USER'S
GUIDE
Ultra160
SCSI to PCI
Host Adapters
O c t o b e r 2 0 0 1
Version 1.1
®
DB15-000183-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LSI Ultra160

Summary of Contents for LSI Ultra160

  • Page 1 USER’S GUIDE Ultra160 SCSI to PCI Host Adapters O c t o b e r 2 0 0 1 Version 1.1 ® DB15-000183-01...
  • Page 2 Consult the dealer or an experienced radio/TV technician for help. Shielded cables for SCSI connection external to the cabinet are used in the compliance testing of this Product. LSI Logic is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI Logic.
  • Page 3 LSI Logic; nor does the purchase or use of a product from LSI Logic convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Logic or third parties.
  • Page 5 Preface This book is the user’s guide for all LSI Logic Ultra160 SCSI to PCI Host Adapters. It contains a functional description for the Ultra160 SCSI boards as well as physical and electrical specifications. Audience This document assumes that you have some familiarity with SCSI protocol and related support devices.
  • Page 6 7/01 Contains all Ultra160 SCSI PCI Host Adapters produced by LSI Logic. 10/01 Added LED information in Chapter 3 to ITI6200U3LP board. Changed title to Ultra160 SCSI to PCI Host Adapters and other references to same throughout the book. Preface...

  • Page 7: Table Of Contents

    2.1.1 2.1.2 Connecting SCSI Peripherals 2.2.1 2.2.2 Terminating the SCSI Bus 2.3.1 2.3.2 Completing the Installation Chapter 3 Ultra160 SCSI to PCI Host Adapter Characteristics Ultra160 SCSI to PCI Boards Host Adapter Characteristics 3.2.1 3.2.2 3.2.3 3.2.4 3.2.5 3.2.6 3.2.7...
  • Page 8 3.3.1 3.3.2 Technical Specifications 3.4.1 3.4.2 3.4.3 Appendix A Glossary of Terms and Abbreviations Index Customer Feedback viii Contents Internal SCSI Cables External SCSI Cables and Connectors Electrical Characteristics Thermal, Atmospheric Characteristics Safety Characteristics 3-10 3-11 3-13 3-14 3-15 3-15...
  • Page 9 Figures Hardware Connections for the Host Adapter Inserting the Host Adapter Internal SCSI Ribbon Cable to Host Adapter Multiple Internal SCSI Devices Chained Together External SCSI Connection to an External SCSI Device Multiple External SCSI Devices Chained Together Autotermination Shunt LSI20160 Mechanical Drawing LSI20160L Mechanical Drawing LSI22903 Mechanical Drawing...
  • Page 10 Contents...
  • Page 11 Tables SCSI ID Record Ultra160 SCSI to PCI Host Adapter Boards Host Adapter Characteristics Cable Specifications Maximum Power Requirements Contents 2-10 3-10 3-14...
  • Page 12 Contents...

  • Page 13: Chapter 1 Quick Installation Procedures

    LS53C1010 Installing any of these adapters into your PCI system allows you to connect SCSI devices over a SCSI bus. You can use the Ultra160 SCSI boards in PCI computer systems with either a standard or Low Profile PCI (LPPCI) bracket type.

  • Page 14: Obtaining Windows Nt/Windows 2000 Drivers

    Before you begin the Ultra160 SCSI host adapter installation, create a Windows NT or Windows 2000 driver diskette by copying the driver files from either the LSI Logic SDMS CD-ROM or from the LSI Logic web site at http://www.lsilogic.com. If you obtain the driver software from the LSI Logic web site, the zipped package that you download contains the appropriate files.

  • Page 15: Quick Host Adapter Installation

    If you prefer more detailed instructions and guidance, refer to SCSI Host Adapter,” page To install an LSI Logic Ultra160 SCSI to PCI Host Adapter, follow these steps: Step 1. Ground yourself before handling the host adapter board to Step 2.

