- Page 1 INTELLIGENT BATTERY CHARGER FOR V-LOCK LITHIUM ION BATTERIES ONLY Model CVS8X OPERATING INSTRUCTIONS Revision 1.0 www.blueshape.net Printed in Malta 2009...
-
Page 2: This Equipment Must Be Earthed
Please read these instructions concerning your safety BLUESHAPE lithium-ion battery chargers have been designed to provide a superior performance by managing relatively high currents during their operation in order to reduce charging time. As may be expected, the chargers become warm during operation and it is therefore very important to keep their ventilation openings unobstructed. - Page 3 BLUESHAPE CHARGERS ARE INTENDED FOR OPERATION WITH LINE VOLTAGES BETWEEN 100V AND 240V AC AND LINE FREQUENCIES BETWEEN 43Hz AND 60 Hz The equipment is being supplied with a compatible AC mains power cord.
- Page 4 CVS8X graphic description – Front/right side Battery LED indicators (see page 12 for explanation) AUX output LED indicator (see page 13 for explanation) LCD keys LCD display Carrying handle Ventilation inlets Release buttons Battery #3 and #4 charging bays (Battery #1 and #2 charging...
- Page 5 CVS8X graphic description – Rear/left side Ventilation outlets Data connector AUX output connector (13.8V 110W) Ventilation inlets Release buttons Battery #1 and #2 charging bays (Battery #3 and #4 charging bays are on opposite side) AC Mains input, 100V-240V Mains switch...
- Page 6 Introduction The BLUESHAPE series of intelligent lithium ion battery chargers has been specifically designed for fast and reliable charging of the BLUESHAPE V-lock battery range. All charger models are capable of delivering up to 4.9Amps in constant current mode making them particularly suitable to users who require a fast turnaround from their batteries.
- Page 7 Li-Ion charger in the broadcasting sector. This results in currently the shortest possible battery charging time. BLUESHAPE Li-Ion BV battery series allow fast charging due to several intrinsic features such as pre-charge protection and cell balancing; avoiding cell damage and life-cycle shortening, as demonstrated by the life-cycle performances.
-
Page 8: Ctp: Flexibility Of Operation And Charger Reliability
CTP: flexibility of operation and charger reliability Due to the high charging currents developed by the CVS8X charger, heat control is an issue for a travel charger, especially if the travel charger is used in potentially hot environments such as inside a car or a van. - Page 9 Insert in the direction of the arrow Observe the LED. In addition, the charge status may be read in 20% steps through the BLUESHAPE battery LED array. Leave the battery to charge for the appropriate time (see table on page 6)
- Page 10 ADDITIONAL SAFETY NOTES Chargers and/or batteries may become hot during charging. This is normal. Please consult your BLUESHAPE dealer if you notice that either a charger or a battery, become excessively hot during the charging operation. Be careful not to block the equipment’s ventilation outlets.
- Page 11 Please note: When batteries other than Blueshape are installed, the information displayed may not be accurate. Pressing the 'INFO' button permits quick browsing through the information.
-
Page 12: Battery Led Indications
Battery LED indications OPERATING MODE TIMEOUT LED INDICATION BATTERY DETECTION BATTERY WAITING: Battery detected while the other on GREEN: 1sec ON/1sec OFF the same pair is already charging BATTERY NOT ALLOWED BATTERY NOT ALLOWED: 10Kohm < ID resistor < 60Kohm GREEN: 500ms/RED: 500ms BATTERY EVALUATION i) Total pack voltage <... -
Page 13: Operating Mode
AUX output LED indications OPERATING MODE LED INDICATION The AUX output is correctly powered up: AUX OK: 10mA < I < 8.2A AUX LED Steady GREEN The AUX is self-protected if a load is connected and an SHORT-CIRCUIT: excessive current is absorbed: AUX LED Steady ORANGE I >... -
Page 14: Technical Specifications
Technical specifications Constant current and voltage control system with timer Type interventions CC-MODE: Output current 4900mA ± 1% CC-MODE: Vmax 16800 ± 50mV (0.3%) CV-MODE: Vmax 16800 ± 50mV (0.3%) CV-MODE: Cutoff current 150mA ± 10mA Short circuit protection Available Overcharge protection Available Overtemperature protection... -
Page 15: Notes Concerning Charger Usage With Blueshape Battery Packs
Notes concerning charger usage with BLUESHAPE battery packs It is recommended that the users always have at least another spare battery readily available. It is preferable to charge batteries immediately before use. Some loss from self-discharge would result if the batteries are charged several weeks in advance of their use. -
Page 16: Warranty
Warranty BLUESHAPE chargers are warranted to be free from defects in materials, workmanship and functionality for a period of 12 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
