- Page 1 Platinum CCTV Surveillance Solutions CD-0245 CCD Indoor Dome Camera Installation Manual High-Resolution 1/4” Color CCD Indoor Mini-Dome Camera w/420 TVL Http://Platinum-CCTV.com...
-
Page 2: Camera Installation
Platinum CCTV Surveillance Solutions Camera Installation Camera Mounting: Items Needed: Screwdriver, Drill, Mounting Hardware, Glove or Cloth for moving Dome, Pencil Remove Dome Mark wall through Mounting Holes Drill Holes for mounting Drill Hole for Cables... - Page 3 Platinum CCTV Surveillance Solutions Camera Installation Connect Cables Top = BNC Video Connector Bottom = Power Connector Insert Drywall Anchors (Drywall Mounting Only) Insert & Tighten Screws Adjust camera angle to suit needs Reinstall Dome...
-
Page 4: Installation Notes
Platinum CCTV Surveillance Solutions CD-0245 CCD Color Dome Camera Image Sensor ¼” Color CCD Sensor Number of Pixels NTSC: 568 (H) x 494 (V) Lens 3.6mm Sync System Internal Synchronization Resolution 420 TVL Dimensions 70mm (D) x 50mm (H) Video Output 1.0Vp-p75Ω...
