- Page 1 Platinum CCTV Surveillance Solutions http://Platinum-CCTV.com http://Platinum-CCTV.com Camera Installation Manual Ver 1.0 Pan, Tilt and Zoom Dome Camera / PTZ-...
- Page 2 Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
-
Page 3: Table Of Contents
5.2 Alnet™ PC-Based DVR Cards/Software 5.3 PTZ-KEY Controller Keyboard Function Settings 6.1 Preset Settings 6.2 Scan Settings 6.3 Pattern Settings 6.4 Tour Settings 6.5 Zone Settings 6.6 Time Running Settings Troubleshooting Warranty Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... - Page 4 Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
-
Page 5: Precautions
Don’t place the camera to directly view any strong lights. Don’t ever point the camera into direct sunlight, doing so can cause the image sensor to burn and will void the camera’s warranty. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... -
Page 6: Dome Performance
Auto Gain Control Signal to Noise >60 dB Shutter Auto: 1/50 – 1/120,000 sec Lens 10x optical zoom 3.8~38.0mm (F1.8~4.2) Video Output Coaxial Video Output, 1.0Vp-p Environmental Temperature C to 45 ° ° Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... -
Page 7: Dome Performance And Features
Dome Performance Dome Performance and Features The PTZ-2201-10 PTZ Dome camera is a high-tech surveillance product with a high definition Sony CCD Image sensor, variable speed Pan/Tilt and zoom capabilities with a built-in multi-protocol RS-485 decoder. This camera is designed for reliable operation, and can provide many years of reliable service in home or business security camera installations. -
Page 8: Dome Features
Iris by a PTZ Controller keyboard using the “Open/Close” key or through a DVR with RS-485 PTZ Controls. User can reassume Auto-Iris control by simply moving the camera again using the joystick. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... -
Page 9: Pattern Tour
The user can set up the PTZ-2201 camera to scan between a left and right point smoothly. This function is popular for a continuous back and forth scanning motion to view around corners and more. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... -
Page 10: Camera Installation
Locate the Ceiling mount plate and mark the mounting holes on your ceiling. 2. Mount the threaded ceiling adapter to the camera with included 3 screws. Be sure to line up the spline in the adapter to the groove on the camera. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... -
Page 11: Wall Mount Bracket
Wall Mount Bracket The PTZ-2201-10 mini PTZ dome camera also comes with a Wall Mount bracket. To install the wall mount bracket, follow these easy steps Locate the wall mount bracket and remove the 4 allen screws to remove the wall adapter plate from the bracket 2. - Page 12 4. Mount the camera to the wall mount arm with 3 included Phillips head screws 5. Mount the wall mount arm to the adapter plate and secure with the 4 Allen screws removed previously. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
-
Page 13: Connect Cables
2. Connect the power connector to the power conductor of your security camera power/video cable (center pin positive). 3. Connect the BNC Video conductor from your CCTV Power/Video cable to the BNC video connector on the camera. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... -
Page 14: Set Address On Camera
The following chart will show you the settings for each of the dip switches to set the camera to PELCO-D 2400 baud with an address of 1-8. Address Dipswitch Settings (DIPs 1-6) Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... - Page 15 Camera Installation Baud Rate adjustment: Baud Rate Dip 7 Dip 8 2400 bps 4800 bps 9600 bps 1200 bps Protocol adjustment: Protocol DIP 9 DIP 10 PELCO-D PELCO-P Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
-
Page 16: Ptz Camera Control
DVR or Controller DVR-700x Series H.264 Standalone DVR (Platinum CCTV™ Brand) Our Platinum CCTV™ brand DVR-7004, DVR-7008 and DVR-7016 series H.264 Standalone DVRs provide you with PTZ camera controls built-in, allowing you to control your PTZ-2201 camera from your DVR with a mouse, remote control, or even over the internet from your PC, Laptop, iPhone™, Android™... -
Page 17: Alnet™ Pc-Based Dvr Cards/Software
Protocol (with baud rate), and then enter the address for the camera. Also click on the Enable button so it is highlighted in red, then click close to apply. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... - Page 18 PTZ camera using the up/down/left/right of the joystick, and twisting the joystick for zoom. With any other PTZ keyboard, consult the keyboard manual to set Address, Protocol and Baud rate to match. Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
-
Page 19: Ptz-Key Controller Keyboard
6.1.2 DVR-700x H.264 Standalone DVR – DVRCMS PC software With the Platinum CCTV™ DVR-700x series H.264 Standalone DVR, you can configure and recall preset positions using the DVR CMS software for the PC. Open up your DVRCMS software and connect to your DVR. - Page 20 3. Now once you are done moving the camera, it will wait the amount of time defined before moving to home (when home is enabled). Home Position Delays: Time (sec) Preset # Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
-
Page 21: Pattern Settings
Programming the Pattern Tour: 1. Use the Set Preset (6.1) to set preset #240 2. This will clear all memory on the camera 3. Cycle power to the camera Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... -
Page 22: Troubleshooting
• Use a soft dry cloth or microfiber cloth to clean inside and outside dome covers. • Use mild LCD cleaners if necessary to dissolve any difficult to remove materials Pan, Tilt and Zoom Dome Camera / PTZ-2201-10... - Page 23 B. One wire of RS-485 B. Replace RS485 wires bus is broken C. Add Termination C. The dome is far from resistors controller D. Install RS-485 D. There are too many distributor domes connected Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
-
Page 24: Warranty
The factory will not bear any responsibility for special, unexpected or continued damage for any reason • The manufacturer has the final right of explanation for the above terms Pan, Tilt and Zoom Dome Camera / PTZ-2201-10...