  • Page 16: Quick Windows Nt/Windows 2000 Driver Installation

    Quick Windows NT/Windows 2000 Driver Installation To load the SYM_U3.SYS miniport driver during a new Windows NT or Windows 2000 system installation, you can boot directly from the Microsoft installation CD-ROM. The Windows NT 4.0 and Windows 2000 drivers are not interchangeable, however the instructions are very similar. To install a new Windows NT or Windows 2000 operating system and its appropriate device driver, follow these steps: Step 1.

  • Page 17: Chapter 2 Detailed Host Adapter Installation

    Step 1. Ground yourself before removing the host adapter board from Caution: Step 2. Remove your Ultra160 SCSI host adapter from its packing and Step 3. Turn off and unplug your computer and peripherals. Ultra160 SCSI to PCI Host Adapters its package to discharge static electricity.

  • Page 18: Inserting The Host Adapter

    Step 5. Locate the PCI slots on your computer. 2.1.2 Inserting the Host Adapter Perform the following steps to install your Ultra160 SCSI Host Adapter in your PC mainboard. Step 1. Remove the blank bracket panel on the back of the computer Step 2.

  • Page 19: Hardware Connections For The Host Adapter

    SCSI Connector Ultra160 SCSI PCI Bus Note: Notice that the components on a Ultra160 SCSI to PCI host adapter face the opposite way from non-PCI adapter boards you may have in your system. This is correct. The board is keyed to go in only one way.

  • Page 20: Connecting Scsi Peripherals

    Figure 2.2 Bracket around connector J3 fits where blank bracket panel was removed. Connecting SCSI Peripherals This section provides information about making internal and external SCSI connections. 2.2.1 Making Internal Wide SCSI Bus Connections This section provides step-by-step instructions for making internal SCSI bus connections.

  • Page 21: Internal Scsi Ribbon Cable To Host Adapter

    Step 1. Plug the 68-pin connector on the SCSI ribbon cable into the internal connector on the host adapter board. illustrates how to make this connection. Figure 2.3 Internal SCSI Ribbon Cable to Host Adapter 68-Pin High Density Ribbon Cable (See examples of internal ribbon cables.) 68-Pin...

  • Page 22: Making External Scsi Bus Connections

    Step 3. Plug in any additional internal SCSI devices, as required. Figure 2.4 External Connector 2.2.2 Making External SCSI Bus Connections This section provides step-by-step instructions for making external SCSI bus connections. Refer to Connectors,” page 3-11 Step 1. Plug the 50-pin connector on one end of a shielded external Step 2.

  • Page 23: External Scsi Connection To An External Scsi Device

    Figure 2.5 shows an example of an external SCSI connection to a single external SCSI device. If you have the correct cable, it matches the external connector. Termination occurs on the last SCSI device. See for more information about SCSI bus termination. Figure 2.5 External SCSI Connection to an External SCSI Device Terminator...

  • Page 24: Terminating The Scsi Bus

    To utilize Ultra160 SCSI performance, you must only have LVD devices on the bus. Do not mix any SE devices with LVD devices or the entire bus will drop to SE speed, limiting bus performance to Ultra SCSI.

  • Page 25: Internal And External Scsi Terminations

    The Ultra160 SCSI host adapters automatically control SCSI bus termination for various bus configurations. In one case, you may disable termination by using BIOS software control to change the BIOS termination from Automatic to Off. In another case where jumpers are provided on the board, you would locate the shunts on the board for autotermination override.
  • Page 26 IDs for future reference. Correct any duplications at this time. Table 2.1 provides a place to keep this record. SCSI ID Record SCSI Device Channel A Ultra160 SCSI to PCI Host Adapter SCSI Device Channel B Ultra160 SCSI to PCI Host Adapter...

  • Page 27: Completing The Installation

    Step 2. Plug in all power cords, turn on the peripherals, and then turn Step 3. Wait for your computer to boot up. Step 4. Refer to the LSI Logic PCI Storage Device Management Completing the Installation on your computer.
  • Page 28 2-12 Detailed Host Adapter Installation...

