- Page 1 INSTRUCTION MANUAL Nobo Wi-Fi Panel Heater Models: NTL4R 10 | NTL4R 15 I NTL4R 20 | NTL4R 24 For domestic household use only.
-
Page 2: Important Safety Advice
IMPORTANT SAFETY ADVICE THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your panel heater for the first time and keep them in a safe place. -
Page 3: Child Safety
WARNING - THE SURFACES ON THIS HEATER CAN BE HOT. The heater carries a warning symbol to alert the user to the risk of fire that exists if the heater is accidentally covered. CAUTION - Some parts of this product can become very hot and cause burns. - Page 4 IMPORTANT SAFETY ADVICE THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your panel heater for the first time and keep them in a safe place.
- Page 5 WARNING - THE SURFACES ON THIS HEATER CAN BE HOT. The heater carries a warning symbol to alert the user to the risk of fire that exists if the heater is accidentally covered. CAUTION - Some parts of this product can become very hot and cause burns.
-
Page 6: Operating Warnings
OPERATING WARNINGS IMPORTANT: Remember to observe all safety warnings and precautions when operating the heater on the automatic or timer modes, either attended or unattended since a fire risk exists when the heater is accidentally covered or displaced. CAUTION: Do not use if the heater’s main power lead is damaged. If the supply cord is damaged it must be replaced by the installer or an approved Nobo service partner. - Page 7 IMPORTANT SAFETY ADVICE Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children No extension leads Where the power may be left or power boards cable may be unattended damaged On a slope or Where there is risk Where it may be uneven surface...
- Page 8 Sizing Options WATTAGE PRODUCT CODE DIMENSIONS (MM) WEIGHT (KW) NTL4R 10 725W x 400H x 55D 4.7kg NTL4R 15 1025W x 400H x 55D 5.8kg NTL4R 20 1125W x 400H x 55D 7.6kg NTL4R 24 1425W x 400H x 55D...
- Page 9 Installation Parts Dimensions Watt 1000 1200 1025 2000 1125 2400 1425 1000 50mm (min) WARNING - Minimum clearances and IP zone requirements must be adhered to. Do not locate the appliance immediately below or in front of a fixed socket outlet or connection box.
-
Page 10: Wall Mounted Installation
Wall Mounted Installation MINIMUM CLEARANCE: WALL BRACKET INSTALLATION STEPS: The wall bracket can be used as a Mark the location for the two bottom measuring device for placing the screws (A-A) and fasten the two screws heater on the wall. in the wall. - Page 11 Place the wall bracket onto the bottom Place the heater on the wall screws (A-A). Then fasten the wall bracket bracket (1), secure the tilt strap with the top screws. (2) and click the heater onto the top catches (3). Turn on the switch to Plug the product.
-
Page 12: Portable Installation
Portable Installation CAUTION: Castors/portable installation is only suited for well insulated spaces or occasional use. A: Ensure the enclosed screw (M3.5x10) is in place on the power supply as shown. Assemble foot onto the frame hole. Align the product with reference to slots provided on frame. -
Page 13: Operation
Operation Temperature Settings This device has two modes, being COMFORT and ECO. When the display light is red, the device is on COMFORT mode. When the display light is green, the device is on ECO mode. Control the temperature on both modes by pressing the + or - button as below. - Page 14 Operation Application Setup WARNING: You must remember to put product into Standy-by or Away mode when not home. We recommend only operating the product when somone is on the premises. To add a heater to your site, press the + button in the top, right corner of the control screen.
-
Page 15: Cleaning And Storage
Cleaning & Storage Over time, dust can accumulate on the heater which can effect performance. It is recommended to clean the unit at least once a month. Turn the unit OFF and disconnect the appliance from the power supply. Remove any dust build up with a soft brush. Wipe the surface of the unit with a soft damp cloth. - Page 16 Customer Care : 1300 556 816 customer.care@glendimplex.com.au www.nobo.com.au Supplied by Glen Dimplex Australia 8 Lakeview Drive, Scoresby, Victoria, 3179 ©Nobo Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Nobo Australia.
