- Page 1 INSTRUCTION MANUAL Nobo NTL Heater with Timer Models: NTL4T 07 | NTL4T 10 | NTL4T 12 NTL4T 15 | NTL4T 20 | NTL4T 24 For domestic household use only. 300001875 Issue 1...
-
Page 2: Suitable Applications
IMPORTANT SAFETY ADVICE THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE. Note also the information presented on the appliance CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE YOUR WARRANTY Please read the operating instructions carefully before using your panel heater for the first time and keep them in a safe place. -
Page 3: Child Safety
WARNING - THE SURFACES ON THIS HEATER CAN BE HOT. The heater carries a warning symbol to alert the user to the risk of fire that exists if the heater is accidentally covered. CAUTION - Some parts of this product can become very hot and cause burns. -
Page 4: Operating Warnings
OPERATING WARNINGS IMPORTANT: Remember to observe all safety warnings and precautions when operating the heater on the automatic or timer modes, either attended or unattended since a fire risk exists when the heater is accidentally covered or displaced. CAUTION: Do not use if the heater’s main power lead is damaged. If the supply cord is damaged it must be replaced by the installer or an approved Nobo service partner. -
Page 5: Important Safety Advice
IMPORTANT SAFETY ADVICE Exposed to the Near water If the power cable weather outdoors wires are frayed or cut Where small children If an extension Where the power may be left lead may become cable may be unattended overloaded damaged On a slope or Where there is risk Where it may be... - Page 6 Sizing Options WATTAGE PRODUCT CODE DIMENSIONS (MM) WEIGHT (KW) NTL4T 07 0.75 625W x 400H x 55D 3.9kg NTL4T 10 725W x 400H x 55D 4.7kg NTL4T 12 925W x 400H x 55D 5.3kg NTL4T 15 1025W x 400H x 55D 5.8kg...
- Page 7 Installation Parts WARNING - Minimum clearances and IP zone requirements must be adhered to. Do not locate the heater immediately below a fixed electrical power point. WARNING: This heater must not be connected to the electricity supply via an external switching device (such as a timer) or circuit that is regularly switched on and off by the utility supplier.
-
Page 8: Wall Mounted Installation
Wall Mounted Installation MINIMUM CLEARANCE: WALL BRACKET INSTALLATION STEPS: The wall bracket can be used as a Mark the location for the two bottom measuring device for placing the screws (A-A) and fasten the two screws heater on the wall. in the wall. - Page 9 Place the wall bracket onto the bottom Place the heater on the wall screws (A-A). Then fasten the wall bracket bracket (1), secure the tilt strap with the top screws. (2) and click the heater onto the top catches (3). To secure the heater safely Plug the product.
-
Page 10: Portable Installation
Portable Installation CAUTION: Castors/portable installation is only suited for well insulated spaces or occasional use. A: Ensure the enclosed screw (M3.5x10) is in place on the power supply as shown. Assemble foot onto the frame hole. Align the product with reference to slots provided on frame. -
Page 11: Setting The Timer
Setting the Timer SET DAY AND TIME Press Settings Button at home screen. 2. Press the same button displaying the (tick) when the clock icon appears. Press Arrow keys to Set Day; Press Next Key to confirm the selection. Use arrow key to set hour; Press Next key. After setting minutes press ✓... -
Page 12: Adaptive Start
ADAPTIVE START Adaptive Start is an intelligent feature that allows the heater to begin heating the room before the start of the heating period to ensure the room is at the required temperature when the period starts. SET TEMPERATURE / OVERRIDE Use the up and down buttons to increase or decrease the temperature. -
Page 13: Adding A Profile
Adding a Profile EXAMPLE PROFILE ADD PROFILE Press ✓ button to Add first profile. Use arrow button to change Profile Days (MO – SU) or (MO-FR). Press Next button to go for Mode and Time setting. Cycle through Mode, Time menu and set time with arrow buttons and at the end press ✓... -
Page 14: Editing Or Deleting A Profile
Editing or Deleting a Profile EDIT PROFILE Select profile you want to edit and press ✓ button. Press ✓ button to enter into profile. Use arrow keys to cycle through profile Days. Press ✓ button to change time. Set Time by using arrow keys. Press ✓... -
Page 15: Cleaning And Storage
Cleaning & Storage Over time, dust can accumulate on the heater which can effect performance. It is recommended to clean the unit at least once a month. Turn the unit OFF and disconnect the appliance from the power supply. Remove any dust build up with a soft brush. Wipe the surface of the unit with a soft damp cloth. - Page 16 Customer Care : 1300 556 816 customer.care@glendimplex.com.au www.nobo.com.au Supplied by Glen Dimplex Australia 8 Lakeview Drive, Scoresby, Victoria, 3179 ©Nobo Australia. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without prior permission in writing of Nobo Australia.
