NOBO PANEL RADIATORS
SERIES '14' TYPE 'E4E GB' PANEL RADIATORS
Six sizes 500 to 2000 watt
o
Electronic Thermostatic control
o
Adjustable scale 5 - 30°C.
o
On - Off switch
o
Over-heat Cut-Out
o
White paint finish RAL 9010
o
Classified IP 24
o
Flex connection 1.9m (RH side)
o
Electronic proportional temperature regulation
o
Variety of Plug-In Control options:
o
E4E GB 2000
E4E GB 1500
E4E GB 1250
E4E GB 1000
E4E GB 750
E4E GB 500
475
625
775
Telephone: 0121 328 5671
Facsimile: 0121 327 8580
Series 8 'R80' plug & play technology.
D
D
C
B
A
975
1125
1525
A
B
C
D
E
400
E
Wall Bracket fixing centres
L
200
300
200
400
600
1000
70
100
Min. Clearance
70
Min. Clearance
L
Series 14 - E4E GB - Dims. txt - 1403
110
62
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for NOBOCOOL E4E GB 2000
Summary of Contents for NOBOCOOL E4E GB 2000
- Page 1 Classified IP 24 Flex connection 1.9m (RH side) Electronic proportional temperature regulation Variety of Plug-In Control options: Series 8 'R80' plug & play technology. E4E GB 2000 E4E GB 1500 E4E GB 1250 E4E GB 1000 E4E GB 750 Min. Clearance E4E GB 500 Min.
- Page 2 NOBO CABLE CONTROL CONTROL MODULE type R80 ZDC designed for use with NOBO Panel heaters using Series 8 controls. Temperature control module. A Control module with adjustable economy & comfort settings, suitable for dual temperature applications. supplied with pilot wire for switching between temperature modes.
- Page 3 NOBO CABLE CONTROL H27Z Power: 230 - 240 volts AC Contacts: 3 amps at 240 volts Enclosure: Double Insulated - IP30 Dimensions: 101 x 163 x 33 Mounting: Wall surface mounted Battery: 10 months Switch: 3 on and 3 off per day Override: 1 or 2 hours boost Heating 2 Zone 7 day Time Control Unit.
