NOBOCOOL NUL4T2 05 Installation And Operating Instructions Manual

Dimensions
Model(s) Watt
NUL4T2 05 500
NUL4T2 10 1000
NUL4T2 15 1500
NUL4T2 20 2000
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
IMPORTANT SAFETY ADVICE
When using electrical
precautions should always be followed to reduce
the risk of fire, electrical shock, and injury to
persons, including the following:
IMPORTANT - The wall bracket supplied with
the appliance must be used.
DO NOT use this heater in the immediate
surroundings of a bath, a shower or a swimming
pool.
IMPORTANT - If the heater is installed in a
room containing a bath or shower, it must be
so installed that switches and other controls
cannot be touched by a person using a bath or
shower.
WARNING - In order to avoid overheating, do
not cover the heater. Do not place material
or garments on the heater, or obstruct the
air circulation around the heater, for instance
by curtains or furniture, as this could cause
overheating and a fire risk.
This heater carries the warning symbol
indicating that it must not be covered.
NEVER cover or obstruct in any way the heat
outlet slots at the top of the heater or the air
inlet slots in the base of the heater.
CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience or knowledge if they have
been given supervision or instruction concerning
the use of the appliance in a safe way and
understand the hazards involved. Children shall
not play with the appliance. Cleaning and user
maintenance shall not be carried out by children
without supervision.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
A B
425mm 400mm 115mm
525mm 400mm 115mm
625mm 400mm 115mm
925mm 400mm 115mm
appliances, basic
Installation and Operating Instructions
Fig. 1
30mm
(min)
C
'B'
in its intended normal operating position and
they have been given supervision or instruction
concerning the use of the appliance in a safe
way and understand the hazards involved.
Children aged from 3 years and less than 8
years shall not plug in, regulate and clean the
appliance or perform user maintenance.
If the supply cord is damaged it must be
replaced by the manufacturer or service agent
or a similarly qualified person in order to avoid
a hazard.
WARNING: Servicing and product repairs should
only be undertaken by the manufacturer's
approved service agent or a similarly qualified
person, using only exact manufacturer approved
spare parts.
The supply circuit to the heater must incorporate
a double pole isolating switch having a contact
separation of at least 3mm.
WARNING: Packaging should be disposed of
responsibly as the EPS used could be a potential
choking hazard for children.
WARNING: Do not locate the heater immediately
below a fixed socket outlet or connection box.
Note that due care and consideration must be
taken when using this heater in series with a
thermal control, a program controller, a timer
or any other device that switches on the heat
automatically, since a fire risk exists when the
heater is accidentally covered or displaced.
WARNING: Do not use this heater in small
rooms when they are occupied by persons not
capable of leaving the room on their own , unless
constant supervision is provided.
Do not use this heater if it has been dropped.
Do not use if there are visible signs of damage
to the heater.
WARNING: To reduce the risk of fire, keep
textiles, curtains or any other flammable material
a minimum distance of 1m from the air outlet.
Use this heater on a horizontal and stable
surface, or fix it to the wall as applicable.
NOBO Compact Heater
08/55138/0
30mm
'A'
(min)
300mm
Minimum
front
clearance
50mm
(min)
50mm (min)
Issue 2
Shelf
(min)
'C'
