- Page 1 INTELLIGENT BATTERY CHARGER FOR 3-STUD LITHIUM ION BATTERIES ONLY Model CGTR2P - SIMULTANEOUS OPERATING INSTRUCTIONS Revision 1.0 www.BLUESHAPE.net Printed in Malta 2019...
- Page 2 Please read these instructions concerning your safety BLUESHAPE lithium-ion battery chargers have been designed to provide a superior performance by managing relatively high currents during their operation in order to reduce charging time. As may be expected, the chargers become warm during operation and it is therefore very important to keep their ventilation openings unobstructed.
-
Page 3: Additional Safety Notes
In the case when the UK plug is fitted, this plug is equipped with a 13A replaceable fuse. Package contents - CGTR2P simultaneous dual position charger with Aux output - AC power cord [according to region] - Safety operating instructions... - Page 4 CGTR2P graphic description Mains socket with fuse Fan switch (on/off) Cooling fan outlet Auxiliary power XLR 4pin Data socket (for computer connectivity and FW upgrades if needed) 3-Stud battery #2 installation bay Carrying handle Battery release button LEDs (Bat #1, AC on/off, Bat #2) 10.
- Page 5 The CGTR2P is capable of delivering up to a maximum of 6 Amps in constant current (CC) mode on both channels simultaneously.
- Page 6 Data connector for computer connectivity and monitoring of BLUESHAPE batteries through BSCVMON free software, directly downloadable from our website Note: The special data cable is not included in the kit but is available as a separate product.
- Page 7 CGTR2P charging performance CGTR2P charging performance with fan set to ‘ON’ Approximate charging time per channel (minutes) State of Charge (SOC)% Battery Model Battery Capacity CC rate (0.5C) 90% (mins) 100% (mins) BG095HDmini 6.6Ah - 95Wh 3.3A BG140HDmini 9.9Ah - 143Wh 4.95A...
- Page 8 Insert a battery inside any one of the two battery bay Observe the battery LED. In addition, the charge status may be read in 20% steps through the BLUESHAPE battery LED array or continuously, using the Wi-Fi features of the battery (see the battery operating manual for the activation of the internal Wi-Fi transmitter).
- Page 9 AUX port management The AUX port is always available whenever AC is connected or at least one battery is present and with a voltage greater than 12500mV. Working without AC When operating without AC the available power on the AUX port is limited by the power of the installed batteries but up to a controlled maximum of 8A.
-
Page 10: Battery Led Indications
Battery LED indications INDICATION EXPLANATION Steady Red There is no AC present Steady Green There is AC present Bat #1 Steady Green Battery is full Bat #2 Bat #1 AC is not present and the blinking channel is ready to Flashing Green power or is actually powering the load on the AUX port Bat #2... -
Page 11: Technical Specifications
LEDS 3-colour type for Bat #1, Bat #2, AC Charging current and voltage regulated according to Special features battery capacity for BLUESHAPE or compatible batteries only Power supply AC mains 100V - 240V ~ 47 - 63 Hz autoselect Fuse 1 x 220V 2.5A (5x20mm quick blow) + 1 spare... -
Page 12: Notes Concerning Charger Usage With Blueshape Battery Packs
Notes concerning charger usage with BLUESHAPE battery packs It is recommended that the users always have at least another spare battery readily available. It is preferable to charge batteries immediately before use. Some loss from self-discharge would result if the batteries are charged several weeks in advance of their use. - Page 13 This page has been intentionally left blank...
- Page 14 This page has been intentionally left blank...
- Page 15 Warranty BLUESHAPE chargers are warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
- Page 16 NEW CELL TOP Srl VIA LIGURIA 4-6, 42124 REGGIO EMILIA, ITALY TEL. +39 0522 518556 FAX. +39 0522 277084 WEB: www.BLUESHAPE.net EMAIL: info@BLUESHAPE.net...
