Copying A Program - Ada MP-1 CLASSIC Owner's Manual

ADA MP-1 Classic owner's manual
STORING AN EDITED PROGRAM
Hint: Pressing "Store" accesses internal program locations 1 through 128 where all
edited programs can be stored.
1. Press the STORE button. It will light and the display will show the Bank number and
an underscore for the ones digit
2. To select a different BANK to Store a Program, use the BANK-UP or BANK-DOWN
buttons to select the Bank number
3. Press a digit, 0 to 9, to select the Program number to store to.
Hint: Storing a Program will overwrite the parameter values previously stored at that location.
The original program parameter values will be erased and replaced with the new program
parameter values.

COPYING A PROGRAM

Call up the program number to be copied (See "accessing programs" section of this manual)
1. If you are in MIDI PRGM mode you should first press the INTERNAL PRGM button to
go into the INTERNAL PRGM mode, since you cannot store any programs into a
MIDI program location (see ACCESSING PROGRAMS section for explanation of
both modes)
2. Use the BANK-UP, BANK-DOWN, 0-9 digits and the
program you want to copy.
3. Press the STORE button. It will light.
4. If the program number you want to copy TO is in a different BANK, use the BANK-UP
or BANK-DOWN buttons to select the desired bank number.
5. Press the ones digit (0 to 9) of the desired program number in which you want to copy
your program. Your program is now copied.
LOADING ALL 39 PRESETS
Warning: If you have your own programs in internal memory numbers 1 in 39,
loading all Preset programs from ROM will erase those programs.
There are 39 factory Preset programs (1-39) that can he loaded from ROM into the internal
program memory via the front panel. It is possible to load all 39 at once into the internal
program memory, or load one at a time into the working registers.
1. Press the STORE button. It will light.
2. Press the BANK-UP button and while holding the BANK-UP button down press the 1
button.
3. The display will read "ALL PrEsEtS LoAdEd." When the display returns to a program
number, all 39 factory Presets have been loaded into the INTERNAL register 1-39.
LOADING ONE PRESET
1. If in MIDI PRGM mode, first press the INTERNAL PRGM button to go into the
INTERNAL PRGM mode.
2. Go to the internal Program number which corresponds to the Preset number to be
loaded. for example, to load Preset number 20, go to internal program number 20
3. Press the STORE button. It will light.
4. Press the BANK-UP button and while holding the BANK UP button down press the 4
button.
5. The display will read "onE PrEsEt LoAdEd." When the display returns to the program
number, it will be flashing, as if the program had just edited. If the Program that was
at that location was already the same as the Preset, the display will not flash. The
Preset is now loaded in the working registers, and can be saved to any of the 128
Internal Program locations by following the STORE EDITED PROGRAM procedure
above.
Λ
Page 10 of 18
and V arrows to go to the