  • Page 29: Ultra160 Scsi To Pci Host Adapter Characteristics

    Ultra160 SCSI to PCI Host Adapter Characteristics This chapter describes the LSI Logic Ultra160 SCSI to PCI Host Adapter boards for use in your computer systems. This chapter includes these topics: Section 3.1, “Ultra160 SCSI to PCI Boards,” page 3-1 Section 3.2, “Host Adapter Characteristics,”...

  • Page 30: Host Adapter Characteristics

    2. For BIOS configuration storage The following sections provide the pertinent details and features of each LSI Logic Ultra160 SCSI to PCI host adapters. Along with these features, an example of each board’s mechanical drawing is provided to illustrate the main connectors, the LSI Logic controller, and the termination speed supported by these connections.

  • Page 31: Lsi20160 Host Adapter

    3.2.1 LSI20160 Host Adapter The LSI20160 PCI to Single Channel Ultra160 SCSI Host Adapter (Figure 3.1) provides one Ultra160 SCSI channel. The LSI20160 board supports Low Voltage Differential (LVD) and Single-Ended (SE) SCSI. The SCSI interface is made through connectors J2 and J4.

  • Page 32: Lsi20160L Host Adapter

    3.2.2 LSI20160L Host Adapter The LSI20160L PCI to Single Channel Ultra160 SCSI Low Profile PCI Host Adapter LSI20160L board supports Low Voltage Differential (LVD) and Single- Ended (SE) SCSI. The LSI20160L board is the LPPCI board with a low profile bracket. The SCSI interface is made through connectors J2 and...

  • Page 33: Lsi22903 Host Adapter

    3.2.3 LSI22903 Host Adapter The LSI Logic LSI22903 PCI to Dual Channel Ultra160 SCSI Low Profile PCI Host Adapter channels. The LSI22903 board is a LPPCI board with a low profile bracket. The SCSI interface is made through connector J2 for channel A and J4 for channel B.

  • Page 34: Lsi22915A Host Adapter

    3.2.4 LSI22915A Host Adapter The LSI22915A PCI to Dual Channel Ultra160 SCSI Host Adapter (Figure 3.4) channel A and channel B of the LSI22915A support LVD and SE as a SCSI solution for your computer. The SCSI interface is made through connector J1 or J3 for channel A and J4 or J7 for channel B.

  • Page 35: Iti6200U3Lp Host Adapter

    Subsystem ID is 1300. The LVD status indicators for the LSI22915A and ITI6200U3LP are: Host Adapter Characteristics (Figure 3.5) is an Ultra160 SCSI Low Profile PCI Host Two external 68-pin VHDCI connections One internal 68-pin high density connection J4 Channel B...

  • Page 36: Lsi21003 Host Adapter

    LVD and SE modes of operation. The LSI21003 host adapter has these features: Ultra SCSI Wide SE for channel A to 40 Mbytes/s per data transfer; Ultra160 SCSI for channel B to 160 Mbytes/s per data transfer Four connectors –...

  • Page 37: Lsi21040 Host Adapter

    Channel A supports LVD/SE modes of operation, while channel B supports only the SE mode. The LSI21040 board has these features: Ultra160 SCSI for channel A to 160 Mbytes/s per data transfer; Ultra SCSI SE for channel B to 40 Mbytes/s per data transfer Four connectors –...

  • Page 38: Cabling Scsi Devices

    Ultra speeds. 3.3.1 Internal SCSI Cables You can make internal SCSI bus connections to your Ultra160 SCSI host adapter with an unshielded, 68- or 50-conductor ribbon cable. Some internal cables come with an LVD/SE terminator on one end. This end must be farthest from the host adapter.

  • Page 39: External Scsi Cables And Connectors

    Figure 3.10 SCSI Cable – 50-Pin Low Density 3.3.2 External SCSI Cables and Connectors All external SCSI bus connections to your Ultra160 SCSI host adapter are made with shielded cables. Figures examples of external cables. The connectors on this cable are keyed to ensure proper pin-1 connection.

