- Page 1 Platinum CCTV Surveillance Solutions CD-9255 SONY Indoor/Outdoor Day/Night Long-Range Infrared Camera Installation Manual Outdoor Weatherproof Day/Night Infrared CCD Bullet Camera Http://www.Platinum-CCTV.com...
-
Page 2: Camera Installation
Platinum CCTV Surveillance Solutions Camera Installation Camera Mounting: Items Needed: Screwdriver, Drill, Mounting Hardware (not included), Pencil Mark wall through Mounting Holes on bracket Drill Holes for mounting Drill Hole for Cables (if needed) Insert Screws holding bracket to wall... - Page 3 Platinum CCTV Surveillance Solutions Camera Installation Connect Cables Left side = Power Connection Right side = BNC Video Connection...
-
Page 4: Installation Notes
Platinum CCTV Surveillance Solutions CD-9255 Long Range IR CCD Camera Image Sensor 1/3” SONY Interline Transfer CCD Number of Pixels NTSC: 540 (H) x 491 (V) Scanning System 15.7343Khz (H), 60 Hz (V) Sync System Internal Synchronization Resolution 420 TVL...
