Machine description – quick overview
Front view
4
Machine description – quick overview
4.1
Front view
Item
Symbol Description
1
2
3
4
5
6
7
8
9
10
16
0
Lifting lug
Carrying handle
Signal light, Functional error
On when excess temperature detected
Main switch, machine on/off
Welding voltage step switch
To set the welding voltage
Cooling air inlet
Connection socket, workpiece lead
"Hard" choke tapping
Connection socket, workpiece lead
"Medium" choke tapping
Wheels, guide castors
Wheels, fixed castors
Figure 4-1
099-004991-EW501
26.09.2011
