WARNING: Maintain the
minimum clearances
i n F i g u r e 4 . I f
provide greater clearances from
floor, ceiling, and joining wall.
Figure 4 -Mounting Clearaances
As Viewed From Front Of Heater
IMPORTANT:
heaters add moisture to
air. Although this is beneficial,
installing heater
without enough ventilation air
may cause mildew to
from too much moisture. See
Fresh Air for Combustion and
Ventilation, pages 4 and 5.
INSTALLING THERMOSTAT
SENSING BULB
For MN300TGA
1. Pull out the sensing bulb from the
two clips located in the shippng
position according to the direction
as shown by the arrow. There is no
need to take out the two bulb clips.
2. Take out the bulb clip from the
hardware package and insert it into
the square hole and then insert the
sensing bulb into the bulb clip (see
Figure 5).
Figure 5 - Moving Thermostat
Sensing Bulb
For replacement parts contact:
INSTALLATION
FASTENING HEATER TO WALL
Mounting Bracket
shown
The mounting bracket is located
y o u c a n ,
on back panel of heater (see
figure 6). It has been taped there
for shipping. Remove mounting
bracket from back panel.
Figure 6 -Mounting Bracket
Location
Removing Lower Front Panel Of
Heater
1. Remove two screws near bottom
corners of lower front panel .
2. Pull bottom of lower front panel
Vent-free
forward, then down (see Figure 7).
the
in rooms
form
Figure 7 - Removing Lower Front
Panel Of Heater
Methods For Attaching Mounting
Bracket To Wall
Only use last hole on each end
of mounting bracket to attach
bracket to wall. These two holes
are 16 inches apart from their
centers. Attach mounting bracket
to wall only in one of two ways:
1. Attaching to wall stud
2. Attaching to wall anchor
Attaching to Wall Stud: This method
provides the strongest
mounting screws through mounting
bracket
Attaching to Wall Anchor: This
method
mounting bracket to hollow walls
(wall areas between studs) or to
solid walls (concrete or masonry).
Decide which method better
your needs. Either method
provide a secure
mounting bracket.
Marking Screw Locations
1. Tape mounting bracket to wall
where heater will be located.
Make sure mounting bracket is
level.
2.
wall. (see Figure 8)
Note: Only mark last hole on
each end of mounting bracket.
Insert mounting screws through
these holes only.
3.
bracket from wall.
Model MN300HGA MN300TGA
7
www.PartsFor.com 1-800-446-1446
and into wall
allows you
hold for the
