- Page 1 Platinum CCTV Surveillance Solutions AD-2000 CCD Armor Dome Camera Installation Manual Indoor/Outdoor Vandal-Resistant CCD Armor Dome 480 TVL Camera w/ 3.6mm Wide-Angle Lens For Warranty Registration, visit http://Platinum-CCTV.com...
-
Page 2: Camera Installation
Platinum CCTV Surveillance Solutions Camera Installation Camera Mounting: Items Needed: Screwdriver, Drill, Mounting Hardware (not included), Glove or Cloth for moving Dome, Pencil Remove Dome Mark wall through Mounting Holes Drill Holes for mounting Drill Hole for Cables... - Page 3 Platinum CCTV Surveillance Solutions Camera Installation Connect Cables Top = BNC Video Connector Bottom = Power Connector Insert Drywall Anchors (Drywall Mounting Only *Not Included) Insert Screws Adjust camera angle to suit needs Reinstall Dome...
-
Page 4: Installation Notes
Platinum CCTV Surveillance Solutions AD-2000 CCD Color Dome Camera Image Sensor Sony 1/3” CCD Sensor Number of Pixels NTSC: 620 (H) x 492 (V) Lens 3.6mm (~92 degrees) Sync System Internal Synchronization Resolution 480 TVL Dimensions 108mm (D) x 74mm (H) Video Output 1.0Vp-p75Ω...
