Design and function
Connection for workpiece lead
5.8
Connection for workpiece lead
Item
Symbol Description
1
2
3
•
Insert cable plug on the workpiece lead into the connection socket for workpiece lead 1 or 2
(depending on the application or shielding gas used) and lock by turning to the right.
24
0
Workpiece
Connection socket, workpiece lead
Choke tapping "soft"
Connection socket, workpiece lead
"Hard" choke tapping
Figure 5-4
099-004991-EW501
26.09.2011
