User Guide for the ServSwitch™ Summit
You can use the ServSwitch™ Summit system to manage any practical number of
computer CPUs, from just a few to thousands. This user guide describes how to
configure and operate a keyboard/video/mouse user station attached to a
ServSwitch™ Summit User Station Module ("USM," product code KV1510A). For
USM specifications, installation instructions, system-administrator functions, etc., see
the manual for the ServSwitch™ Summit Base Units (KV1500A through KV1503A).
1. Logging In
You need to login in order to access computers and other devices connected to the
Summit system. The Login Menu (shown in Figure 1 on the next page) is
automatically displayed on every user-station monitor after the attached Summit
Base Unit is powered on; to bring up the Login Menu on a user-station monitor at
any other time, press the system's hotkey (the factory default is [Scroll Lock]) twice
in quick succession to bring up the On Screen User Interface ("OSUI"), then press
function key [F9].
If a user-station monitor displays the message "...No Connection to
Summit..." instead of the Login Menu, either the USM isn't connected
properly to the Base Unit, the Base Unit is powered off, or the Base Unit
is malfunctioning. Notify your system administrator.
CUSTOMER
SUPPORT
INFORMATION
User Station Module
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
NOTE
FEBRUARY 2003
KV1510A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KV1510A ServSwitch Summit and is the answer not in the manual?

Questions and answers

Related Manuals for Black Box KV1510A ServSwitch Summit

Summary of Contents for Black Box KV1510A ServSwitch Summit

  • Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) SUPPORT FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 INFORMATION Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
  • Page 2 SERVSWITCH™ SUMMIT USER STATION MODULE The Device ID field in the login menu will initially contain the attached Base Unit’s default device name: “Summit” followed by “2x42” for a KV1500A, “4x42” for a KV1501A, “8x32” for a KV1502A, or “16x64” for a KV1503A. (The administrator can assign it a different name.) The User Port is the number of the user port on the Base Unit—from 1 to 16 depending on the model—that this USM and user station are attached to.

  • Page 3: Section 2: Selecting A Computer

    SECTION 2: Selecting a Computer 2. Selecting a Computer Immediately after you login, the Summit’s OSUI displays the Selection Menu. If you’re already logged in, you’ll need to bring up the Selection Menu by pressing the hotkey (the factory default is [Scroll Lock]) twice in quick succession, then pressing function key [F2].
  • Page 4 SERVSWITCH™ SUMMIT USER STATION MODULE Selection Menu by Name Main_16x64 Page Name Ch.ID ------------ --------------- Mrktng_8x32 Matrls_8x32 NT40-Fax NT40-Fax NT40-Mail PubSrv_8x32 Wins95_Bob Wins98_Jack ------------ --------------- Page PCName FKey Ent Esc ScrlLock | Scan | Skip NCSL Figure 3. The Selection Menu ordered by name. Main_16x64.02 NT40-Fax Figure 4.
  • Page 5 SECTION 2: Selecting a Computer In the channel-ID (sorted by ID) view, once your desired channel’s page is on screen, you can also press the desired channel’s key number ([1] through [8]) to move the highlight to that channel instantly. In the name view, you can also type the first few characters of the desired channel’s name to move the highlight to the first channel whose name begins with that character sequence.
  • Page 6 SERVSWITCH™ SUMMIT USER STATION MODULE When the Summit system is set to Public View Mode by the administrator, if one user has already selected a computer, another user can also select it, but the second user will only be able to view its video output; they won’t be able to control it or input any data with the keyboard and mouse.

  • Page 7: Section 3: Customizing How The Usm Operates For You

    SECTION 3: Customizing How the USM Operates for You 3. Customizing How the USM Operates for You When the OSUI is active, you can bring up the User Profile Menu, shown in Figure 5, by pressing function key [F4]. This menu is for displaying the Summit’s configuration and for setting preferred operating parameters for individual user accounts.
  • Page 8 SERVSWITCH™ SUMMIT USER STATION MODULE 3. If you want to change the value of any of the other fields, use your keyboard keys to select the field you want to edit: Press [Tab] to move forward through the editable fields, [Shift]+[Tab] to move backward, the up- and down-arrow keys to move up and down, and the left- and right-arrow keys to move left and right.
  • Page 9 SECTION 3: Customizing How the USM Operates for You • ID Display: The ID Display is a small window that can pop up on screen to show you the name and ID of each channel as you switch between them or scan them.
  • Page 10 SERVSWITCH™ SUMMIT USER STATION MODULE • Display Position: Use this parameter to move the OSUI menus and ID Display to the desired position on your monitor screen. First move the highlight to “Menu” (for the OSUI) or “ID” (for the ID Display, which will pop up if it’s not already on screen while the OSUI temporarily disappears) and press [Enter] to highlight it, then use the arrow keys to move the chosen window as desired: the left-arrow key to move the whole window to the left, for example.

  • Page 11: Section 4: Keyboard-Controlled Osui Functions

    SECTION 4: Keyboard-Controlled OSUI Functions 4. Keyboard-Controlled OSUI Functions Use the following function keys to access the Summit’s OSUI functions: Press… When you want to… [F1] View the Help Menu (shown in Figure 6 on the next page). [F2] Access the Selection Menu (see Section 2) in order to view or select channels or view group IDs or scan rates.
  • Page 12 SERVSWITCH™ SUMMIT USER STATION MODULE Help F1 Help / ESC Exit F2 Channel Selection -F12 Sort by Channel/Name F4 User Profile F5 Administrative Functions F6 Toggle Scan On/Off F7 Toggle Skip On/Off F8 Information Screen F9 Logout -Shift+F9 Release Channel F10 Toggle Disp All Ch.
  • Page 13 SECTION 6: Local PC Mode 6. Local PC Mode (Optional) It’s possible for the system administrator to install a KV1519A Computer Interface Module (“CIM”) between your USM and the Base Unit, as shown in Figure 8. This would give you sole access to a local computer CPU in addition to your shared access to the other CPUs in the system.
  • Page 14 If you determine that your ServSwitch™ Summit USM is malfunctioning, do not attempt to alter or repair the unit. It contains no user-serviceable parts. Contact your system administrator; if they aren’t available, contact Black Box Technical Support at 724-746-5500. Before you do, make a record of the history of the problem. We will be able to...

  • Page 15: Section 8: Shipping And Packaging

    • Package it carefully. We recommend that you use the original container. • If you are returning it, make sure you include everything you received with it. Before you ship for return or repair, contact Black Box to get a Return Authorization (RA) number.
  • Page 16 © Copyright 2003. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
