INSTRUCTION MANUAL
Spray Gun with Agitator Cup
W-101A
This manual contains IMPORTANT WARNINGS and INSTRUCTIONS.
Equipment in this manual is exclusively for painting purposes.
Do not use for other purposes.
The operator shall be fully conversant with the requirements stated in this
instruction manual including important warnings, cautions and operation and
correct handling.
Read and understand the instruction manual, before use and retain for
reference.
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing organic solvent.
Be sure to observe following
Indicates a potentially hazardous situation which, if not avoided, may result in serious injury or loss of life.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury or property
damage.
Indicates notes which we ask you to observe. The safety precautions in this instruction manual are the minimum
necessary conditions. Follow national and local regulations regarding fire prevention, electricity and safety as well as
your own company regulations.
Important specifications
■
Max. Pressure ０ ． ６ ８ Ｍ Ｐ ａ / ６ ． ８ b a r / ９ ８ Ｐ Ｓ Ｉ
Noise level
７ １ ． ５ ｄ Ｂ （ Ａ ）
Spray condition Recommended
Measuring point 1m backwards from gun , 1.6ｍ height
Main specifications
■
Type of
Model
feed
W-101A-104G 1.0 (0.039)
Gravity
W-101A-134G
1.3 (0.051)
W-101A-134S Suction
※1. Atomizing air pressure means air pressure at gun inlet when trigger is pulled and air flows．
※2. Tested with 12 sec./NK-2 automotive repair paint

Parts List

■
№
Description
1 Air cap set
◆
2 Fluid nozzle-fluid
◆
needle set
2-1 Fluid nozzle
◆
2-2 Fluid needle set
◆
25 Needle packing set
5 Body set
5-1 Air nipple
5-2 Fluid nipple
6 Pattern adj. set
6-1 Stopper
6-2 Washer
6-3 Back ring
◆
7 Air valve seat set
◆
7-1 O ring
◆
8 Air valve
9 Air valve spring
11 Fluid needle spring
◆
13 Air valve shaft
14 Air adj. set
15 Trigger stud
16 Trigger
17 E stopper
18 Brush
19 Instruction manual
◆ Marked parts are wearable parts.
marked items which are especially important.
※1 Atomizing
Nozzle
Air cap
orifice air pressure
set
φmm(in)
bar (PSI)
W-101
1.5 (21)
H4
№
Q'ty
1 20 Tube
1 21 Air motor lid set
1 22 Container (for suction feed)
or cup (for gravity feed)
1 23 Fluid adj. set
1 24 Air adj. set for air motor
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
和文取説は、 裏面にあり ます
Max. Temperature
Atmosphere
５ ℃∼４ ０ ℃
Air・Fluid
５ ℃∼４ ３ ℃
Fluid Air
output consumption
ml/min l/min(cfm)
90 165(6.5)
180 (6.4)
110 180(7.1)
100 170(6.7)
Description Q'ty
1
1
1
1
1
- 1 -
Pattern
Air & fluid
Width
Connection
mm(in)
(Air)G1/4(NPS1/4)
(Fluid)G1/4(NPS1/4) 775(1.71)
Weight
Remarks
g(lbs)
With
695(1.53)
agitator
cup