  • Page 40: Scsi Cable - 68-Pin Vhdci

    Figure 3.11 SCSI Cable – 68-Pin VHDCI Figure 3.12 SCSI Cable – 50-Pin High Density Figure 3.13 SCSI Cable – 50-Pin Low Density 3-12 Ultra160 SCSI to PCI Host Adapter Characteristics...

  • Page 41: Technical Specifications

    Note: The DB25 Connector is not a SCSI Standard. Technical Specifications The design and implementation of the LSI Logic Ultra160 SCSI to PCI host adapter boards minimize electromagnetic emissions, susceptibility to radio frequency energy, and the effects of electrostatic discharge. The board carries the CE mark, C-Tick mark, FCC Self-Certification log,...

  • Page 42: Electrical Characteristics

    3.4.1 Electrical Characteristics This section provides the power requirements for standard PCI boards and Low Profile PCI Ultra160 SCSI boards. 3.0.0.1 Standard and Low Profile PCI Boards Table 3.4 TERMPWR, under normal operation. Table 3.4 Maximum Power Requirements Host Adapter PCI +5.0 V DC...

  • Page 43: Thermal, Atmospheric Characteristics

    Relative humidity range: 5% to 90% noncondensing 3.4.3 Safety Characteristics All LSI Logic Ultra160 SCSI to PCI host adapter boards meet or exceed the requirements of UL flammability rating 94 V0. Each bare board is also marked with the supplier’s name or trademark, type, and UL flammability rating.
  • Page 44 3-16 Ultra160 SCSI to PCI Host Adapter Characteristics...

  • Page 45: Appendix A Glossary Of Terms And Abbreviations

    Cyclic Redundancy Check (CRC) is an error detection code used in Ultra160 SCSI. Four bytes are transferred with the data to increase the reliability of data transfers. CRC is used on the Double Transition (DT) Data-In and DT Data-Out phases.
  • Page 46 Domain Domain Validation is a software procedure in which a host queries a Validation device to determine its ability to communicate at the negotiated Ultra160 data rate. Double In Double Transition (DT) Clocking, data is sampled on both the asserting Transition and deasserting edge of the REQ/ACK signal.
  • Page 47 SCSI bus has eight available SCSI IDs numbered 0 through 7 (or 0 through 15 for Wide SCSI). The host adapter usually gets the highest ID (7 or 15) giving it priority to control the bus. SDMS Storage Device Management System. An LSI Logic software product that manages SCSI system I/O.
  • Page 48 40 Mbytes/s over an 8-bit SCSI bus, and up to 80 Mbytes/s over a 16-bit SCSI bus. Ultra160 SCSI A standard for SCSI data transfers. It allows a transfer rate of up to 160 Mbytes/s over a 16-bit SCSI bus.
  • Page 49 SE and LVD 3-14 electrical characteristics external SCSI bus connections external chaining making F6 key pressing during installation process Ultra160 SCSI to PCI Host Adapters host adapter inserting installation check list ITI6200U3LP LSI20160 LSI20160L LSI21003 LSI21040 LSI22903...
  • Page 50 IX-2 Index UL flammability rating Ultra160 Ultra160 SCSI to PCI controllers Ultra160 SCSI to PCI host adapters board descriptions subsystem/subsystem vendor IDs Windows NT 4.0 service packs Windows NT/WIndows 2000 miniport driver Windows NT/Windows 2000...

  • Page 51: Customer Feedback

    Please include your name, phone number, fax number, and company address so that we may contact you directly for clarification or additional information. Thank you for your help in improving the quality of our documents. Ultra160 SCSI to PCI Host Adapters...
  • Page 52 Reader’s Comments Fax your comments to: Please tell us how you rate this document: Ultra160 SCSI to PCI Host Adapters User’s Guide. Place a check mark in the appropriate blank for each category. Completeness of information Clarity of information Ease of finding information...
  • Page 53 You can find a current list of our U.S. distributors, international distributors, and sales offices and design resource centers on our web site at http://www.lsilogic.com/contacts/na_salesoffices.html...
