Status indicators
The front panel of the iPoMan II-1200 has several LED
indicators that provide information about the input and output
power status. The following table describes these status
indicators.
Status indicator
Input and
power status indicator
Input power
indicator
Rear Panel of 2-inlet Model
1
Output Display status of each power input and
outlet (A ~ L) as follows:
Input/Output power indicator: Display the
input / Output power status.
- Gray: power off
- Green: power on
- Red: power fault
Display input voltage (Volts), input current
status
(Amps), frequency (Hz), and the number of
Daisy-chaining, sequentially on the 7-
segment switching display. This indicator
also shows system errors in the form of an
error code such E01, E02, E03 and so on.
Refer to "Error codes" on page 37 under the
appendix for a list of all error codes.
A B C D
Description
E F G H
2
~12~
I J K L
iPoMan II-1200
3
4
