- Page 1 INTELLIGENT BATTERY CHARGER FOR B-MOUNT LITHIUM-ION BATTERIES ONLY Model: CBS8XW - WALL MOUNT OPERATING MANUAL Revision 3.0 Printed in Malta 2024 www.blueshape.net...
-
Page 3: Explanation Of Symbols Used In This Manual
Read all instructions and cautionary markings in this manual and on the charger before using this product. Adhere these instructions to prevent misuse of the products and possible injury or damage to property. Keep these instructions. This manual contains important safety and operating instructions for the charger. -
Page 4: General Safety Instructions
DANGER ELECTRIC SHOCK BLUESHAPE CHARGERS ARE INTENDED FOR OPERATION WITH LINE VOLTAGES BETWEEN 100V AND 264V AC AND LINE FREQUENCIES BETWEEN 43Hz AND 60 Hz To prevent fire or shock hazard do not expose the unit to rain or moisture. - Page 5 Other types of batteries may burst, causing personal injury or damage. BLUESHAPE lithium-ion battery chargers have been designed to provide a superior performance by managing relatively high currents during their operation in order to reduce charging time. As may be...
- Page 6 The charger is also equipped with over- temperature protection. Please consult your BLUESHAPE dealer if you notice that either a charger or a battery has become excessively hot during the charging operation. Keep ventilation openings unobstructed to allow adequate airflow through the device.
- Page 7 These materials contain chemicals that can damage, weaken, or destroy plastic. CBS8XW Package Contents This device package contains the following - CBS8XW wall-mount charger - Wall Hanging Bracket - AC Power Cord [according to region] Device-End Connector: IEC 60320 C13...
- Page 8 This charger comes in three different model variants: CVS8XW: For v-lock lithium-ion batteries only CGS8XW: For 3-stud lithium-ion batteries only CBS8XW: For b-mount lithium-ion batteries only To clarify your model, check the front panel markings as illustrated below. CVS8XW...
-
Page 9: Graphic Description
Graphic Description CBS8XW - Front View The Charger front facing panel consists of the following: B-Mount Battery charging bays 3.5” Touch Display Mains switch Aux output connector (28.8V 115W) 3-pin XLR... - Page 10 CVS8XW - Side View The Charger frame consists of the following: Ventilation Outlets Carrying Handle Data connector AC mains input, 100-264V Ventilation Inlets Wall Hanging Bracket (refer to page 9) Supporting lateral studs...
-
Page 11: Installation
Installation This charger is designed to ideally be installed on a wall. Find a suitable location allowing for easy access, ensuring that the ventilation inlets/outlets are free from any obstruction. Fix the mounting bracket against the wall, using suitable screws and/or fittings. - Page 13 The BLUESHAPE series of intelligent lithium-ion battery chargers have been specifically designed for fast and reliable charging of BLUESHAPE batteries. The charging speed depends on the type of batteries on charge since the charger communicates and acquires information from the batteries during operation. The charger is capable of delivering up to a maximum of 3Amps in constant current (CC) mode on all eight channels simultaneously.
- Page 14 It will range from 28.8V up to 34V with no battery, Aux fixed at 28.8V. BLUESHAPE Battery Charging and Performance Features The electronic circuitry provides a very accurate lithium-ion charge algorithm.
- Page 15 CBS8XW Charging Performance with Fan ON Approximate charging time per channel (minutes) State of Charge Battery (SOC)% Battery Model CC rate (0.33C) Capacity 100% (mins) BB145 5Ah -145Wh 1.65A BB145HS 5Ah -145Wh 1.65A BB290 10Ah - 290Wh BB435 15Ah - 435Wh...
- Page 16 This device simultaneously charges eight batteries with charging currents of up to 3A, depending on the battery capacity. The Li-ion batteries can be either BLUESHAPE (preferred) or any other 3 party compatible batteries of any capacity. The charger will automatically select the charging rate to apply.
- Page 17 charging page will show the status of the eight bays independently. When no battery is connect- ed or detected in a battery bay ‘NO BAT’ is shown in the battery status. When a battery is detected, a throbber indicates battery communication initialisation.
- Page 18 During charging mode, the fan state can be toggled by tapping on the fan icon in the main screen. This may be done if silent operation of the CBS8XW is required. For charging performance determined by fan state, refer to the technical specification table in this manual.
- Page 19 Diagnostic page shows additional battery pack information which may be helpful with battery pack troubleshooting. Tapping on the cog icon on the main screen will show gen- eral charger status and information. Display backlight bright- ness can be adjusted via the slider at the bottom of the screen.
- Page 20 Using the Charger as an Auxiliary Power Supply In the case when a device is plugged into the auxiliary XLR port, the charging process may continue but can be slowed down, depending on the power taken by the AUX port that has the priority. The AUX port is only available whenever AC is connected.
-
Page 21: Technical Specifications
Available Overtemperature protection Available Charging current and voltage regulated according to Special features battery capacity for BLUESHAPE or compatible batteries only Power supply AC mains 100V - 264V ~ universal,47 - 63 Hz, 1000W Fuse 1 x 250V-2.5A + 1 spare... - Page 22 Concerning Charger Usage with BLUESHAPE Battery Packs It is recommended that the users always have at least another spare battery readily available. It is preferable to charge batteries immediately before use. Some self-discharge would result if the batteries are charged several weeks in advance of their use.
-
Page 23: Disposal Instructions
Disposal Instructions When the equipment has reached the end of its life please dispose of the components in accordance with your local waste directive in your country. Electronic equipment should be recycled wherever possible and not disposed of with regular waste. -
Page 24: Warranty
Warranty BLUESHAPE chargers are warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation. - Page 26 ® BLUESHAPE is a registered trademark of: NEW CELL TOP Srl Via Liguria 4-6, 42124 Reggio Emilia, ITALY TEL.: +39 0522 518556 WEB: www.blueshape.net EMAIL: info@blueshape.net...
