Atmor Platinum Installation Instructions

http://waterheatertimer.org/How-to-install-point-of-use-water-heater.html
Up to 6kW
(One phase)
Also for 2 x 127V (2 )
for Latin America
7kW to 9.5kW
(One phase)
Also for
127V up to 5kW
7kW to 9.5kW
(Two phase)
1. Multi-pole switch 5. Switches
2. Terminal block 6. LED Light
3. Thermostat 7. Heating elements
4. Microswitch 8. Pressure switch
Model Heat Setting
Optima-Platinum - 3.0 1.0;2.0 or 3.0kW
Optima-Platinum - 3.5 1.5;2.0 or 3.5kW
Optima-Platinum - 5.0 2.0;3.0 or 5.0kW
Optima-Platinum - 5.5 2.5;3.0 or 5.5kW
Optima-Platinum - 7.0 3.0;4.0 or 7.0kW
Optima-Platinum - 8.0 4.0;4.0 or 8.0kW
Optima-Platinum - 9.5 4.5;5.0 or 9.5kW
• Operating water pressure 0.3-7 BAR (5-100 psi) • Water pressure operated power switch
• Standard 1/2"fl compression inlet connection • Top-left and right cable entry • Bottom-left water entry
• Fixing pack and instructions supplied
UNIT DIMENSIONS: HEIGHT 185mm
In Platinum Digital Models
Power
Quick Digital Quick
Connector Display Connector
In Platinum Digital Models
Power
Quick Digital Quick
Connector Display Connector
In Platinum Digital Models
Power
Quick Digital Quick
Connector Display Connector
Table 2
kW loading
Recommended Recommended
cable size fuse rating
220V 230V 240V
2
3.0 3.3 3.6 2.5mm 16amps
3.2 3.5 3.8 2.5/4mm 2 20amps
5.0 5.5 6.0 4/6mm 2 25amps
2
5.5 6.0 6.6 4/6mm 25-32amps
7.0 7.7 8.3 6/10mm 2 40amps
2
7.3 8.0 8.7 6/10mm 40amps
8.7 9.5 10.3 10mm 2 45amps
WIDTH 300mm DEPTH 110mm
Installation Instructions for "Platinum"and "Optima" model
Background
The instant water heater is a novel appliance designed to supply
continuous and unlimited hot water while conserving energy
saving up to 80% in electricity compared to a 120 liter boiler.
Temp.
Sensor
Temp. Digital Flow control
Display
(in Digital model)
Flow control
Multi Shower
Shower kit
Quality Sprayer with Adju
stable Shower Head, Slidi
Temp.
Sensor ng Rail and Soap Dish
ELCB
Multi Temp (Optional)
MULTI TEMPERATURE CONTROL Only for Platinum
Multi Shower
Temp. Digital Flow control
Display
(in Digital model)
Temp.
Sensor
Multi Temp
MULTI TEMPERATURE CONTROL
Tri
Shower
Temp. Digital Display
(in Digital model)
Tri Temp
3 TEMPERATURE SETTINGS
Only for
Multi and
Completa models
To remove triangle
Push out from inner side
of white cover
on this point
Power setting
Power setting
Terminal block
cable connector
2 Cable entry
right and left
Sink
or
Power setting
To remove triangle
Push out from inner side
of white cover
on this point
Sink
or
Terminal block
cable connector
Power setting
2 Cable entry
right and left
ELCB
(Optional)
Releave snap
to release cover
ELCB
(Optional)
Fig. No. 1
Releave
snap to
release
cover
Fig. No. 1
