blueshape Battery Packs
Notes Concerning charger usage with BLUESHAPE battery Packs It is recommended that the users always have at least another spare battery readily available. It is preferable to charge batteries immediately before use. Some self-discharge would result if the batteries are charged several weeks in advance of their use. - Page 20 DISPOSAL When the equipment has reached the end of its life please dispose of the components in accordance with your local waste directive in your country. Electronic equipment should be recycled wherever possible and not disposed of with regular waste.
-
Page 21: Warranty
Warranty BLUESHAPE chargers are warranted to be free from defects in mate- rials, workmanship and functionality for a period of 18 months com- mencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal condi- tions of operation. - Page 22 This page is intentionally left blank.
- Page 24 NEW CELL TOP Srl VIA LIGURIA 4-6, 42124 REGGIO EMILIA, ITALY TEL. +39 0522 518556 FAX. +39 0522 277084 WEB: www.blueshape.net EMAIL: info@blueshape.net...
